S0183 - Brand new AS-PL Starter motor

Associated Numbers

0001218002 0986010590 0986016611 10338 10338R 10353 112541 11355 11361 17005R 20479451BN 20479451OE 20479451RC 20479751RC 22.0338 22.0338M 25-0411 25-1490 3508 35257880 42099451 432538 433256 436061 5002476 6015154 6015157 7700665613 7701351026 7701352055 7701499466 8016611 8953002577 8EA726086-001 9000331420 943251059 AES3183 AES5131 CS338 CST15154AS CST15154GS CST15154RS CST15157RS D11E172 D11E272 DRS0590 DRS3075 EAA-121341 LRS00383 LRS00531 S0183 SS311 SS343 STR2053 VS168

S0183 ASPLList
AES3183 AUTOELECTRO
AES5131 AUTOELECTRO
0001218002 BOSCHList
0986010590 BOSCH
0986016611 BOSCH
9000331420 BOSCHList
112541 CARGO
CST15154AS CASCO
CST15154GS CASCO
CST15154RS CASCO
CST15157RS CASCO
3508 CEVAM
DRS0590 DELCO
DRS3075 DELCO
EAA121341 EAA
11355 EAI
11361 EAI
250411 ELSTOCK
251490 ELSTOCK
8016611 FRIESEN
CS338 HC PARTS
8EA726086001 HELLA
42099451 HERTH+BUSS
22.0338 LAUBER
22.0338M LAUBER
LRS00383 LUCAS
LRS00531 LUCAS
943251059 MAGNETI MARELLI
35257880 PRESTOLITEList
20479451BN REAL
20479451OE REAL
20479451RC REAL
20479751RC REAL
7700665613 RENAULT
7701351026 RENAULT
7701352055 RENAULTList
7701499466 RENAULT
8953002577 RENAULT
6015154 SANDO
6015157 SANDO
SS311 SOVEREIGN
SS343 SOVEREIGN
432538 VALEOList
433256 VALEO
436061 VALEO
D11E172 VALEOList
D11E272 VALEOList
VS168 VALEO
5002476 VOLVOList
17005R WAI / TRANSPO
STR2053 WOODAUTO

0001218002 Bosch
0986010590 Bosch ruil
0986010591 Bosch ruil
102001 Valeo
11010590 EuroTec
11016610 EuroTec
112541 Cargo
11361 EAI
11779 EAI
1205050 PIC
17005R WAI
19721 Lester
19721R WAI
251129 Elstock
251490 Elstock
253051 Elstock
3508 CEVAM
3572 CEVAM
4030 Lester
4030SP Spidan
432538 Valeo
433256 Valeo
433310 Valeo
570501123 PSH
7701381644 Renault
7701499246 Renault
8010590F Friesen
8010600F Friesen
9000331420 Bosch
913075 EDR
913939 EDR
943251059 Magneti Marelli
CS353 HC
D9R134 Valeo
D9R73 Valeo
DRS3075 Remy
DRS3939 Remy
F042002044 Bosch
F042S02044 Bosch
HCS353 HC
IA9329 Mahle
IS9329 Mahle
LRS00531 Lucas
LRS02017 Lucas
LRS383 Lucas
LRS531 Lucas
MSR348 Magneti Marelli
ND036 Valeo
S23156 Hitachi
S26037 Hitachi
STR2053 Unipoint
Bosch 0001218002, 0986010590
Lucas LRS383
MAHLE 11.139.329, AZE4561
Renault 7701352055, 7701381644, 7701499246, 8953008165
Valeo 432538, 433256, 436061
Valeo 102001, D11E172, D9R73, ND036

Substitutes:
Bosch SR6505X
MAHLE IS9329
Remy Light Duty 16566
Wilson 91203507

References:
Bosch 0001218002, 0986010590, 0986010591, 9000331420
Chrysler 53002577
Delco DRS0590, DRS3075, DRS3939, SX0050, SX0274
Delphi SX0050, SX0274
Hella CS338, CS353
INA D9R73
Lester 17085, 17209
Lucas LRS383, LRS531, S1369, S1380
Magneti Marelli 943251059, 943251059010, 943251307, MSR348
Peterson Lighting 17005
PIC Picture ID 108228
Renault 7700665613, 7700764429, 7701351026, 7701499246, 7701499466, 7702111904
Valeo 099451, 102001, 432580, 433256, 433310, D11E172, D9R73, ND036
Wilson 91203507

