Associated Numbers
A6404S ASPLList
UD13825A ASPLList
12317616119 BMW
12317616121 BMW
7616119 BMW
7616121 BMW
CAL40461 CASCO
1042106500 DENSOList
1042106501 DENSOList
1042106502 DENSOList
1042106503 DENSOList
1042106504 DENSOList
DAN1135 DENSO
A80621 DIXIE
209453 ERA
ALN1135 KRAUF
215.598.210 PSH
2040461 SANDO
90295851 WILSON
DENDAN1135 WOODAUTO
1042106500 Denso
1042106501 Denso
1042106502 Denso
1042106503 Denso
1042106504 Denso
12090759 EuroTec
12317616119 BMW
12317616121 BMW
215598210 PSH
7616119 BMW
7616121 BMW
DAN1135 Denso
BMW 12317616119, 12317616121, 761611901, 761611902
Delco AR135057
Denso 1042106500, 1042106501, 1042106502, 1042106503, 1042106504
Lester 11712
PIC Picture ID 2205798, 2906015
Wilson 90295851
40052687R
1042106570 1042106571 1042106573 1042106574 1042106572
Specifications
| Amp | 210 A |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | 10.5 mm |
| Diameter (D.3) | 8.5 mm |
| Diameter (D.4) | 10.5 mm |
| Grooves | 8 qty |
| Length (L.1) | 184 mm |
| Mount Inside Length or Pad Mount C-C (C) | 40 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 49 mm |
| Pad mount thickness (E.1) | 63 mm |
| Pad mount thickness (E.2) | 63 mm |
| Pad mount thickness (E.3) | 63 mm |
| Pad mount thickness (E.4) | 63 mm |
| Plug Code | PL_2306 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 29 mm |
| Pulley Type | SOLID |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| BMW | 335 3.0 i | (F31)[N55B30A] | 07.2012-06.2015 |
| BMW | 335 3.0 i | (F34)[N55B30A] | 03.2013- |
| BMW | 335 3.0 i xDrive | (F30)[N55B30A] | 05.2011-07.2015 |
| BMW | 335 3.0 i xDrive | (F80)[N55B30A] | 05.2011-07.2015 |
| BMW | 355 3.0 i xDrive | (F34)[N55B30A] | 03.2013- |
| BMW | 435 3.0 i | (F32)[N55B30A] | 07.2013- |
| BMW | 435 3.0 i | (F33)[N55B30A] | 10.2013- |
| BMW | 435 3.0 i | [F82}[N55B30A] | 07.2013- |
| BMW | 435 3.0 i | (F83)[N55B30A] | 10.2013- |
| BMW | 435 3.0 i xDrive | (F32)[N55B30A] | 07.2013- |
| BMW | 435 3.0 i xDrive | (F33)[N55B30A] | 07.2014- |
| BMW | 435 3.0 i xDrive | (F82)[N55B30A] | 07.2013- |
| BMW | 435 3.0 i xDrive | (F83)[N55B30A] | 07.2014- |
| BMW | 535 3.0 i | (F07)[N55B30A] | 01.2009- |
| BMW | 535 3.0 i | (F10)[N55B30A] | 01.2009-10.2016 |
| BMW | 535 3.0 i | (F11)[N55B30A] | 11.2009- |
| BMW | 535 3.0 i xDrive | (F07)[N55B30A] | 01.2010- |
| BMW | 535 3.0 i xDrive | (F10)[N55B30A] | 03.2010-10.2016 |
| BMW | 535 3.0 i xDrive | (F11)[N55B30A] | 07.2010- |
| BMW | 640 3.0 i | (F06)[N55B30A] | 09.2011- |
| BMW | 640 3.0 i | (F12)[N55B30A] | 03.2011- |
