Associated Numbers
2706031130 2706031131 2706031132 104210-2081 1042102081 27060-31091 2706031092 27060-31092
1042105000 1042105001
UD11464A ASPL
12821 DELCO
1042102080 DENSOList
1042104740 DENSOList
9664219208 DENSO
A80353 DIXIE
ALN0073 KRAUF
554084RI KUHNER
2706031090 TOYOTAList
2706031091 TOYOTAList
270603109184 TOYOTA
11322R WAI / TRANSPO
90295635 WILSON
1042104740 Denso
11322 Lester
11322N WAI
195317100 PSH
2706031090 Toyota
2706031091 Toyota
270603109184 Toyota
dxa597
104210-2080 104210-4740 11322R 12821 27060-31090 27060-31091 27060-31091-84 554084RI 90-29-5635 9664219-208 A-80353 ALN0073 UD11464A
Specifications
| Amp | 100 A |
| Diameter (D.1) | 11 mm |
| Diameter (D.2) | 11 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M10x1.25 mm |
| Grooves | 7 qty |
| Length (L.1) | 167 mm |
| Outside Diameter (O.D.1) | 52.5 mm |
| Pivot Foot Length (B) | 20 mm |
| Pivot Inside Length (C) | 36 mm |
| Plug Code | PL_4002 |
| Pulley Type | CLUTCH |
| Pulley to Mount Distance (A) | 35 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | RAV4 3.5 V6 | [2GR-FE] | 01.2006-12.2012 |
Alternatives >>>
A6522S - Brand new 150 amp version
A6277R - Remanufactured 130 amp Option
Reference Information
27060-31090 90-29-5635 27060-31091 27060-31091-84 A-80353 104210-4740 UD11464A 554084RI 9664219-208 11322R ALN0073 12821 104210-2080Video/Publications
104210-2080 104210-4740 11322R 12821 27060-31090 27060-31091 27060-31091-84 554084RI 90-29-5635 9664219-208 A-80353 ALN0073 UD11464AAdd Your Number
