Associated Numbers
0124325014 038903025A 0986042710 11.1548 112401 20101353OE 2010353 28-4630 301548RI 4064 437742 56841 89213017 9042710 9213017 944390427100 AEA4277 ALT10369 CA1548IR CAL10353GS DRB2710 LRB00477 SA306Specifications
Amp | 90 A |
Bottom Mounting Foot Width (B) | 14 mm |
Diameter (D.1) | 9 mm |
Diameter (D.2) | 9 mm |
Diameter (D.3) | M8x1.25 mm |
Diameter (D.4) | M8x1.25 mm |
Grooves | 5 qty |
Length (L.1) | 183 mm |
Mount Inside Length or Pad Mount C-C (C) | 61 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 56 mm |
Plug Code | PL_2300 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 44 mm |
Pulley Type | CLUTCH |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
SEAT | Arosa 1.7 SDi | [AKU] | 01.1999-12.2002 |
SEAT | Arosa 1.7 SDi | [AKU] | 08.1997-06.2004 |
VW | Lupo 1.7 SDi | [AKU] | 04.1998-07.2005 |
VW | Lupo 1.7 SDi | [AKU] | 09.1998-07.2005 |
VW | Polo 1.4 FSi | [AXU] | 01.2001- |
VW | Polo 1.7 D | [AHG] | 01.1998-01.2001 |
VW | Polo 1.7 SDi | [AHG] | 10.1999- |
VW | Polo 1.7 SDi | [AHG] | 10.1999-09.2001 |
VW | Polo 1.7 SDi | [AKU] | 10.1999-09.2001 |
VW | Polo 1.9 SDi | [AGD] | 10.1999-09.2001 |
VW | Polo 1.9 SDi | [ASX] | 10.1999-09.2001 |
Reference Information
9042710 ALTS299 CAL10353GS 112401 PRAS299 SA306 209043 20101353OE AI-90084 RNL4271 LRB477 A12BH1154A2 038903025A A0235 9.4439E+11 38903025A ALT123530 PRAS299B DRB2710 301548RI ALT123530A ALTS299B 0124325014 0986042710 28-4630 4064 89213017 9213017 AEA4277 124325014 ALT10369 CA1548IR LRB00477 ANM44930X 441695 56841 310885 ALT1865 986042710 ALTW290 11.1548 437742 STA0488R 2010353Video/Publications
0124325014 038903025A 0986042710 11.1548 112401 20101353OE 2010353 28-4630 301548RI 310885 4064 437742 56841 89213017 9042710 944390427100 AEA4277 AI-90084 ALT10369 ALT123530 ALT123530A ALTS299 ALTS299B ALTW290 CA1548IR CAL10353GS DRB2710 LRB00477 LRB477 PRAS299 PRAS299B RNL4271 SA306 209043Add Your Number
