Associated Numbers
0120300528 0120300529 0120300558 0120300559 0120300568 0120300569 0120339515 0120339516 0120339527 0120339528 0986030120 10590 11.0077 11.0077M 11.201.017 11.201.037 11.201.783 111180 12029N 20119001BN 20119001OE 20130207 2021100 2091 2119 28-0537 30355RI 30355RIL 30355RIM 3045 30680274 3077RI 3077RIM 4224325 4257063 4257074 4257771 4265 4274815 4275283 4275285 4275286 4325179 432991 436109 4474729 4474752 4474815 4474816 4475266 4475268 46231680 4998353 505.002.033 5101645 55697 63300506 63300506010 63300521 63300521010 63300802 63300900 63300901 63300920 63300921 63300931 63300931010 63321032 63321032010 63362003 63362003010 63362004 63362004010 63362006 63362006010 77145410 77150410 77250410 9030120 9212983 A0012 AAG0402 AAG0403 AAG1104 AAG1130 AAK1104 AEA1199 ALT12006 CA77IR CAL21100 CAL21100AS CAL21100ES CAL21100GS CAL21100OS CAL21100RS DAN607 DRA0120 EAA-221059 IA0037 LRA00199 LRA00913 SA204 8EL012427-661 8EL725944-001 20104036
ANB201
0120300528 Bosch show
0120300529 Bosch show
0120300558 Bosch show
0120300559 Bosch show
0120300568 Bosch show
0120300569 Bosch show
0120339515 Bosch
0120339516 Bosch
0120339527 Bosch
0120339528 Bosch
063300900 Magneti Marelli
063300901 Magneti Marelli
063300920 Magneti Marelli
063300921 Magneti Marelli
0986030120 Bosch ruil
0986030121 Bosch ruil
0986121177 Bosch ruil
110180 Cargo
110899 Cargo
111180 Cargo
11201017 Mahle
11201037 Mahle
11201783 Mahle
116133 Cargo
12029 EAI
12030120 EuroTec
12033880 EuroTec
19025787 Delco
2091 CEVAM
218103332 DRI
220420 PIC
2338 CEVAM
280537 Elstock
294390900 Same
3045 CEVAM
30680274 Magneti Marelli
3121SP Spidan
4224325 Fiat
4257063 Fiat
4257074 Fiat
4257771 Fiat
4274815 Fiat
4275283 Fiat
4275285 Fiat
4275286 Fiat
4325179 Fiat
432991 Valeo
436109 Valeo
4474729 Fiat
4474752 Fiat
4474815 Fiat
4474816 Fiat
46231680 Fiat
46621735 Fiat
4753104 Fiat
4998353 Allis-chalmers
5011827 Fiat
505002033 PSH
5101707 Fiat
55696 EAI
55697 EAI
5974259 Fiat
6000102364 Renault
6005701124 Renault
63300506 Magneti Marelli
63300521 Magneti Marelli
63300521010 Magneti Marelli
63300802 Magneti Marelli
63300802010 Magneti Marelli
63300900 Magneti Marelli
63300900010 Magneti Marelli
63300901 Magneti Marelli
63300901010 Magneti Marelli
63300920 Magneti Marelli
63300920010 Magneti Marelli
63300921 Magneti Marelli
63300921010 Magneti Marelli
63321032 Magneti Marelli
63362003 Magneti Marelli
63362004 Magneti Marelli
63362006 Magneti Marelli
72735436 Mahle
75558 EAI
7580206 Fiat
77250410 Fiat
8EL725944001 Hella
90156283 Wilson
9030120 Friesen
9030120F Friesen
9120143035 Bosch
930120 Remy
943300920 Magneti Marelli
9972269 Ford
AAG0402 Mahle
AAG0403 Mahle
AAG1104 Mahle
AAG1130 Mahle
ALT1268sa Electrolog
ALTH017 Unipoint
