- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0001260025Associated Numbers
0001260025 0001260026 11.130.836 11.131.542 11.131.727 113570 20419711OE 25-4033 254856 254856M 35259360 6021117 8103 83646500 836673290 836866817 836873290 87751000 AZF4141 AZF4190 AZF4261 AZF4513 CST21117GS DRS0569 IS0836 LRS023610001260025 BOSCHList
0001260026 BOSCHList
113570 CARGO
CST21117GS CASCO
8103 CEVAM
DRS0569 DELCO
254033 ELSTOCK
11.130.836 ISKRA / LETRIKAList
11.131.542 ISKRA / LETRIKAList
11.131.727 ISKRA / LETRIKAList
AZF4141 ISKRA / LETRIKAList
AZF4190 ISKRA / LETRIKAList
AZF4261 ISKRA / LETRIKA
AZF4513 ISKRA / LETRIKAList
IS0836 ISKRA / LETRIKAList
LRS02361 LUCAS
87751000 NEW HOLLAND
35259360 PRESTOLITEList
20419711OE REAL
6021117 SANDO
836866817 SISU
83646500 VALMET
836673290 VALMET
836873290 VALMET
569018D1 AGCO
836673290 AGCO
836866817 AGCO
836873088 AGCO
836873457 AGCO
V836866817 AGCO
V836873457 AGCO
S9227 ASPLList
UD02663S ASPL
113570 CARGO
CST21117 CASCO
47111575 CASEList
84284540 CASEList
8103 CEVAM
DRS0569 DELCO
26026102 DIXIE
EAA112193 EAA
254033 ELSTOCK
162000090722 FIAT
87751000 FIAT
11.130.836 ISKRA / LETRIKAList
11.131.542 ISKRA / LETRIKAList
11.131.727 ISKRA / LETRIKAList
11.131.968 ISKRA / LETRIKA
11.132.174 ISKRA / LETRIKAList
11.132.356 ISKRA / LETRIKAList
11.132.359 ISKRA / LETRIKAList
AZF4141 ISKRA / LETRIKAList
AZF4190 ISKRA / LETRIKAList
AZF4261 ISKRA / LETRIKA
AZF4320 ISKRA / LETRIKAList
AZF4369 ISKRA / LETRIKAList
AZF4370 ISKRA / LETRIKAList
AZF4513 ISKRA / LETRIKAList
IS0836 ISKRA / LETRIKAList
STI3570 KRAUF
LRS02361 LUCAS
MS175 MAHLEList
MS591 MAHLEList
87693781 NEW HOLLANDList
35259360 PRESTOLITEList
6021117 SANDO
83646500 VALMET
89732200 VALMET
VPF7263 VALMET
LETIS0836 WOODAUTO
Bosch 0001260026
References:
Arrowhead SBO0324
AGCO 89732200
Bosch 0001260025, 0001260026
Case 84284540
Bosch 0001260025
Substitutes:
J&N 41024239
MAHLE MS175
References:
Arrowhead SBO0324
J&N 41024239
Bosch 0001260025
Case 84284540
702601
0001260025 Bosch
0001260026 Bosch
11090215 EuroTec
11130836 Mahle
11131727 Mahle
11131968 Mahle
19992N WAI
254033 Elstock
800008113 PSH
836866817 Valtra
AZF4141 Mahle
AZF4190 Mahle
AZF4513 Mahle
DRS0569 Remy
IS0836 Mahle
LRS02361 Lucas
MS175 Mahle
11013690 EuroTec
11130710 Mahle
11130897 Mahle
11131249 Mahle
252141 Elstock
27512E Lucas
33836662073 VALMET(Sisu)
800004113 PSH
AZJ3247 Mahle
AZJ3319 Mahle
AZJ3405 Mahle
IS0897 Mahle
MS91 Mahle
SNL017GQ
Specifications
| Kilowatt | 4.20 kW |
| Length (L.1) | 326 mm |
| Mount Hole Center - Center (O.1) | 90 mm |
| Mount Hole Center - Center (O.2) | 127 mm |
| Mount Hole Center - Center (O.3) | 90 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| No./Teeth (Replaces) | 11 qty |
