Associated Numbers
UD15195A ASPL
AEK3893 AUTOELECTRO
0986083340 BOSCH
F000BL08F1 BOSCHList
F000BL08F2 BOSCHList
F000BL08P3 BOSCH
F000BL08P4 BOSCH
116193 CARGO
CAL10553 CASCO
CAL10553AS CASCO
CAL10553ES CASCO
CAL10553GS CASCO
CAL10553OS CASCO
CAL10553RS CASCO
CAL15594 CASCO
CAL15594AS CASCO
CAL15594ES CASCO
CAL15594GS CASCO
CAL15594OS CASCO
CAL15594RS CASCO
DA2456 DELCO
DRA1346 DELCO
EAA224492 EAA
57411 EAI
287503 ELSTOCK
ALV3823 KRAUF
554055RIB KUHNER
554055RIV KUHNER
LRA03893 LUCAS
89215862 POWERMAX
305.923.140 PSH
20179495 REAL
2010553 SANDO
2015594 SANDO
TG14C071 VALEOList
TG14C083 VALEO
TG14C103 VALEOList
04C903023K VW
04C903023KX VW
04C903023L VW
04C903023LX VW
04C903023M VW
04C903023MX VW
04C903023T VW
04C903023TX VW
ALT14538 WOODAUTO
BOSF000BL08F2 WOODAUTO
VAL439894 WOODAUTO
04C903023K VW
04C903023M VW
0986083340 Bosch ruil
12090519 EuroTec
2622499A Valeo
2715992A Valeo
287503 Elstock
305923140 PSH
440640 Valeo
57411 EAI
715992 Valeo
8EL011712881 Hella
9090827F Friesen
931346 EDR
DRA1346 Remy
LRA03893 Lucas
TG14C071 Valeo
TG14C083 Valeo
TG14C103 Valeo
04C903023L VW
0986083790 Bosch ruil
20352N WAI
20352NOE WAI
305541140 PSH
ALT1147sa Electrolog
CAL15594GS Casco
F000BL08F1 Bosch
F000BL08F2 Bosch
F000BL08F2OR +line
F000BL08F4 Bosch
F000BL08P3 Bosch
F000BL08P4 Bosch
439821 6525051
Specifications
| Amp | 140 A |
| Bottom Mounting Foot Width (B) | 13.5 mm |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | 8.5 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M8x1.25 mm |
| Grooves | 6 qty |
| Length (L.1) | 204 mm |
| Mount Inside Length or Pad Mount C-C (C) | 61 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 52 mm |
| Plug Code | PL_2306 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 30 mm |
| Pulley Type | CLUTCH |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A1 1.0 TFSi | [CHZB] | 01.2015- |
| AUDI | A1 1.0 TFSi | [CHZE] | 01.2015- |
| AUDI | A1 1.4 TFSi | [CZCA] | 01.2014- |
| AUDI | A1 1.4 TFSi | [CZDB] | 01.2014- |
| AUDI | A1 1.4 TFSi | [CZEA] | 01.2014- |
| AUDI | A3 1.2 TFSi | [CYVB] | 01.2014- |
| AUDI | A3 1.4 TFSi | [CPTA] | 01.2013- |
| AUDI | A3 1.4 TFSi | [CPWA] | 01.2013- |
| AUDI | A3 1.4 TFSi | [CXSB] | 01.2013- |
| AUDI | A3 1.4 TFSi | [CZCA] | 01.2013- |
| AUDI | A3 1.4 TFSi | [CZEA] | 01.2013- |
| AUDI | Q2 1.0 TFSi | [CHZJ] | 01.2016- |
| AUDI | Q2 1.4 TFSi | [CZEA] | 01.2016- |
| AUDI | Q2 1.4 TFSi Quattro | [CZEA] | 01.2016- |
| AUDI | Q3 1.4 TFSi | [CZDA] | 01.2013- |
| AUDI | Q3 1.4 TFSi | [CZEA] | 01.2013- |
| SEAT | Alhambra 1.4 TSi | [CZDA] | 01.2015- |
| SEAT | Ateca 1.0 TSi | [CHZJ] | 01.2016- |
| SEAT | Ateca 1.4 TSi | [CZEA] | 01.2016- |
| SEAT | Ateca 1.4 TSi 4Drive | [CZEA] | 01.2016- |
| SEAT | Ibiza 1.2 TSi | [CJZC] | 01.2015-12.2016 |
| SEAT | Ibiza 1.2 TSi | [CJZD] | 01.2015-12.2016 |
| SEAT | Ibiza 1.4 TSi | [CPTA] | 01.2013- |
| SEAT | Leon 1.0 TSi | [CHZD] | 01.2015- |
| SEAT | Leon 1.4 TGi | [CPWA] | 01.2013- |
| SEAT | Leon 1.4 TSi | [C..A] | 01.2013- |
| SEAT | Toledo 1.2 TSi | [CJZC] | 01.2015- |
| SEAT | Toledo 1.2 TSi | [CJZD] | 01.2015- |
| SEAT | Toledo 1.4 TSi | [CZCA] | 01.2015- |
| SKODA | Fabia 1.2 TSi | [CJZC] | 01.2014- |
| SKODA | Fabia 1.2 TSi | [CJZD] | 01.2014- |
| SKODA | Superb 1.4 TSi | [CZCA] | 01.2015- |
| SKODA | Superb 1.4 TSi | [CZDA] | 01.2015- |
| SKODA | Superb 1.4 TSi | [CZEA] | 01.2015- |
| SKODA | Superb 1.4 TSi 4x4 | [CZDA] | 01.2015- |
