Brand new AS-PL Alternator
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 525.95 including GST
NZ$ 457.35 excluding GST
or four payments of $131.49
with
Learn More
each
A0250
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Related Items
Information
0124555006Associated Numbers
0124555006 114036 12811N 1387388 1400520 18.2000M 20101646OE 2010646 2492 48-5819 553004RI 553004RIB 553004RIP 860806 CAL10646GS EAA-221969 LRA03207Specifications
| Amp | 80 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 10.50 mm |
| Diameter (D.2) | 10.50 mm |
| Diameter (D.3) | M10x1.5 mm |
| Length (L.1) | 194 mm |
| Mount Inside Length or Pad Mount C-C (C) | 81.50 mm |
| OEM Product | No |
| Plug Code | PL_5003 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 8 qty |
| Pulley Outside Diameter (O.D.1) | 55 mm |
| Pulley to Mount Distance (A) | 37.50 mm |
| Pulley Type | Solid |
| Unit Type | BOSCH |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| DAF | CF 65.180 5.9 | [CE136C] | 01.2001-12.2006 |
| DAF | CF 65.220 5.9 | [CE162] | 01.2001-12.2007 |
| DAF | CF 65.220 9.7 | [GR165] | 01.2006- |
| DAF | CF 65.250 5.9 | [CE184C] | 01.2001-12.2006 |
| DAF | CF 65.250 9.7 | [GR184] | 01.2006- |
| DAF | CF 65.280 9.7 | [GR210] | 01.2007- |
| DAF | LF 45.140 4.5 | [FR103] | 01.2006- |
| DAF | LF 45.150 3.9 | [BE110C] | 01.2001-12.2007 |
| DAF | LF 45.160 4.5 | [FR118] | 01.2006- |
| DAF | LF 45.170 3.9 | [BE123C] | 01.2001-12.2007 |
| DAF | LF 45.180 4.5 | [FR136] | 01.2006- |
| DAF | LF 45.180 5.9 | [CE136C] | 01.2001-12.2008 |
| DAF | LF 45.220 5.9 | [CE162C] | 01.2001-12.2009 |
| DAF | LF 45.220 6.7 | [GR165] | 01.2006- |
| DAF | LF 45.250 6.7 | [GR184] | 01.2006- |
| DAF | LF 55.180 4.5 | [FR136] | 01.2006- |
| DAF | LF 55.180 5.9 | [CE136C] | 01.2001-12.2008 |
| DAF | LF 55.220 5.9 | [CE162C] | 01.2001-12.2008 |
| DAF | LF 55.250 5.9 | [CE184C] | 01.2001-12.2008 |
| DAF | LF 55.250 6.7 | [GR184] | 01.2006- |
| DAF | LF 55.280 6.7 | [GR210] | 01.2006- |
Reference Information
| 0124555006 | BOSCH |
| 0124555006 | BOSCH |
| 0124555006R | RNL |
| 0124555006R | RNL |
| 0124555006RP | RNL |
| 0124555006RP | RNL |
| 0124555108 | BOSCH |
| 0124555108 | BOSCH |
| 0986047410 | BOSCH |
| 0986047410 | BOSCH |
| 11.209.601 | ISKRA / LETRIKA |
| 11.209.601 | ISKRA / LETRIKA |
| 114036 | CARGO |
| 114036 | CARGO |
| 12811N | WAI / TRANSPO |
| 12811N | WAI / TRANSPO |
| 1387388 | DAF |
| 1387388 | DAF |
| 1400520 | DAF |
| 1400520 | DAF |
| 1400520R | DAF |
| 1400520R | DAF |
| 1528594 | DAF |
| 1528594 | DAF |
| 18.2000M | CQ |
| 18.2000M | CQ |
| 19092045 | DELCO |
| 19092045 | DELCO |
| 1986A00513 | BOSCH |
| 1986A00513 | BOSCH |
| 1986A00915 | BOSCH |
| 1986A00915 | BOSCH |
| 20010646AV | ITAB AUTOMOTIVE |
| 20010646AV | ITAB AUTOMOTIVE |