| OEM Product | No |
| Pinion at Rest (B) | 48 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AGCO | 520C | - | |
| AGCO | 540C | - | |
| AGCO | 670B | - | |
| AGCO | 670B EEA | - | |
| AGCO | A76 | 01.2008- | |
| AGCO | Engine | 44CTA | - |
| AGCO | Engine 4.9 | CWA | - |
| AGCO | Engine 8.4 | 84CTA | - |
| AGCO | MT745D 8.4 | - | |
| AGCO | MT755D 8.4 | - | |
| AGCO | MT765D 8.4 | - | |
| AGCO | MT775E 9.8 | - | |
| AGCO | R66 | 01.2008- | |
| AGCO | R76 | 01.2008- | |
| AGCO | S67 | 01.2010- | |
| AGCO | S68 | 01.2014- | |
| AGCO | S77 | 01.2010- | |
| AGCO | S78 | 01.2014- | |
| AGCO | S88 | 01.2014- | |
| CASE IH | CS 105 PRO 4.4 | 01.2008- | |
| CASE IH | CS 110 4.4 | 01.2004- | |
| CASE IH | CS 120 | 01.2004- | |
| CASE IH | CS 130 6.6 | 620.92 | 01.1997-12.2003 |
| CASE IH | CS 150 | 01.2004- | |
| CASE IH | CS 78 4.4 | 420.81 | 01.1998-12.2003 |
| CASE IH | CS 80 PRO | 10.2007- | |
| CASE IH | CS 85 PRO 4.4 | 01.2008- | |
| CASE IH | CS 86 | 01.1999-01.2004 | |
| CASE IH | CS 94 | 420.83 | 01.1998-12.2004 |
| CASE IH | CS 95 PRO | 01.2008- | |
| CASE IH | CVX 1135 | 01.2003-01.0001 | |
| CASE IH | CVX 1145 | 01.2003-01.0001 | |
| CASE IH | CVX 1155 | 01.2003-01.0001 | |
| CASE IH | CVX 1170 | 01.2003-01.0001 | |
| CASE IH | CVX 1190 | 01.2003-01.0001 | |
| CASE IH | CVX 1195 | 01.2003- | |
| CASE IH | CVX 120 | 01.2000-05.2003 | |
| CASE IH | CVX 130 | 07.2000-05.2003 | |
| CASE IH | CVX 140 6.6 | 620.60 | 01.2007-12.2009 |
| CASE IH | CVX 150 6.6 | 01.2000-05.2003 | |
| CASE IH | CVX 160 6.6 | 620.62 | 01.2007-12.2009 |
| CASE IH | CVX 170 6.6 | 620.90 | 01.2000-12.2003 |
| CASE IH | CVX 175 | 07.2007- | |
| CASE IH | CVX 190 6.6 | 01.2007- | |
| CASE IH | CVX 195 | 01.2007- | |
| CHALLENGER | 652C 8.4 | CTA | - |
| CHALLENGER | 660B 8.4 | CTA | - |
| CHALLENGER | 670B 8.4 | CTA | - |
| CHALLENGER | 672C 7.4 | - | |
| CHALLENGER | 8333 8.4 | CTA | - |
| CHALLENGER | MT665D 8.4 | - | |
| CHALLENGER | MT685D 8.4 | - | |
| CHALLENGER | MT745D 8.4 | CTA | - |
| CHALLENGER | MT755D 8.4 | CTA | - |
| CHALLENGER | MT765D 8.4 | CTA | - |
| CHALLENGER | RG1100 8.4 | - | |
| CHALLENGER | RG1300 8.4 | - | |
| CHALLENGER | RG635B 4.9 | - | |
| CHALLENGER | RG645B 7.4 | - | |
| CHALLENGER | RG655B 7.4 | - | |
| CHALLENGER | TG845 8.4 | CTA | - |
| CHALLENGER | WR9740 4.9 | - | |
| CRYSTAL TRACTOR | Orion 16 | - | |
| FENDT | Vario 310 | 10.2012- | |
| FENDT | Vario 310 | 10.2012- | |
| FENDT | Vario 311 | 10.2012- | |
| FENDT | Vario 311 | 10.2012- | |
| FENDT | Vario 312 | 10.2012- | |
| FENDT | Vario 312 | 10.2012- | |
| FENDT | Vario 313 | 09.2010- | |