CA45 HC
CA45IR HC
CA77IR HC
DAN609 Denso
DRA0120 Remy
F042A0H017 Bosch
HCA77IR HC
IA0017 Mahle
IA0037 Mahle
IA0783 Mahle
L30120 ATL
L32170 ATL
LRA00199 Lucas
LRA00913 Lucas
LRA199 Lucas
LRA913 Lucas
MAN320 Magneti Marelli
MAN379 Magneti Marelli
MG123 Mahle
MG437 Mahle
NA284 Valeo
SP3121 Spidan
VA198 Valeo
W23018 van Heck
W23023 van Heck
Bosch AL84X
Substitutes:
MAHLE MG437
Valeo 432991
Wilson 90-15-6283
References:
Bosch 0120300528, 0120300529, 0120300550, 0120300551, 0120300558, 0120300559, 0120300568, 0120300569, 0120339515, 0120339516, 0120339527, 0120339528, AL84X
Lucas A0828, A6556
Magneti Marelli 63302004, 63362006
AL87X
References:
Bosch 0120300528, 0120300529, 0120300550, 0120300551, 0120300558, 0120300559, 0120300568, 0120300569
Lester 13058
Superseded From:
Valeo 9AR5006, 9AR5006G, NA284
Substitutes:
Lucas A0913
Magneti Marelli MAN344
MAHLE MG437
Valeo 436109
References:
Bosch 0120339515, 0120339516, 0120339527, 0120339528, 0986030120, 0986030121, AL87X
Delco 31-265, DRA0120, RM0007
Delphi RM0007
Fiat 4224325, 4257074, 4273601, 4275283, 4373601, 4474729, 4474752, 46231680, 4998353, 77145410, 77250410
Hella CA45, CA77IR
Leece Neville 9AR5006G
Lucas LRA199, LRA913
Magneti Marelli 63300900, 63300901, 63300920, 63300921, 63362006, 943300920, MAN344
Valeo 436109, 950060, 9AR5006, 9AR5006G, NA284
MAHLE MG535
Valeo 432991
References:
Bosch 0120339515, 0120339516, 0120339527, 0120339528, 0120489126, 0120489127, 0120489187, 0120489188, 0120489401, 0120489738, 0120489739, 0986030120, 0986030121, 0986030940, 0986030941, 0986033250, 0986033251
Fiat 4224325, 4257074, 4275283, 4395131, 4395134, 4405303, 4418109, 4419109, 4419794, 4434083, 4434084, 4474729, 4474752, 46231680, 46231684, 46231687, 46445098, 4998353, 5955501, 5958394, 5958395, 5958565, 5967595, 5967596, 5967965, 5974259, 7541823, 7552459, 7565588, 7580207, 765558, 7667795, 77145410, 77250410, 77320410, 77367410, 77367411, 7765558, 9922350
Lester 12030
Lucas LRA199, LRA270, LRA603, LRA913, LRA998, NAB004, NAB013
Magneti Marelli 063321154010, 24203, 24214, 54022240, 63300900, 63300920, 63305101, 63305131, 63305401, 63305431, 63307101, 63307125, 63307131, 63307401, 63307431, 63320004, 63320006, 63320028, 63320047, 63321003, 63321006, 63321058, 63321154
MAHLE 11201203, 11201204, AAK1163, AAK1171, AAK1172, MG437
Valeo 432991
MAHLE 11201017, 11201085, 11201167, 11201203, 11201204, 11201405, AAG0403, AAK1123, AAK1163, AAK1171, AAK1172, AAK3529, IA0405
Substitutes:
Valeo 433115
References:
Bosch 0120489126, 0120489127, 0120489187, 0120489188, 0120489738, 0120489739, 0986030940, 0986030941, 0986030948, 0986033250, 0986033251