| SKODA | Superb 1.4 TSi 4x4 | [CZEA] | 01.2015- |
| SKODA | Yeti 1.4 TSi | [CZCA] | 01.2015- |
| VW | Caddy 1.4 TGi CNG | [CPWA] | 01.2015-12.2016 |
| VW | CC 1.4 TSi | [CZDA] | 01.2015- |
| VW | Golf Sportsvan 1.2 TSi | [CYVA] | 01.2014- |
| VW | Golf Sportsvan 1.2 TSi | [CYVB] | 01.2014- |
| VW | Golf Sportsvan 1.4 TSi | [CPVB] | 01.2014- |
| VW | Golf Sportsvan 1.4 TSi | [CZCA] | 01.2014- |
| VW | Golf Sportsvan 1.4 TSi | [CZDA] | 01.2014- |
| VW | Golf VI 1.4 TSi | [CZCA] | 01.2013- |
| VW | Golf VII 1.0 TSi | [CHZD] | 01.2015- |
| VW | Golf VII 1.2 TSi | [CJZA] | 01.2013- |
| VW | Golf VII 1.2 TSi | [CJZB] | 01.2013- |
| VW | Golf VII 1.2 TSi | [CYVA] | 01.2013- |
| VW | Golf VII 1.2 TSi | [CYVB] | 01.2013- |
| VW | Golf VII 1.4 TGI | [CPWA] | 01.2013- |
| VW | Golf VII 1.4 TGI | [CZBA] | 01.2013- |
| VW | Golf VII 1.4 TSi | [CHP.] | 01.2013- |
| VW | Golf VII 1.4 TSi | [CPTA] | 01.2013- |
| VW | Golf VII 1.4 TSi | [CPV.] | 01.2013- |
| VW | Golf VII 1.4 TSi | [CZ.A] | 01.2013- |
| VW | Jetta 1.4 TSi | [CZCA] | 01.2014-12.2016 |
| VW | Passat 1.4 TSi | [CZCA] | 01.2014- |
| VW | Passat 1.4 TSi | [CZDA] | 01.2014- |
| VW | Passat 1.4 TSi | [CZEA] | 01.2014- |
| VW | Passat 1.4 TSi 4-Motion | [CZEA] | 01.2015- |
| VW | Polo 1.0 TSi | [CHZB] | 01.2014- |
| VW | Polo 1.0 TSi | [CHZC] | 01.2014- |
| VW | Polo 1.2 TSi | [CJZC] | 01.2014- |
| VW | Polo 1.2 TSi | [CJZD] | 01.2014- |
| VW | Polo 1.4 TSi | [CZEA] | 01.2014- |
| VW | Scirocco 1.4 TSi | [CZCA] | 01.2015- |
| VW | Scirocco 1.4 TSi | [CZDA] | 01.2015- |
| VW | Scirocco 1.4 TSi | [CZDC] | 01.2015- |
| VW | Sharan 1.4 TSi | [CZDA] | 01.2015- |
| VW | Tiguan 1.4 TSi | [CZDA] | 01.2015- |
| VW | Tiguan 1.4 TSi | [CZDB] | 01.2015- |
Reference Information
0F000BL08P4 4C903023MX 4E903015B CAL15594GS F000BL08J4 F000BL08J3 A12BH0097 0F000BL08P3 04C903023KX RAA12457 2015594.1 440640 4C903023TX ALT2383CP L04C903023K L04C903023L 4C903023LX L04C903023M A12VA0097 89215862 04C903023TX 305.923.140.000 0F000BL08J3 0F000BL08J4 2622499A A12BH0097AS 04E903024S 04E903015TX 20351N 015 4C903023KX 2711899A 116193 4E903015Q 4C903023K 4E903015T 4C903023L 4C903023M 4C903023T 04E903023J EAA-224492 0986083340 TG14C083 20179495OE ALT175940 28-7503 VAL439894 F000BL08F1 F000BL08F2 04E903015BX 209492 04C903021A TG14C103-N 630-201 TG14C094 40259 554055RIV 986083340 ALTE204 209262 PRAE204 0F000BL08F1 4E903024S 04C903023LX 2715267A ALT14538 LRA3893 ALT0405 04C903023T UD15195A 0F000BL08F2 F000BL08P4 4E903015BX 04E903024SX 554055RIB DA2456 DRA1346 04C903023MX 4C903021A CGB-87503 439894 8EL 04E903015B 441952 LRA03893 TG14C071 F000BL08P3 04E903015PX 04C903021AX 305.923.140.501 TG14C103 04C903023M 04C903023L 04E903015Q 04E903015T 305.923.140.502 04E903015P 04C903023KVideo/Publications
CGB-87503 PRAE204 ALTE204 UD15195A 0986083340 116193 CAL15594GS 40259 DA2456 DRA1346 RAA12457 EAA-224492 28-7503 209492 TG14C103-N 8EL 015 630-201 554055RIB 554055RIV LRA03893 LRA3893 89215862 305.923.140.000 305.923.140.501 305.923.140.502 2015594.1 20179495OE ALT2383CP ALT175940 439894 440640 TG14C071 20351N ALT14538 VAL439894 TG14C083 TG14C094 F000BL08F1 F000BL08F2 F000BL08J3 F000BL08J4 F000BL08P3 F000BL08P4 04C903021A 04C903021AX 04C903023K 04C903023KX 04C903023L 04C903023LX 04C903023M 04C903023MX 04C903023T 04C903023TX 04E903024S 04E903024SX 2622499A 2711899A 2715267A 209262Add Your Number