| HESSTON | WR9735 4.9 | CTAT4F | - |
| HESSTON | WR9740 4.9 | CTAT4F | - |
| HESSTON | WR9760 4.9 | CTAT4F | - |
| HESSTON | WR9770 6.6 | CTAT4F | - |
| HESSTON | WR9860 4.9 | CTAT4F | - |
| HESSTON | WR9870 6.6 | CTAT4F | - |
| JCB | FASTTRAC 2155 | 01.2010- | |
| JCB | FASTTRAC 2170 | 01.2010- | |
| JCB | FASTTRAC 3200 | 01.2010- | |
| JCB | FASTTRAC 3230 | 01.2010- | |
| JCB | FASTTRAC 8280 | 01.2010- | |
| JCB | FASTTRAC 8310 | 01.2010- | |
| MASSEY FERGUSON | MF 32 | 620DS | 03.2008- |
| MASSEY FERGUSON | MF 34 | 634DSA | 04.2008- |
| MASSEY FERGUSON | MF 4292 | 420DS | 06.2009- |
| MASSEY FERGUSON | MF 4297 | 420DS | 06.2009- |
| MASSEY FERGUSON | MF 4299 | 420DSA | 06.2009- |
| MASSEY FERGUSON | MF 4299 | 420DSA | 08.2009- |
| MASSEY FERGUSON | MF 460 XTRA | 44DTA | 06.2009- |
| MASSEY FERGUSON | MF 470 XTRA | 44DTA | 06.2009- |
| MASSEY FERGUSON | MF 480 XTRA | 44DTA | 06.2009- |
| MASSEY FERGUSON | MF 5650 | 620DS | 03.2008- |
| MCCORMICK | Tele-Trac 4.4 | 44-CWA | - |
| PIONEIRA | Engine | 420DS | 07.2008- |
| SAMPO ROSENLEW | 3065L 4.4 | 44DT | - |
| SAMPO ROSENLEW | SR1046X 4.4 | 44DT | - |
| SAMPO ROSENLEW | SR1066 4.4 | 44DT | - |
| SAMPO ROSENLEW | SR3045C 4.4 | 44DT | - |
| SAMPO ROSENLEW | SR3085L TS 4.4 | 44DT | - |
| VALTRA | A SERIES A82, A92 | 01.2008-12.2011 | |
| VALTRA | A SERIES A82, A92 | 01.2008-12.2011 | |
| VALTRA | A SERIES A85, A95 | 01.2002-12.2008 | |
| VALTRA | A SERIES A85, A95 | 01.2002-12.2008 | |
| VALTRA | N SERIES N111, N111e | 01.2005-12.2007 | |
| VALTRA | N SERIES N121 | 01.2005-12.2007 | |
| VALTRA | N SERIES N122 | 01.2009-12.2011 | |
| VALTRA | N SERIES N123 | 01.2011- | |
| VALTRA | N SERIES N141 | 01.2005-12.2007 | |
| VALTRA | N SERIES N142 | 01.2009-12.2011 | |
| VALTRA | N SERIES N143 | 01.2011- | |
| VALTRA | N SERIES N163 | 01.2011- | |
| VALTRA | N SERIES N91, N101 | 01.2005-12.2007 | |
| VALTRA | S SERIES S230 | 01.2001-12.2003 | |
| VALTRA | S SERIES S232, S233 | 01.2008-12.2013 | |
| VALTRA | S SERIES S240 | 01.2003-12.2006 | |
| VALTRA | S SERIES S260 | 01.2003-12.2006 | |
| VALTRA | S SERIES S262, S263 | 01.2008-12.2011 | |
| VALTRA | S SERIES S274 | 01.2014- | |
| VALTRA | S SERIES S280 | 01.2003-12.2008 | |
| VALTRA | S SERIES S292, S293 | 01.2008-12.2011 | |
| VALTRA | S SERIES S294 | 01.2014- | |
| VALTRA | S SERIES S322, S323 | 01.2008-12.2011 | |
| VALTRA | S SERIES S324 | 01.2014- | |
| VALTRA | S SERIES S352, S353 | 01.2008-12.2011 | |
| VALTRA | S SERIES S374 | 01.2014- | |
| VALTRA | T120 | ||
| VALTRA | T130 | ||
| VALTRA | T140 | ||
| VALTRA | T160 | ||
| VALTRA | T170 | ||
| VALTRA | T180 | ||
| VALTRA | T190 | ||