Fiat 4395131, 4395134, 4405303, 4418109, 4419109, 4419794, 4434083, 4434084, 46231684, 46231687, 5955501, 5958394, 5958395, 5967595, 5967596, 5967965, 7533853, 7541823, 7552459, 7565398, 7565588, 7580207, 7667795, 77320410, 77367410, 77367411, 7765558, 992235
Lucas 23980, 23980A, 23980B, LRA0405, LRA270, LRA405, LRA464, LRA603, LRA998
Magneti Marelli 30680307, 30680352, 63305101, 63305131, 63305401, 63305431, 63307101, 63307125, 63307131, 63307401, 63307431, 63320004, 63320005, 63320006, 63320028, 63320035, 63321003, 63321004, 63321005, 63321006, 63321007, 63321058, 943321003, 943321004, 943321007, 943321068, 943356806, MAN344
MAHLE IA0405
Paris Rhone A13E25
Valeo 433114, 433115, 433116, 436114, 436115, 436245, NA381, VA166
Specifications
| Amp | 33 A |
| Diameter (D.1) | 10 mm |
| Diameter (D.2) | 10 mm |
| Diameter (D.3) | 10 mm |
| Grooves | 1 qty |
| Length (L.1) | 162 mm |
| Outside Diameter (O.D.1) | 59 mm |
| Pivot Foot Length (B) | 24 mm |
| Pivot Inside Length (C) | 74 mm |
| Plug Code | PL_3201 |
| Pulley Type | SOLID |
| Pulley to Mount Distance (A) | 48.5 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FIAT | 127 1.0 | [127A.000] | 04.1977-05.1983 |
| FIAT | 127 1.0 | [127A.000] | 04.1977-12.1986 |
| FIAT | 127 1.0 Panorama | [127A.000] | 01.1977-12.1986 |
| FIAT | 127 1.0 Panorama | [127A.000] | 04.1977-05.1986 |
| FIAT | 127 1.0 Sport | [127A1.000] | 07.1978-02.1982 |
| FIAT | 127 1.0 Sport | [127A1.000] | 07.1978-11.1981 |
| FIAT | 128 1.1 1100 | [128A.000] | 09.1969-12.1984 |
| FIAT | 128 1.1 1100 | [128A.000] | |
| FIAT | 128 1.1 1100 | [128A.048] | 02.1975-02.1981 |
| FIAT | 128 1.1 1100 | [128A.048] | 02.1975-09.1981 |
| FIAT | 128 1.1 1100 | [128A.048] | 09.1969-09.1981 |
| FIAT | 128 1.1 1100 | [128AC5.000] | 03.1972-02.1981 |
| FIAT | 128 1.1 1100 | [128AC5.000] | 08.1975-02.1981 |
| FIAT | 128 1.3 1300 | [128A1.000] | 01.1971-12.1984 |
| FIAT | 128 1.3 1300 | [128A1.000] | 12.1974-10.1982 |
| FIAT | 128 1.3 1300 | [128AC.000] | 03.1972-12.1979 |
| FIAT | 128 1.3 1300 | [128AC.000] | 11.1971-12.1975 |
| FIAT | 128 1.3 1300 Berlinetta | [128AC.000] | 06.1975-12.1979 |
| FIAT | 128 1.3 1300 Sport | [128A1.000] | 08.1974-12.1984 |
| FIAT | 128 1.3 1300 Sport | [128A1.000] | 10.1978-12.1984 |
| FIAT | 420 D | 01.1984- | |
| FIAT | 500S D | 01.1978-01.1982 | |
| FIAT | 540 | [8035.02.302] | 03.1978- |
| FIAT | Fiorino 1.05 | [127A.000] | 01.1980-12.1987 |
| FIAT-ALLIS | Various Models | ||
| LAMBORGHINI | C 554 2.8 D | [100.3P] | 06.1987-12.2000 |
| LAMBORGHINI | C 554 2.8 Diesel | [100.3P] | 06.1987-12.2000 |
| LAMBORGHINI | R 513 2.7 D | [983L] | 03.1983-12.1995 |
| LAMBORGHINI | R 513 2.7 Diesel | [983L] | 03.1983-12.1995 |
| SAME | Centauro 70 Diesel | 12.1981-10.1987 | |
| SAME | Centurion 75 Diesel | 11.1978-05.1988 | |
