Associated Numbers
254582D 28100-21060 28100-21061 28100-21062 428000-0024 428000-7830 DRS0296 DSN936 STR70285
DRS0296 DELCO
4280000024 DENSOList
4280007830 DENSO
DSN936 DENSO
254582D KUHNER
2810021060 TOYOTA
2810021061 TOYOTA
2810021062 TOYOTA
STR70285 WOODAUTO
701833
0986025620 Bosch ruil
11040856 EuroTec
114239 Cargo
17842 Lester
17842N WAI
17842R WAI
190598102 PSH
1906139 PIC
23020ND WAI
254232 Elstock
2810021060 Toyota
2810021061 Toyota
2810021062 Toyota
2810021063 Toyota
4280000020 Denso
4280000021 Denso
4280000022 Denso
4280000023 Denso
4280000024 Denso
4280007830 Denso
910296 EDR
91295658 Wilson
A79240 ATL
CS1499 HC
DRS0296 Remy
DSN936 Denso
LRS02560 Lucas
CST40316GS CASCO
DRS0296 DELCO
428000-0024 DENSOList
428000-7830 DENSO
DSN936 DENSO
254582D KUHNER
20432613OE REAL
6040316 SANDO
28100-21060 TOYOTA
28100-21061 TOYOTA
28100-21062 TOYOTA
STR70285 WOODAUTO
4280007831
Denso 4280000020, 4280000021, 4280000022, 4280000023
Substitutes:
J&N 41052274
Bosch SR3285X
Remy Light Duty 17383
Wilson 91295658
References:
Denso 4280000020, 4280000021, 4280000022, 4280000023
Specifications
Kilowatt | 1.6 kW |
Length (L.1) | 182 mm |
Mount Hole Center - Center (O.1) | 122.5 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | 11.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 10 qty |
No./Teeth (Replaces) | 10 qty |
Pinion at Rest (B) | 14 mm |
Rotation | CW |
Spigot Diameter (A) | 74 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Yaris 1.3 16V | (NCP10_)[2NZ-FE] | 11.1999-10.2004 |
TOYOTA | Yaris Verso 1.3 | (NCP22)[2NZ-FE] | 11.1999-09.2005 |
Reference Information
17842N 6E+11 MSN8057 986025620 DS1406 CS1499 428000-7830 20432613OE 428000-0020 STRS313 428000-0022 428000-0021 254582D 428000-0024 428000-0023 DRS0296 428000-0026 428000-0025 63280057010 25-4232 STR70285 6040316.1 190.598.102.050 88214076 DSN936 220927 STR6412 254582 PRSS313 114239 000986025620 28100-21061 J5212104 28100-21062 28100-21060 28100-21063 LRS02560 336482 CST40316GS LRS2560 63280057 190.598.102.260Video/Publications
254582D 28100-21060 28100-21061 28100-21062 428000-0024 428000-7830 DRS0296 DSN936 STR70285 220927Add Your Number
Contact Details
Request More Information
Add your number to the message box below and we will add it to our system
View your shopping basket or Browse other items in Starter Motors.