| VALTRA | T SERIES T120/c | 01.2004-12.2007 | |
| VALTRA | T SERIES T121 | 01.2007-12.2011 | |
| VALTRA | T SERIES T130/c | 01.2004-12.2007 | |
| VALTRA | T SERIES T131 | 01.2011-12.2011 | |
| VALTRA | T SERIES T132, T152 | 01.2009-12.2011 | |
| VALTRA | T SERIES T133, T153 | 01.2012- | |
| VALTRA | T SERIES T140/c, T150/c | 01.2004-12.2007 | |
| VALTRA | T SERIES T144, T154 | 02.2015- | |
| VALTRA | T SERIES T151e, T161 | 01.2011-12.2012 | |
| VALTRA | T SERIES T160/c | 01.2004-12.2007 | |
| VALTRA | T SERIES T162e | 01.2009-12.2011 | |
| VALTRA | T SERIES T163e | 01.2012- | |
| VALTRA | T SERIES T170/c | 01.2004-12.2007 | |
| VALTRA | T SERIES T171, T191 | 01.2007-12.2012 | |
| VALTRA | T SERIES T172, T182 | 01.2009-12.2011 | |
| VALTRA | T SERIES T173, T193 | 01.2012- | |
| VALTRA | T SERIES T174 | 02.2015- | |
| VALTRA | T SERIES T180, T190 | 01.2004-12.2007 | |
| VALTRA | T SERIES T194 | 02.2015- | |
| VALTRA | T SERIES T202 | 01.2009-12.2011 | |
| VALTRA | T SERIES T203, T213 | 01.2012- | |
| VALTRA | T SERIES T214 | 02.2015- | |
| VALTRA | T SERIES T234 | 02.2015- | |
| ZETOR | 3520 | 7201 | 01.1995- |
| ZETOR | 3540 | 7201 | 01.1995- |
| ZETOR | 4712 2.5 | Z4701 | 01.1974-12.1977 |
| ZETOR | 4718 2.5 | Z4701 | 01.1974-12.1977 |
| ZETOR | 4911 2.6 | Z4901 | 01.1976-12.1980 |
| ZETOR | 5011 2.6 | Z5001 | 01.1980-12.1984 |
| ZETOR | 5211 2.6 | Z5001 | 01.1984-12.1990 |
| ZETOR | 5213 | - | |
| ZETOR | 5243 | - | |
| ZETOR | 5245 | - | |
| ZETOR | 5320 3.5 | Z7201 | 01.1992- |
| ZETOR | 5321 3.5 | 7202 | 01.1997- |
| ZETOR | 5340 3.5 | Z7201 | 01.1992- |
| ZETOR | 5341 3.5 | 7202 | 01.1997- |
| ZETOR | 5511 | Z5501 | - |
| ZETOR | 5516 | Z5501 | - |
| ZETOR | 5545 | Z5501 | - |
| ZETOR | 5611 | Z5501 | - |
| ZETOR | 5645 | Z5501 | - |
| ZETOR | 5647 | Z5501 | - |
| ZETOR | 5711 3.1 | Z-5501 | 01.1974-12.1977 |
| ZETOR | 5718 3.1 | Z5501 | 01.1974-12.1977 |
| ZETOR | 5745 | Z5501 | - |
| ZETOR | 5748 | Z5501 | - |
| ZETOR | 59113.4 | Z5901 | 01.1978-12.1980 |
| ZETOR | 5945 3.4 | Z5901 | 01.1978-12.1980 |
| ZETOR | 6011 3.4 | Z6001 | 01.1980-12.1984 |
| ZETOR | 6045 3.4 | Z6001 | 01.1980-12.1984 |
| ZETOR | 6211 3.4 | Z6001 | 01.1984-12.1990 |
| ZETOR | 6212 3.4 | Z6001 | 01.1984-12.1990 |
| ZETOR | 6245 3.4 | Z6001 | 01.1984-12.1990 |
| ZETOR | 6320 3.9 | Z7701 | 01.1992- |
| ZETOR | 6321 3.9 | Z7702 | 01.1977- |
| ZETOR | 6340 3.9 | Z7701 | 01.1992- |
| ZETOR | 6341 3.9 | Z7702 | 01.1977- |
| ZETOR | 6511 | - | |
| ZETOR | 6518 | - | |
| ZETOR | 6522 | - | |
| ZETOR | 6711 3.4 | Z6701 | 01.1974-12.1977 |
| ZETOR | 6718 3.4 | Z6701 | 01.1974-12.1977 |
| ZETOR | 6745 3.4 | Z6701 | 01.1974-12.1977 |