| BMW | 640 3.0 i | (F13)[N55B30A] | 11.2010- |
| BMW | 640 3.0 i xDrive | (F06)[N55B30A] | 01.2013- |
| BMW | 640 3.0 i xDrive | (F12)[N55B30A] | 01.2013- |
| BMW | 640 3.0 i xDrive | (F13)[N55B30A] | 01.2013- |
| BMW | 740 3.0 i | (F01)[N55B30A] | 07.2012-12.2015 |
| BMW | 740 3.0 i | (F02)[N55B30A] | 07.2012-12.2015 |
| BMW | 740 3.0 i | (F03)[N55B30A] | 07.2012-12.2015 |
| BMW | 740 3.0 i | (F04)[N55B30A] | 07.2012-12.2015 |
| BMW | 740 3.0 Li | (F01)[N55B30A] | 07.2012-12.2015 |
| BMW | 740 3.0 Li | (F02)[N55B30A] | 07.2012-12.2015 |
| BMW | 740 3.0 Li | (F03)[N55B30A] | 07.2012-12.2015 |
| BMW | 740 3.0 Li | (F04)[N55B30A] | 07.2012-12.2015 |
| BMW | M 135 3.0 i | (F20)[N55B30A] | 11.2011- |
| BMW | M 135 3.0 i | (F21)[N55B30A] | 12.2011- |
| BMW | M 135 3.0 i xDrive | (F20)[N55B30A] | 02.2012- |
| BMW | M 135 3.0 i xDrive | (F21)[N55B30A] | 02.2012- |
| BMW | M 235 3.0 i | (F22)[N55B30A] | 10.2013- |
| BMW | M 235 3.0 i | (F87)[N55B30A] | 10.2013- |
| BMW | M 235 3.0 i xDrive | (F22)[N55B30A] | 07.2014- |
| BMW | M 235 3.0 i xDrive | (F87)[N55B30A] | 07.2014- |
| BMW | M 335 3.0 i | (F30)[N55B30A] | 04.2011-07.2015 |
| BMW | M 335 3.0 i | (F80)[N55B30A] | 04.2011-07.2015 |
| BMW | X3 3.0 xDrive 35 i | (F25)[N55B30A] | 09.2010- |
| BMW | X4 3.0 xDrive 35 i | (F26)[N55B30A] | 06.2013- |
| BMW | X5 3.0 xDrive 35 i | (E70)[N55B30A] | 02.2012-06.2013 |
| BMW | X5 3.0 xDrive 35 i | (E70)[N55B30A] | 09.2010-06.2013 |
| BMW | X5 3.0 xDrive 35 i | (F15)[N55B30A] | 11.2013- |
| BMW | X5 3.0 xDrive 35 i | (F85)[N55B30A] | 11.2013- |
| BMW | X6 3.0 xDrive 35 i | (E71)[N54B30A] | 06.2007-03.2010 |
| BMW | X6 3.0 xDrive 35 i | (E71)[N55B30A] | 06.2007-03.2010 |
| BMW | X6 3.0 xDrive 35 i | (E72)[N54B30A] | 06.2007-03.2010 |
| BMW | X6 3.0 xDrive 35 i | (E72)[N55B30A] | 06.2007-03.2010 |
Reference Information
ALN1135 CAL40461 7616121 DAN1135 LRA4162 104210-6502 104210-6503 104210-6500 104210-6501 A6404S 443275 104210-6504 LRA04162 ALT6728 12317616121 CAL40461RS A-80621 90-29-5851 ALTE952 554480RID DENDAN1135 CAL40461AS CAL40461GS 209453 2040461 12090759 UD13825A CAL40461ES 215.598.210 12317616119 32118809 28-7771 7616119 CAL40461OSVideo/Publications
104210-6500 104210-6501 104210-6502 104210-6503 104210-6504 12090759 12317616119 12317616121 2040461 209453 215.598.210 28-7771 32118809 554480RID 90-29-5851 A-80621 A6404S ALN1135 ALTE952 CAL40461 CAL40461AS CAL40461ES CAL40461GS CAL40461OS CAL40461RS DAN1135 DENDAN1135 LRA04162 LRA4162 UD13825AAdd Your Number
