Associated Numbers
0124555006 114036 12811N 1387388 1400520 18.2000M 20101646OE 2010646 2492 48-5819 553004RI 553004RIB 553004RIP 860806 CAL10646GS EAA-221969 LRA03207Specifications
Amp | 80 A |
Bottom Mounting Foot Width (B) | 14 mm |
Diameter (D.1) | 10.5 mm |
Diameter (D.2) | 10.5 mm |
Diameter (D.3) | M10x1.5 mm |
Grooves | 8 qty |
Length (L.1) | 194 mm |
Mount Inside Length or Pad Mount C-C (C) | 81.5 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 55 mm |
Plug Code | PL_5003 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 37.5 mm |
Pulley Type | SOLID |
Unit Type | BOSCH |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
DAF | CF 65.180 5.9 | [CE136C] | 01.2001-12.2006 |
DAF | CF 65.220 5.9 | [CE162] | 01.2001-12.2007 |
DAF | CF 65.220 9.7 | [GR165] | 01.2006- |
DAF | CF 65.250 5.9 | [CE184C] | 01.2001-12.2006 |
DAF | CF 65.250 9.7 | [GR184] | 01.2006- |
DAF | CF 65.280 9.7 | [GR210] | 01.2007- |
DAF | LF 45.140 4.5 | [FR103] | 01.2006- |
DAF | LF 45.150 3.9 | [BE110C] | 01.2001-12.2007 |
DAF | LF 45.160 4.5 | [FR118] | 01.2006- |
DAF | LF 45.170 3.9 | [BE123C] | 01.2001-12.2007 |
DAF | LF 45.180 4.5 | [FR136] | 01.2006- |
DAF | LF 45.180 5.9 | [CE136C] | 01.2001-12.2008 |
DAF | LF 45.220 5.9 | [CE162C] | 01.2001-12.2009 |
DAF | LF 45.220 6.7 | [GR165] | 01.2006- |
DAF | LF 45.250 6.7 | [GR184] | 01.2006- |
DAF | LF 55.180 4.5 | [FR136] | 01.2006- |
DAF | LF 55.180 5.9 | [CE136C] | 01.2001-12.2008 |
DAF | LF 55.220 5.9 | [CE162C] | 01.2001-12.2008 |
DAF | LF 55.250 5.9 | [CE184C] | 01.2001-12.2008 |
DAF | LF 55.250 6.7 | [GR184] | 01.2006- |
DAF | LF 55.280 6.7 | [GR210] | 01.2006- |
Reference Information
18.2000M LRA03207 553004RIB CAL10646GS 2492 A24BH0095AS ALT126460A 2010646 48-5819 860806 CA2117IR LRA3207 553004RIP 0124555006 114036 ALT126460 PRAS943 D276002 1400520R ALTS943 EAA-221969 ALT1625 12811N 553004RI AELD074 442007 1387388 1400520 124555006 20101646OE 1528594Video/Publications
0124555006 114036 12811N 1387388 1400520 18.2000M 20101646OE 2010646 2492 48-5819 553004RI 553004RIB 553004RIP 860806 ALT126460 ALT126460A ALTS943 CA2117IR CAL10646GS EAA-221969 LRA03207 LRA3207 PRAS943Add Your Number