Specifications

Kilowatt	2.20 kW
Length (L.1)	272 mm
Mount Hole Center - Center (O.1)	86 mm
Mount Hole Center - Center (O.2)	126 mm
Mount Hole Center - Center (O.3)	87 mm
Mount Hole Diameter (C.2)	M10x1.5 mm
No./Mount holes	3 qty
No./Mount holes with thread	1 qty
No./Teeth	10 qty
No./Teeth (Replaces)	10. 12 qty
OEM Product	No
Pinion at Rest (B)	-6.50 mm
Product Line	Standard Line
Product Type	Brand new
Rotation	CW
Spigot Diameter (A)	77 mm
Unit Type	BOSCH
Voltage	12 V

Vehicle Applications

Make	Model	Type	Year
FIAT	CROMA (154_) 2500 TD (154.LL, 154.PL)	8144.97	05.1989-08.1996
FIAT	CROMA (154_) 2500 TD (154.LL, 154.PL)	8144.97.2400	05.1989-08.1996
FIAT	CROMA (154_) 2500 TD (154.LL, 154.PL)	8144.97Y	05.1989-08.1996
FIAT	CROMA (154_) 2500 TDE	8144.97S	12.1991-08.1996
FIAT	Croma 2.5 TD	[8144.97S]	12.1991-08.1996
JEEP	CHEROKEE (XJ) 2.1 TD	J8S	10.1984-09.2001
RENAULT	18 (134_) 2.1 Diesel	J8S711	11.1981-07.1986
RENAULT	18 (134_) 2.1 Diesel (1344)	852710	11.1981-07.1986
RENAULT	18 (134_) 2.1 Diesel (1344)	J8S711	11.1981-07.1986
RENAULT	18 (134_) 2.1 TD	J8S712	11.1981-07.1986
RENAULT	18 Variable (135_) 2.1 Diesel (1354)	852710	11.1980-07.1986
RENAULT	18 Variable (135_) 2.1 Diesel (1354)	J8S711	11.1980-07.1986
RENAULT	20 (127_) 2.1 Diesel (1276)	852702	10.1980-12.1983
RENAULT	20 (127_) 2.1 TD	J8S702	01.1982-12.1983
RENAULT	21 (B48_) 2.1 D	J8S704	07.1989-05.1993
RENAULT	21 (B48_) 2.1 D	J8S784	07.1989-05.1993
RENAULT	21 (B48_) 2.1 D (B480)	J8S784	04.1992-06.1994
RENAULT	21 (B48_) 2.1 D (B48V/B48O)	J8S600	09.1989-12.1992
RENAULT	21 (B48_) 2.1 D (B48V/B48O)	J8S740	09.1989-12.1992
RENAULT	21 (B48_) 2.1 Turbo-D (B486, B488, B48V)	J8S714	09.1989-06.1994
RENAULT	21 (B48_) 2.1 Turbo-D (B486, B488, B48V)	J8S786	09.1989-06.1994
RENAULT	21 (B48_) 2.1 Turbo-D (B486, B488, B48V)	J8S788	09.1989-06.1994
RENAULT	21 Estate (K48_) 2.1 D 4x4 (K486)	J8S704	10.1988-05.1992
RENAULT	21 Estate (K48_) 2.1 D (K480)	J8S784	02.1992-09.1995
RENAULT	21 Estate (K48_) 2.1 D (K/S486)	J8S704	10.1986-09.1990
RENAULT	21 Estate (K48_) 2.1 D (K/S48V, K/S48O)	J8S600	08.1989-12.1992
RENAULT	21 Estate (K48_) 2.1 D (K/S48V, K/S48O)	J8S740	08.1989-12.1992
RENAULT	21 Estate (K48_) 2.1 Turbo-D (K48A, K48W, K487, K488)	J8S714	10.1986-11.1993
RENAULT	21 Estate (K48_) 2.1 Turbo-D (K48A, K48W, K487, K488)	J8S786	10.1986-11.1993
RENAULT	21 Estate (K48_) 2.1 Turbo-D (K48A, K48W, K487, K488)	J8S788	10.1986-11.1993
RENAULT	21 Estate Van (S48_) 2.1 D	J8S704	06.1986-08.1994
