Associated Numbers
AEA3268 AUTOELECTRO
CAL30195GS CASCO
EAA221406 EAA
285695 ELSTOCK
54022470 LUCAS
LRA03083 LUCAS
63340005 MAGNETI MARELLIList
20104591OE REAL
YLE10100 ROVER
YLE10100E ROVER
2030195 SANDO
13697N WAI / TRANSPO
ALT12029 WOODAUTO
Magneti Marelli MAN675
Wilson 90192510
References:
Arrowhead ALU0005
Beck Arnley 1861073
Bosch AL9346X
Lester 13697
Lucas A2529, LRA03083, LRB00368
Magneti Marelli 54022470, 63340005, MAN675
PIC Picture ID 202121
Remy Light Duty 14362
Rover AMR1271, YLE10100
Wilson 90192510
&N 40041000
Lucas A2529
Magneti Marelli MAR675
References:
J&N 40041000
Bosch AL9346X
Delco 3341821, 3342047, DRA3678
Lester 13697
Lucas 54022470, A2529
Magneti Marelli 63322470, 63340005, MAR675
PIC Picture ID 202121
Rover YLE10100, YLE10100E, YLE10124
&N 40041000
Bosch AL9346X
Magneti Marelli MAN675
Wilson 90192510
References:
Magneti Marelli 63321243
Wilson 90192510
Arrowhead ALU0005
J&N 40041000
Delco DRA3678
Lucas 54022470, A2528, A2529, LRB368
Magneti Marelli 063340005010, 54022470, 63320314, 63340005, MAR675
ANM025 LXA834 LXA835
Specifications
| Amp | 100 A |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 8.5 mm |
| Diameter (D.3) | 8.5 mm |
| Grooves | 4 qty |
| Length (L.1) | 176 mm |
| Outside Diameter (O.D.1) | 60 mm |
| Pivot Foot Length (B) | 13 mm |
| Pivot Inside Length (C) | 83.5 mm |
| Plug Code | PL_9105 |
| Pulley Type | SOLID |
| Pulley to Mount Distance (A) | 31.5 mm |
| Unit Type | MAGNETI MARELLI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| LAND ROVER | Range Rover 3.9 V8 | 01.1991-12.1996 |
Alternatives >>>
A4100 - Connections in a different position. Plus only has 3 mounts
Reference Information
LRA3083 LRA03083 63340005 ALTW259 13697N YLE10100 ALT12029 EAA-221406 28-5695 54022470 301085RIM YLE10100EVideo/Publications
13697N 20104591OE 2030195 28-5695 301085RIM 54022470 63340005 AEA3268 ALT12029 ALTW259 CAL30195GS EAA-221406 LRA03083 LRA3083 YLE10100 YLE10100EAdd Your Number
