Brand new AS-PL Alternator
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 635.04 including GST
NZ$ 552.21 excluding GST
or four payments of $158.76
with
Learn More
each
AAM-C6189
A0201
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0124625019Associated Numbers
0111549802 0121549802 0124625019 0986046340 11.1764 11.1764M 113944 20101141BN 20101141OE 20101141RC 2010141 23269N 28-4728 301764RI 301764RIB 301764RIK 4809 56924 89212549 8EL012426-081 8EL738159-001 9046340 9212549 A0111549802 A0121549802 A0201 AEC1764 ALT10434 CA1764IR CAL10141AS CAL10141GS CAL10141RS DRB6340 EAA-221172 GA625019-A LRA02250 SA359 SB168Specifications
| Amp | 200 A |
| Diameter (D.1) | 9.50 mm |
| Diameter (D.2) | 9.50 mm |
| Diameter (D.3) | 9 mm |
| Diameter (D.4) | 9 mm |
| Length (L.1) | 188 mm |
| Mount Inside Length or Pad Mount C-C (C) | 56 mm |
| OEM Product | No |
| Pad mount thickness (E.1) | 93 mm |
| Pad mount thickness (E.2) | 93 mm |
| Pad mount thickness (E.3) | 97 mm |
| Plug Code | PL_2300 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 50 mm |
| Pulley to Mount Distance (A) | 32.50 mm |
| Pulley Type | Clutch |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MERCEDES BENZ | E 200 E 2.1 CDi | (211)[OM646.951] | 07.2002- |
| MERCEDES BENZ | E 220 2.1 CDi | (211)[OM646.961] | 03.2002- |
| MERCEDES BENZ | E 220 2.1 CDi | (S211)[OM646.961] | 03.2003- |
| MERCEDES BENZ | E 220 2.1 CDi | (W211)[OM646.961] | 03.2002- |
| MERCEDES BENZ | E 220 2.2 CDi | [OM646.961] | 03.2003- |
| MERCEDES BENZ | E 270 2.7 CDi | (210)[OM612.961] | 03.2002- |
| MERCEDES BENZ | E 270 2.7 CDi | (210)[OM647.961] | 03.2003- |
| MERCEDES BENZ | E 280 3.2 CDi | (211)[OM648.961] | 05.2004-03.2005 |
| MERCEDES BENZ | E 320 3.2 CDi | [OM648.961] | 11.2002-03.2005 |
| MERCEDES BENZ | S 320 3.2 CDi | (220)[OM648.960] | 09.2002- |
Reference Information
| 0111549802 | MERCEDES |
| 011154980280 | MERCEDES |
| 0121549802 | MERCEDES |
| 012154980280 | MERCEDES |
| 0124625019 | BOSCH |
| 0986046340 | BOSCH |
| 11.1764 | LAUBER |
| 11.1764M | LAUBER |
| 113944 | CARGO |
| 20101141BN | REAL |
| 20101141OE | REAL |
| 20101141RC | REAL |
| 2010141 | SANDO |
| 210273 | ERA |
| 23269N | WAI / TRANSPO |
| 28-4728 | ELSTOCK |
| 301764RI | KUHNER |
| 301764RIB | KUHNER |
| 301764RIK | KUHNER |
| 311028 | RHIAG |
| 32046340 | HERTH+BUSS |
| 441917 | LOGISTIK |
| 4809 | CEVAM |
| 5515155 | MEAT & DORIA |
| 56924 | EAI |
| 89212549 | POWERMAX |
| 8EL012426-081 | HELLA |
| 8EL738159-001 | HELLA |
| 9046340 | FRIESEN |
| 9212549 | POWERMAX |
| A0111549802 | MERCEDES |
| A011154980280 | MERCEDES |
| A0121549802 | MERCEDES |
| A012154980280 | MERCEDES |
| A0201 | AS-PL |
| A12BH0274A2 | SIDAT |
| A12BH0274AS | SIDAT |
| AEC1764 | AUTOELECTRO |
| AI-90038 | AINDE |
| ALT10434 | WOODAUTO |
| ALT121410 | SIOM |
| ALT121410A | SIOM |
| ALT121410R | SIOM |
| ALT121580 | SIOM |
| ALT1367 | ELECTROLOG |
| ALTL128 | 3EFFE |
| ALTL128B | 3EFFE |
| ALTL128HQ | 3EFFE |
| ANM48560X | ANDEL |
| CA1764IR | HC PARTS |
| CAL10141AS | CASCO |
| CAL10141GS | CASCO |
| CAL10141RS | CASCO |
| CGB-84728 | AINDE |
| DRB6340 | DELCO |
| F032113944 | CARGO |
| GA625019-A | GPARTS |
| LRA02250 | LUCAS |
| LRA2250 | LUCAS |
| PRAL128HQ | 3EFFE |
| RNL4634 | RNL |
| RNL625033 | RNL |
| SA359 | SOVEREIGN |
| SB168 | SOVEREIGN |
| STX100419 | STARDAX |
| STX100419R | STARDAX |
Video/Publications
