Associated Numbers
0001418016 101122 6614040 STB1122 STR50358 UD16659S UNIT BOM 120-6227
UD16659S AS-PL
0001418016 BOSCHList
6614040 CLAAS
STB1122 KRAUF
STR50358 KRAUF
101122 KUHNER
UNIT BOM 120-6227 WAI / TRANSPO
111792
Specifications
Kilowatt | 3.6 kW |
Length (L.1) | 386.5 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 127 mm |
Mount Hole Center - Center (O.3) | 90 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Oil Sealed | Yes |
Pinion at Rest (B) | 48 mm |
Rotation | ACW |
Spigot Diameter (A) | 89 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
VOLVO PENTA | Various Models |
Reference Information
1418016 STR50358 BOM 120-6227 UNIT STB1122 UD16659S 101122 0001418016 6614040 STRF097 STR10152Video/Publications
0001418016 101122 6614040 STB1122 STR50358 STRF097 UD16659S UNIT BOM 120-6227Add Your Number
