Associated Numbers
231.002.113 30051600003 30051600015 30051600041 30051600041A 65.26201-7077 65262017076 65262017076A 65262017077 65262017077B 65262017077D 8214256 8241 S-80294 S9277 STD0013 STR85204 UD12909S
57-091 VXS930
S9277 ASPLList
UD12909S ASPL
8241 CEVAM
S80294 DIXIE
30051600003 DOOSAN
30051600015 DOOSAN
30051600041 DOOSAN
30051600041A DOOSAN
65262017077 DOOSANList
65262017076 DOOSAN
65262017076A DOOSAN
65262017077 DOOSANList
65262017077B DOOSAN
65262017077D DOOSAN
STD0013 KRAUF
8214256 POWERMAX
231002113 PSH
STR85204 WOODAUTO
Arrowhead SMT0447
J&N 41058033
Daewoo 30051600041A
Delco 8200777
Doosan 65262017076, 65262017076A, 65262017076B, 65262017076C, 65262017076D
Arrowhead SMT0447
J&N 41058101
Daewoo 30051600041A
Delco 8200777
Doosan 65262017076, 65262017076A, 65262017076B, 65262017076C, 65262017076D
19080033 Remy
19982 Lester
231004113 PSH
30051600003 Doosan
30051600041 Doosan
65262017076 Daewoo
8200475 Remy
910695N EDR
CST46601GS Casco
QDJ2501 Doosan
STR2717sa Electrolog
TRS161 TWA
017073 Andre Niermann
141479 PIC
231002113 PSH
65262017077 Daewoo
65262017078 Daewoo
DRS0286 Remy
TRS065 TWA
19080026 Remy
231001113 PSH
30051600056 Doosan
30051600056A Doosan
30051600056B Doosan
30051600056C Doosan
5000661 Daewoo
500661 Daewoo
65262017073 Daewoo
65262017073C Daewoo
STR2123sa Electrolog
TRS192 TWA
Specifications
| Kilowatt | 4.5 kW |
| Length (L.1) | 289 mm |
| Mount Hole Center - Center (O.1) | 136 mm |
| Mount Hole Center - Center (O.2) | 112 mm |
| Mount Hole Center - Center (O.3) | 112 mm |
| Mount Hole Diameter (C.1) | 13.5 mm |
| Mount Hole Diameter (C.2) | 13.5 mm |
| Mount Hole Diameter (C.3) | 13.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| Pinion at Rest (B) | 48 mm |
| Rotation | CW |
| Spigot Diameter (A) | 105 mm |
| Unit Type | DOOSAN |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| DOOSAN | Kraan |
Reference Information
S-80294 S9277 STR85204 65262017077D 65262017076A 65262017077B UD12909S 65.26201-7077 8214256 8241 65262017077 65262017076 30051600015 STD0013 30051600003 30051600041A STRL762 231.002.113 30051600041Video/Publications
231.002.113 30051600003 30051600015 30051600041 30051600041A 65.26201-7077 65262017076 65262017076A 65262017077 65262017077B 65262017077D 8214256 8241 S-80294 S9277 STD0013 STR85204 STRL762 UD12909S< Critical Notes >
Pinion at rest measurement is 48mm