| SAME | Ranger 45 2.7 Diesel | 02.1982-08.1985 | |
| ZASTAVA | 101 1.1 | [128A.000] | 06.1973-01.1990 |
| ZASTAVA | 101 1.1 | [128A.000] | 12.1975-01.1980 |
| ZASTAVA | 101 1.1 1100 | [128A.064] | 05.1975-12.1993 |
| ZASTAVA | 101 1.1 Super | [128AC5000] | 07.1979-09.1981 |
| ZASTAVA | 101 1.3 1100 | [128AR000] | 10.1981-12.1993 |
Reference Information
PRAS572 SA204 4474752 ALT1050R EAA-221059 63300931 46231680 8EL725944-001 63321032010 ALT12006 12029N 110899 3077RI 123 120300559 4325179 120300558 55697 ALT1050A 432991 3077RIM PRAL148 4474815 IA0037 10590 CAL21100AS 28-0537 A0012 LRA00199 11.201.037 ALTS572 DRA0120 77150410 120300568 120300569 20119001BN 4257063 AAK1104 111180 4275286 2021100 210220 4275285 CA77IR 4275283 4998353 DAN607 CAL21100RS 5510045 4257074 5101645 11.0077M AAG1130 ALT2070 4474816 ALTL150L CAL21100GS AEA1199 3045 11.201.017 30355RIL CAL21100 311289 LRA913 63362003010 4274815 AAG1104 CAL21100OS 437 4224325 63300506010 MG RNL11201037 63300521010 120339528 120339527 CGB-80537 436109 120339515 63300931010 11.0077 ALTL230 4265 63321032 4257771 CGB-10037 A12BH0037A2 11.201.783 2119 8EL012427-661 30355RIM ALTF531 63362006010 63300506 63300901 20104036 63300900 LRA00913 120339516 2091 20130207 63300521 CAL21100ES 4475268 4475266 63362006 CA771IR 63362003 63362004 120300528 PRAF531 120300529 20119001OE 4474729 505.002.033.010 ALT1050 ALTS817 30355RI LRA199 9212983 986030120 30680274 9030120 440224 77145410 PRAL148M 77250410 63362004010 AAG0403 AAG0402 ALT3800 ANM32340X 63300802 63300921 63300920Video/Publications
0120300528 0120300529 0120300558 0120300559 0120300568 0120300569 0120339515 0120339516 0120339527 0120339528 0986030120 10590 11.0077 11.0077M 11.201.017 11.201.037 11.201.783 110899 111180 12029N 20104036 20119001BN 20119001OE 20130207 2021100 2091 210220 2119 28-0537 30355RI 30355RIL 30355RIM 3045 30680274 3077RI 3077RIM 311289 4224325 4257063 4257074 4257771 4265 4274815 4275283 4275285 4275286 4325179 432991 436109 4474729 4474752 4474815 4474816 4475266 4475268 46231680 4998353 505.002.033 5101645 55697 63300506 63300506010 63300521 63300521010 63300802 63300900 63300901 63300920 63300921 63300931 63300931010 63321032 63321032010 63362003 63362003010 63362004 63362004010 63362006 63362006010 77145410 77150410 77250410 8EL012427-661 8EL725944-001 9030120 9212983 A0012 AAG0402 AAG0403 AAG1104 AAG1130 AAK1104 AEA1199 ALT1050 ALT1050A ALT1050R ALT12006 ALT2070 ALT3800 ALTF531 ALTL150L ALTL230 ALTS572 ALTS817 CA77IR CAL21100 CAL21100AS CAL21100ES CAL21100GS CAL21100OS CAL21100RS CGB-10037 CGB-80537 DAN607 DRA0120 EAA-221059 IA0037 LRA00199 LRA00913 LRA199 LRA913 MG 123 MG 437 PRAF531 PRAL148 PRAL148M PRAS572 RNL11201037 SA204 CA771IR 210313Add Your Number
