or four payments of $102.76
with
Learn More
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- < Critical Notes >
Associated Numbers
0123505008 0123510033 0123510088 058903016C 058903016CX 058903018C 058903018CX 0986041200 113867 13817 20110374 28-3504 301140RI 437493 56709 90-15-6337 A-6273 AEA3274 AG1079 ALT10349 DRB1200 EAA-223050 LRB00374
BOSCH 0123510033, AL0702X, AL0712X, AL0793X
DELCO 334-2075, DRB1200
LESTER 13817
VOLKSWAGEN 058903016C
0120468121 Bosch show
0123505008 Bosch show
0123510015 Bosch show
0123510033 Bosch show
0123510033SEL +line
0123510088 Bosch show
034903016N VW
058903016C VW
058903016CX VW
058903018C VW
058903018CX VW
0986041200 Bosch ruil
0986041201 Bosch ruil
0986044197 Bosch ruil
113867 Cargo
12041200 EuroTec
13817 Lester
2111581202 DRI
2113851202 DRI
220330 PIC
283504 Elstock
286584 Elstock
305520120 PSH
437493 Valeo
4593 CEVAM
5588SP Spidan
56709 EAI
90156337 Wilson
9041200F Friesen
943355045010 Magneti Marelli
AL0702X Bosch (USA)
CA1140IR HC
DRB1200 Remy
HCA1140IR HC
L41200 ATL
L60260 ATL
LRB00374 Lucas
ALTW268 3EFFE
PRAW268 3EFFE
CGB-83504 AINDE
AEA3274 AUTOELECTRO
0123505008 BOSCHList
0123510033 BOSCHList
0123510088 BOSCHList
0986041200 BOSCH
113867 CARGO
DRB1200 DELCO
A-6273 DIXIE
EAA-223050 EAA
56709 EAI
28-3504 ELSTOCK
AG1079 GHIBAUDI
301140RI KUHNER
LRB00374 LUCAS
LRB374 LUCAS
20110374 PRESTOLITE
310651 RHIAG
437493 VALEO
058903016C VW
058903016CX VW
058903018C VW
058903018CX VW
13817 WAI / TRANSPO
90-15-6337 WILSON
ALT10349 WOODAUTO
ALTW268 3EFFE
PRAW268 3EFFE
0120468121 BOSCHList
0123510015 BOSCHList
4593 CEVAM
28-6584 ELSTOCK
CA1140IR HC PARTS
8EL737160-001 HELLA
ALB1140 KRAUF
301140RI KUHNER
LRA03474 LUCAS
LRA3474 LUCAS
943355045010 MAGNETI MARELLI
944390412000 MAGNETI MARELLI
MAR5545 MAGNETI MARELLI
MRA41200 MAGNETI MARELLI
89213134 POWERMAX
305.520.120 PSH
310651 RHIAG
034903016N VW
13817R WAI / TRANSPO
ALTW268 3EFFE
PRAW268 3EFFE
0120468121 BOSCHList
0123510015 BOSCHList
4593 CEVAM
28-6584 ELSTOCK
CA1140IR HC PARTS
8EL737160-001 HELLA
ALB1140 KRAUF
301140RI KUHNER
LRA03474 LUCAS
LRA3474 LUCAS
943355045010 MAGNETI MARELLI
944390412000 MAGNETI MARELLI
MAR5545 MAGNETI MARELLI
MRA41200 MAGNETI MARELLI
89213134 POWERMAX
305.520.120 PSH
310651 RHIAG
034903016N VW
13817R WAI / TRANSPO
Specifications
| Amp | 120 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | M10x1.50 mm |
| Diameter (D.2) | 10.5 mm |
| Diameter (D.3) | 10.5 mm |
| Length (L.1) | 186 mm |
