Associated Numbers
UD804941(DENSO)A ASPL
AEK3819 AUTOELECTRO
CAL40393GS CASCO
4357 CEVAM
DRA1094 DELCO
1042113020 DENSO
1042113021 DENSO
1042113022 DENSO
1042113090 DENSO
DAN1093 DENSOList
286929 ELSTOCK
209107 ERA
553703RID KUHNER
LRA03819 LUCAS
20132393OE REAL
2040393 SANDO
270600Y130 TOYOTA
270600Y160 TOYOTA
DENDAN1093 WOODAUTO
1042101350 Denso
1042113020 Denso
1042113021 Denso
1042113022 Denso
1042113090 Denso
1042113340 Denso
12061146 EuroTec
195975100 PSH
270600Y130 Toyota
270600Y160 Toyota
2706047260 Toyota
286929 Elstock
931094 EDR
DAN1093 Denso
DRA1094 Remy
J5112198 Nipparts
LRA03819 Lucas
Specifications
Amp | 100 A |
Bottom Mounting Foot Width (B) | 19 mm |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | 11 mm |
Diameter (D.3) | M10x1.25 mm |
Grooves | 4 qty |
Length (L.1) | 162 mm |
Mount Inside Length or Pad Mount C-C (C) | 36.5 mm |
OEM Product | Yes |
Outside Diameter (O.D.1) | 62.5 mm |
Plug Code | PL_1100 |
Product Line | Premium Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 29 mm |
Pulley Type | CLUTCH |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Auris 1.33 | [1NR-FE] | 01.2012- |
TOYOTA | Corolla 1.33 | [1NR-FE] | 01.2013- |
TOYOTA | Verso S 1.33 | [1NR-FE] | 01.2010-12.2015 |
TOYOTA | Yaris 1.33 | [1NR-FE] | 01.2011- |
Reference Information
104211-3022 104211-3021 195.975.100.260 104211-3020 CAL40393GS 209107 ALT2340CP 20132393OE 2706047260 27060-0Y160 27060-47150 AEK3819 DENDAN1093 LRA03819 DAN1093 CGB-86929 195.975.100.050 104211-3090 28-6929 J5112181 DRA1094 27060-47260 27060-0Y130 ALT6458 553703RID 4357 2040393.1 LRA3819 UD804941(DENSO)AVideo/Publications
104211-3020 104211-3021 104211-3022 104211-3090 20132393OE 2040393.1 209107 27060-0Y130 27060-0Y160 28-6929 4357 553703RID AEK3819 ALT2340CP CAL40393GS CGB-86929 DAN1093 DENDAN1093 DRA1094 J5112181 LRA03819 LRA3819 UD804941(DENSO)AAdd Your Number