| ZETOR | 6748 3.4 | Z6701 | 01.1974-12.1977 |
| ZETOR | 6911 3.4 | Z6901 | 01.1978-12.1980 |
| ZETOR | 6918 3.4 | Z6901 | 01.1978-12.1980 |
| ZETOR | 6945 3.4 | Z6901 | 01.1978-12.1980 |
| ZETOR | 7011 3.4 | Z7001 | 01.1980-12.1984 |
| ZETOR | 7045 3.4 | Z7001 | 01.1980-12.1984 |
| ZETOR | 7211 3.5 | Z7201 | 01.1984-12.1990 |
| ZETOR | 7245 3.5 | Z7201 | 01.1984-12.1990 |
| ZETOR | 7321 3.9 | Z7302 | 01.1997- |
| ZETOR | 7340 3.9 | Z7301 | 01.1992- |
| ZETOR | 7341 3.9 | Z7302 | 01.1997- |
| ZETOR | 7520 4.1 | 7801 | 01.1991- |
| ZETOR | 7711 3.9 | Z7701 | 01.1986-12.1990 |
| ZETOR | 7745 3.9 | Z7701 | 01.1986-12.1990 |
Reference Information
| 0001260025 | BOSCH |
| 0001260026 | BOSCH |
| 0001260035 | BOSCH |
| 10010049OV | ITAB AUTOMOTIVE |
| 10021117OV | ITAB AUTOMOTIVE |
| 11.131.727 | ISKRA / LETRIKA |
| 11.132.356 | ISKRA / LETRIKA |
| 113570 | CARGO |
| 162000090722 | NEW HOLLAND |
| 19992N | WAI |
| 20401940OE | REAL |
| 20419711BN | REAL |
| 20419711OE | REAL |
| 25-4033 | ELSTOCK |
| 254420 | KUHNER |
| 254856 | KUHNER |
| 254856B | KUHNER |
| 254856M | KUHNER |
| 254856S | KUHNER |
| 47111575 | CASE |
| 5010948G | MEAT & DORIA |
| 569018D1 | AGCO |
| 6010049.1 | SANDO |
| 6021117.0 | SANDO |
| 6021117.1 | SANDO |
| 72735803 | MAHLE |
| 800.008.113.010 | WAI |
| 800.008.113.090 | WAI |
| 800.008.113.211 | WAI |
| 800.008.113.280 | WAI |
| 800.008.113.311 | WAI |
| 8103 | CEVAM |
| 83646500 | VALTRA |
| 836673290 | VALTRA |
| 836866817 | VALTRA |
| 836873088 | AGCO |
| 836873290 | HESSTON |
| 836873457 | AGCO |
| 84284540 | CASE |
| 87693781 | NEW HOLLAND |
| 87751000 | NEW HOLLAND |
| 88213744 | POWERMAX |
| 89732200 | VALTRA |
| 91-23-6582 | WILSON |
| AZF4190 | ISKRA / LETRIKA |
| AZF4369 | ISKRA / LETRIKA |
| CGB-23257 | AINDE |
| CST10049GS | CASCO |
| CST21117AS | CASCO |
| CST21117GS | CASCO |
| DRS0569 | DELCO |
| DS1679 | DELCO |
| F032113570 | CARGO |
| IS0836 | ISKRA / LETRIKA |
| LRS02361 | LUCAS |
| LRS2361 | LUCAS |
| MAHMS175 | WOODAUTO |
| MAV120490 | SIOM |
| MAV231170 | SIOM |
| MS175 | MAHLE |
| MS591 | MAHLE |
| PRSL814 | 3EFFE |
| S100701 | BTS TURBO |
| S101605 | BTS TURBO |
| S103289 | BTS TURBO |
| S104110 | BTS TURBO |
| S12BH0917 | SIDAT |
| S135.358 | WAI |
| S145.465 | WAI |
| S5001L | PRESTOLITE |
| STI3570 | KRAUF |
| STR10018 | ELECTROLOG |
| STR50592 | WOODAUTO |
| STR60609 | WOODAUTO |
| STR7894 | ELECTROLOG |
| STRL814 | 3EFFE |
| STRL814L | 3EFFE |
| V836866817 | AGCO |
| V836873457 | AGCO |
| VPF7263 | VALTRA |
| WOOSTR50592 | WOODAUTO |
| WOOSTR60609 | WOODAUTO |
Video/Publications
S0285View your shopping basket or Browse other items in Starter Motors.