| 20010646OV | ITAB AUTOMOTIVE |
| 20010646OV | ITAB AUTOMOTIVE |
| 20101646BN | REAL |
| 20101646BN | REAL |
| 20101646OE | REAL |
| 20101646OE | REAL |
| 2010646.0 | SANDO |
| 2010646.0 | SANDO |
| 2010646.1 | SANDO |
| 2010646.1 | SANDO |
| 202100 | VALEO |
| 202100 | VALEO |
| 2165376 | DAF |
| 2165376 | DAF |
| 2492 | CEVAM |
| 2492 | CEVAM |
| 440129 | VALEO |
| 440129 | VALEO |
| 442007 | LOGISTIK |
| 442007 | LOGISTIK |
| 443514 | VALEO |
| 443514 | VALEO |
| 48-5819 | ELSTOCK |
| 48-5819 | ELSTOCK |
| 553004RI | KUHNER |
| 553004RI | KUHNER |
| 553004RIB | KUHNER |
| 553004RIB | KUHNER |
| 553004RIP | KUHNER |
| 553004RIP | KUHNER |
| 5610078 | MEAT & DORIA |
| 5610078 | MEAT & DORIA |
| 5610078G | MEAT & DORIA |
| 5610078G | MEAT & DORIA |
| 6.8157.1 | IKA |
| 6.8157.1 | IKA |
| 72445479 | MAHLE |
| 72445479 | MAHLE |
| 860806 | PRESTOLITE |
| 860806 | PRESTOLITE |
| 906.502.080.014 | PSH |
| 906.502.080.014 | PSH |
| 906.502.080.280 | PSH |
| 906.502.080.280 | PSH |
| A146.521 | PSH |
| A146.521 | PSH |
| A24BH0095 | SIDAT |
| A24BH0095 | SIDAT |
| A24BH0095AS | SIDAT |
| A24BH0095AS | SIDAT |
| AAN5390 | ISKRA / LETRIKA |
| AAN5390 | ISKRA / LETRIKA |
| AELD074 | LEYLAND |
| AELD074 | LEYLAND |
| ALT126460 | SIOM |
| ALT126460 | SIOM |
| ALT126460A | SIOM |
| ALT126460A | SIOM |
| ALT1625 | ELECTROLOG |
| ALT1625 | ELECTROLOG |
| ALTS943 | 3EFFE |
| ALTS943 | 3EFFE |
| AZMT-49-035-2878 | A.Z. MEISTERTEILE |
| AZMT-49-035-2878 | A.Z. MEISTERTEILE |
| BOS0124555006 | WOODAUTO |
| BOS0124555006 | WOODAUTO |
| BOS1986A00513 | WOODAUTO |
| BOS1986A00513 | WOODAUTO |
| BREF0320986047410 | CARWOOD GROUP |
| BREF0320986047410 | CARWOOD GROUP |
| CA2117IR | HC PARTS |
| CA2117IR | HC PARTS |
| CAL10646AS | CASCO |
| CAL10646AS | CASCO |
| CAL10646GS | CASCO |
| CAL10646GS | CASCO |
| D276002 | PACCAR |
| D276002 | PACCAR |
| DRB7410 | DELCO |
| DRB7410 | DELCO |
| F032114036 | CARGO |
| F032114036 | CARGO |
| G100656 | BTS TURBO |
| G100656 | BTS TURBO |
| G101041 | BTS TURBO |
| G101041 | BTS TURBO |
| G101323 | BTS TURBO |
| G101323 | BTS TURBO |
| H5610078 | HOFFER |
| H5610078 | HOFFER |
| H5610078G | HOFFER |
| H5610078G | HOFFER |
| IA9449 | ISKRA / LETRIKA |
| IA9449 | ISKRA / LETRIKA |
| LRA03207 | LUCAS |
| LRA03207 | LUCAS |
| LRA3207 | LUCAS |
| LRA3207 | LUCAS |
| MG810 | MAHLE |
| MG810 | MAHLE |
| PRAS943 | 3EFFE |
| PRAS943 | 3EFFE |
| PRE860806 | WOODAUTO |
| PRE860806 | WOODAUTO |
| PRE860806GB | WOODAUTO |
| PRE860806GB | WOODAUTO |
| RNL4741 | RNL |
| RNL4741 | RNL |
| RNL4741OER | RNL |
| RNL4741OER | RNL |
| SEG0124555108 | WOODAUTO |
| SEG0124555108 | WOODAUTO |
| WG2044009 | WILMINK GROUP |
| WG2044009 | WILMINK GROUP |
| WG2282955 | WILMINK GROUP |
| WG2282955 | WILMINK GROUP |