| Mount Inside Length or Pad Mount C-C (C) | 81.5 mm |
| OEM Product | No |
| Plug Code | PL_9104 |
| Product Line | Premium Line |
| Product Type | Remanufactured |
| Pulley Grooves | 5 qty |
| Pulley Outside Diameter (O.D.1) | 55 mm |
| Pulley to Mount Distance (A) | 35 mm |
| Pulley Type | SOLID |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | 80 2.2 Quattro | [ADU] | 03.1994-05.1995 |
| AUDI | 80 2.2 S2 Quattro | [ABY] | 02.1993-07.1995 |
| AUDI | A4 1.6 | [ADP] | 01.1995-10.1996 |
| AUDI | A4 1.6 | [AHL] | 10.1996-07.1999 |
| AUDI | A4 1.8 | [ADR] | 01.1995-11.2000 |
| AUDI | A4 1.8 | [ADR] | 11.1994-04.1999 |
| AUDI | A4 1.8 | [AFY] | 04.1995-11.2000 |
| AUDI | A4 1.8 Quattro | [ADR] | 11.1994-04.1999 |
| AUDI | A4 1.8 Quattro | [AEB] | 11.1994-12.1998 |
| AUDI | A4 1.8 Quattro | [AFY] | 07.1995-11.2000 |
| AUDI | A4 1.8 Quattro | [AJL] | 12.1997-09.2001 |
| AUDI | A4 1.8 Turbo | [AEB] | 11.1994-07.1998 |
| AUDI | A6 1.8 | [ADR] | 12.1995-10.1997 |
| AUDI | A6 1.8 | [AEB] | 12.1997-01.2005 |
| AUDI | A6 1.8 | [AFY] | 02.1998-01.2005 |
| AUDI | A6 1.8 | [AJL] | 12.1997-01.2005 |
| AUDI | A6 1.8 | [AJP] | 07.1997-01.2005 |
| AUDI | A6 1.8 Quattro | [ADR] | 12.1995-10.1997 |
| AUDI | A6 1.8 Quattro | [AEB] | 12.1997-01.2005 |
| AUDI | A6 1.8 Quattro | [AJL] | 12.1997-01.2005 |
| AUDI | A6 1.8 Turbo | [AEB] | 01.1997-01.2005 |
| AUDI | A6 2.8 | [AGE] | 10.1997-07.1998 |
| AUDI | Coupe 2.2 S2 Quattro | [ABY] | 10.1992-12.1996 |
| VW | Passat 1.6 | [ADP] | 10.1996-11.2000 |
| VW | Passat 1.6 | [AHL] | 06.1997-11.2000 |
| VW | Passat 1.6 | [AHL] | 10.1996-11.2000 |
| VW | Passat 1.8 | [ADR] | 06.1997-11.2000 |
| VW | Passat 1.8 | [ADR] | 10.1996-11.2000 |
| VW | Passat 1.8 | [AFY] | 01.1997-11.2000 |
| VW | Passat 1.8 Syncro 4-Motion | [ADR] | 10.1996-11.2000 |
| VW | Passat 1.8 T Syncro | [AEB] | 11.1996-08.2000 |
| VW | Passat 1.8 Turbo | [AEB] | 06.1997-11.2000 |
| VW | Passat 1.8 Turbo | [AEB] | 10.1996-11.2000 |
Reference Information
CGB-83504 AEA3274 LRB374 58903016CX AG1079 0123510033 034903016NX 441287 310651 034903016N 437493 ALT1237 058903016C 28-3504 058903018C A-6273 CAL10083AS DRB1200 0986041200 301140RI PRAW268 113867 0123505008 LRB00374 ALTW268 90-15-6337 0123510088 20110374 20101380BN 13817 ALT10349 STX101378 58903018C 58903016C 56709 058903018CX 2010083.0 058903016CXVideo/Publications
A0273PR< Critical Notes >
The Alternators listed below may need the pulley swapped from the original.
0120468121 BOSCH
0123510015 BOSCH
034903016N VW
