A0188 - Brand new AS-PL Alternator

Associated Numbers

0124325015 0124325033 036903024L 037903025H 037903025P 038903018C 038903018CX 0986041310 11.1560 112408 20130117 2015281 20179182OE 21480R 2542280 2542840 28-3914 301560RI 32041310 4063 437403 439444 56856 89213033 8EL737814-001 9041310 9213033 AEA4280 ALT14238 CA1560IR CAL15281GS DRB1310 EAA-221550 IA1304 LRB00480 SG9B023 SG9B069

Specifications

Amp	90 A
Bottom Mounting Foot Width (B)	14 mm
Diameter (D.1)	8 mm
Diameter (D.2)	9.50 mm
Diameter (D.3)	M8x1.25 mm
Length (L.1)	183 mm
Mount Inside Length or Pad Mount C-C (C)	61 mm
OEM Product	No
Plug Code	PL_2300
Product Line	Standard Line
Product Type	Brand new
Pulley Grooves	6 qty
Pulley Outside Diameter (O.D.1)	50 mm
Pulley to Mount Distance (A)	40 mm
Pulley Type	Solid
Unit Type	BOSCH
Voltage	12 V

Vehicle Applications

Make	Model	Type	Year
SEAT	Arosa 1.0	[AER]	05.1997-09.1999
SEAT	Arosa 1.0	[ALD]	01.1999-07.2000
SEAT	Arosa 1.0	[ALL]	10.1997-05.1999
SEAT	Arosa 1.0	[ANV]	01.1999-07.2000
SEAT	Arosa 1.0	[AUC]	05.2000-06.2004
SEAT	Cordoba 1.0	[ALD]	06.1999-10.2002
SEAT	Cordoba 1.0	[ANV]	06.1999-10.2002
SEAT	Cordoba 1.0	[AUC]	06.1999-10.2002
SEAT	Cordoba 1.0 16V	[AST]	05.2000-10.2002
SEAT	Cordoba 1.0 16V	[AVZ]	05.2000-10.2002
SEAT	Cordoba 1.4 16V	[BBY]	10.2002-
SEAT	Cordoba 1.4 16V	[BBZ]	10.2002-
SEAT	Cordoba 1.4 16V	[BXW]	05.2006-
SEAT	Cordoba 1.6	[BAH]	02.2003-
SEAT	Ibiza 1.0	[ALD]	05.1999-05.2002
SEAT	Ibiza 1.0	[ANV]	05.1999-07.2000
SEAT	Ibiza 1.0	[AUC]	07.2000-05.2002
SEAT	Ibiza 1.0 16V	[AST]	05.2000-02.2002
SEAT	Ibiza 1.0 16V	[AVZ]	05.2000-02.2002
SEAT	Ibiza 1.4 16V	[AUB]	02.2002-
SEAT	Ibiza 1.4 16V	[BBY]	02.2002-
SEAT	Ibiza 1.4 16V	[BBZ]	02.2002-
SEAT	Ibiza 1.4 16V	[BXW]	05.2006-
SEAT	Ibiza 1.6	[BAH]	02.2003-
SKODA	Fabia 1.4	[BXW]	03.2007-
SKODA	Fabia 1.4 16V	[AUA]	09.2000-08.2003
SKODA	Fabia 1.4 16V	[AUB]	10.2001-09.2003
SKODA	Fabia 1.4 16V	[BBY]	09.2000-05.2004
SKODA	Fabia 1.4 16V	[BBZ]	10.2001-
SKODA	Fabia 1.4 16V	[BKY]	05.2004-
SKODA	Fabia 1.4 16V	[BUD]	04.2006-12.2007
SKODA	Octavia 1.4	[AMD]	04.1999-03.2001
SKODA	Octavia 1.4	[BCA]	01.2002-
SKODA	Octavia 1.4	[BUD]	05.2006-
VW	Caddy 1.4	[BCA]	03.2004-05.2006
VW	Fox 1.4	[BKR]	04.2005-
VW	Golf V 1.4	[BUD]	06.2007-
VW	Golf V 1.4 16V	[BUD]	05.2006-07.2007
VW	Golf V Plus 1.4 16V	[BUD]	05.2006-07.2007
VW	Lupo 1.0	[AER]	01.1999-05.2000
VW	Lupo 1.0	[ALD]	05.1999-07.2005
VW	Lupo 1.0	[ALL]	10.1998-05.2000
VW	Lupo 1.0	[ANV]	05.1999-05.2000
VW	Lupo 1.0	[AUC]	05.2000-07.2005
VW	Polo 1.0	[ALD]	07.1998-09.2001
VW	Polo 1.0	[AUC]	10.1999-09.2001
VW	Polo 1.4	[AAK]	09.1998-09.2001
VW	Polo 1.4	[AKP]	12.1998-09.2001
VW	Polo 1.4	[AUB]	10.2001-04.2002
VW	Polo 1.4	[AUD]	10.1999-09.2001
VW	Polo 1.4 16V	[AUA]	06.2000-09.2001
VW	Polo 1.4 16V	[BBY]	10.2001-
VW	Polo 1.4 16V	[BBZ]	10.2001-
VW	Polo 1.4 16V	[BKY]	10.2001-
VW	Polo 1.4 16V	[BUD]	05.2006-

Reference Information

0124325015	BOSCH
0124325033	BOSCH
036903024L	VW
036903024LX	VW
037903025H	VW
037903025P	VW
037903025PX	VW
038903018C	VW
038903018CX	VW
059903015H	VW
0986041310	BOSCH
11.1560	LAUBER
112408	CARGO
20130117	PRESTOLITE
2015281	SANDO
20179182OE	REAL
210731	ERA
21480R	WAI / TRANSPO
2542280	VALEO
2542840	VALEO
28-3914	ELSTOCK
301560RI	KUHNER
305.530.090.010	PSH
305.530.090.500	PSH
310895	RHIAG
32041310	HERTH+BUSS
36903024L	VW
36903024LX	VW
37903025H	VW
37903025P	VW
37903025PX	VW
38903018C	VW
38903018CX	VW
4063	CEVAM
437403	VALEO
439444	VALEO
441707	LOGISTIK
56856	EAI
89213033	POWERMAX
8EL737814-001	HELLA
9041310	FRIESEN
9213033	POWERMAX
A0188	AS-PL
A12BH0401A2	SIDAT
A12VA0401	SIDAT
A132.346	PSH
A148.162	PSH
AAL2047	APEC
AEA4280	AUTOELECTRO
ALT00792	ELECTROLOG
ALT14238	WOODAUTO
ALT1458	ELECTROLOG
ALT172810	SIOM
ALT2130	3EFFE
ALTS980	3EFFE
ANM43530X	ANDEL
CA1560IR	HC PARTS
CAL15281GS	CASCO
CGB-83914	AINDE
DRB1310	DELCO
F032112408	CARGO
IA1304	ISKRA / LETRIKA
LRB00480	LUCAS
LRB480	LUCAS
NPANAL2047	NAPA
PRAS980	3EFFE
PRAS980V	3EFFE
RNL4131	RNL
SG9B023	VALEO
SG9B069	VALEO
STA0408R	BOVEZ
STX100325	STARDAX
STX100325R	STARDAX
STX100413	STARDAX
STX100413R	STARDAX
