Associated Numbers
130-80103 18971N 943214941010 M008T55071 M008T55073 M8T55071 M8T55073 ME015766 ME215097 MSRC1494 STM0102 STR71256 UD14923S
UD14923S ASPL
STM0102 KRAUF
943214941010 MAGNETI MARELLI
MSRC1494 MAGNETI MARELLI
M008T55071 MITSUBISHIList
M008T55073 MITSUBISHIList
M8T55071 MITSUBISHIList
M8T55073 MITSUBISHIList
ME015766 MITSUBISHIList
ME215097 MITSUBISHIList
13080103 ROBERT'S
18971N WAI / TRANSPO
STR71256 WOODAUTO
S5195 ASPLList
UD11149S ASPL
STM0102 KRAUF
943214941010 MAGNETI MARELLI
MSRC1494 MAGNETI MARELLI
M008T55071 MITSUBISHIList
M008T55073 MITSUBISHIList
M8T55071 MITSUBISHIList
M8T55073 MITSUBISHIList
ME015766 MITSUBISHIList
ME215097 MITSUBISHIList
13080103 ROBERT'S
18971N WAI / TRANSPO
18971R WAI / TRANSPO
STR71256 WOODAUTO
103457 PIC
150934113 PSH
18971N WAI
23176MI WAI
A11555 ATL
CST35276AS Casco
CST35276GS Casco
M003T67281 Mitsubishi
M003T67282 Mitsubishi
M003T67283 Mitsubishi
M008T55073 Mitsubishi
M3T67281 Mitsubishi
M3T67282 Mitsubishi
M3T67283 Mitsubishi
M8T55073 Mitsubishi
M900514 DuBois
ME015112 Mitsubishi
ME015766 Mitsubishi
ME017094 Mitsubishi
ME215097 Mitsubishi
mxs9613 706600hd snj512
Specifications
| Kilowatt | 3.6 kW |
| Length (L.1) | 287 mm |
| Mount Hole Center - Center (O.1) | 145 mm |
| Mount Hole Center - Center (O.2) | 45 mm |
| Mount Hole Center - Center (O.3) | 65 mm |
| Mount Hole Center - Center (O.4) | 79 mm |
| Mount Hole Diameter (C.1) | 13.5 mm |
| Mount Hole Diameter (C.2) | 13.5 mm |
| Mount Hole Diameter (C.3) | M10x1.25 mm |
| Mount Hole Diameter (C.4) | M10x1.25 mm |
| No./Mount holes | 4 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 17 mm |
| Rotation | CW |
| Spigot Diameter (A) | 60 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MITSUBISHI | Fuso 3.9 | [4D34] | 05.1999- |
| MITSUBISHI | Fuso 4.2 | [4D33] | 05.1999- |
| MITSUBISHI | Fuso Canter FE 3.9 Diesel | 01.1999- | |
| MITSUBISHI | Fuso Canter FG 3.9 Diesel | [4D34-2AT] | 01.1999-01.2004 |
| MITSUBISHI | Fuso FE Series 3.9 Diesel 238 | [4D34-2AT] | 01.1999- |
| MITSUBISHI | Fuso FE Series 3.9 Diesel 238 | [4D34-3AT] | 01.1999- |
| MITSUBISHI | Fuso FG Series 3.9 Diesel 238 | 01.1999- |
Reference Information
STM0102 MSRC1494 ME015766 9.43215E+11 130-80103 UD14923S 18971N STR71256 M8T55073 M8T55071 ME215097 M008T55073 M008T55071Video/Publications
130-80103 18971N 943214941010 M008T55071 M008T55073 M8T55071 M8T55073 ME015766 ME215097 MSRC1494 STM0102 STR71256 UD14923SAdd Your Number