RENAULT	21 Saloon (L48_) 2.1 D (L480)	J8S784	10.1992-06.1994
RENAULT	21 Saloon (L48_) 2.1 D (L486)	J8S704	03.1986-12.1989
RENAULT	21 Saloon (L48_) 2.1 D (L48V, L48O)	J8S600	05.1989-06.1994
RENAULT	21 Saloon (L48_) 2.1 D (L48V, L48O)	J8S740	05.1989-06.1994
RENAULT	21 Saloon (L48_) 2.1 TD	J8S704	04.1986-06.1989
RENAULT	21 Saloon (L48_) 2.1 Turbo-D (L48A, L48W, L487, L488)	J8S714	03.1986-06.1994
RENAULT	21 Saloon (L48_) 2.1 Turbo-D (L48A, L48W, L487, L488)	J8S786	03.1986-06.1994
RENAULT	21 Saloon (L48_) 2.1 Turbo-D (L48A, L48W, L487, L488)	J8S788	03.1986-06.1994
RENAULT	25 (B29_) 2.1 Diesel (B296)	J8S706	04.1984-05.1989
RENAULT	25 (B29_) 2.1 Diesel (B296)	J8S736	06.1989-12.1992
RENAULT	25 (B29_) 2.1 Turbo-D FWD (B290, B29W)	J8S708	04.1984-12.1992
RENAULT	25 (B29_) 2.1 Turbo-D FWD (B290, B29W)	J8S738	04.1984-12.1992
RENAULT	30 (127_) 2.1 Turbo-D (1270)	J8S702	02.1982-03.1986
RENAULT	ESPACE II (J/S63_) 2.1 RTDT Quadra	J8S772	01.1991-05.1992
RENAULT	ESPACE II (J/S63_) 2.1 TD (J633, J634, J/S635, J/S63D)	J8S610	01.1991-10.1996
RENAULT	ESPACE II (J/S63_) 2.1 TD (J633, J634, J/S635, J/S63D)	J8S772	01.1991-10.1996
RENAULT	ESPACE II (J/S63_) 2.1 TD (J633, J634, J/S635, J/S63D)	J8S776	01.1991-10.1996
RENAULT	ESPACE II (J/S63_) 2.1 TD (J633, J634, J/S635, J/S63D)	J8S778	01.1991-10.1996
RENAULT	ESPACE II (J/S63_) 2.1 TD (J63E)	J8S612	11.1994-10.1996
RENAULT	ESPACE II VAN (J/S63_) 2.1 TD (S635, S63D)	J8S610	06.1992-10.1996
RENAULT	ESPACE II VAN (J/S63_) 2.1 TD (S635, S63D)	J8S772	06.1992-10.1996
RENAULT	ESPACE I (J11_) 2.1 TD (J/S115)	J8S240	10.1984-12.1990
RENAULT	ESPACE I (J11_) 2.1 TD (J/S115)	J8S774	10.1984-12.1990
RENAULT	ESPACE I (J11_) 2.1 TD (J/S115)	J8S776	10.1984-12.1990
RENAULT	FUEGO (136_) 2.1 TD	J8S712	08.1982-10.1985
RENAULT	Fuego 2.1 TD	[J8S712]	08.1982-10.1985
RENAULT	MASTER I Bus (T__) 2.1 D	J8S330	11.1989-04.1995
RENAULT	MASTER I Bus (T__) 28-35 2.1 D	J8S330	08.1980-07.1998
RENAULT	MASTER I Van (T__) 28-35 2.1 D	J8S330	08.1980-07.1998
RENAULT	R18 2.1 Diesel	[852710]	11.1980-02.1986
RENAULT	R18 2.1 Diesel	[J8S711]	11.1981-02.1986
RENAULT	R18 2.1 TD	[J8S712]	11.1981-02.1986
RENAULT	R20 2.1 TD	[852]	10.1980-12.1983
RENAULT	R25 2.1 Diesel	[J8S706]	04.1984-05.1989
RENAULT	R25 2.1 Diesel	[J8S736]	06.1989-12.1992
RENAULT	R25 2.1 TD	[J8S708]	04.1984-12.1992
RENAULT	R25 2.1 TD	[J8S738]	06.1989-12.1992
RENAULT	R30 2.1 TD	[J8S702]	02.1982-03.1986
RENAULT	SAFRANE I (B54_) 2.1 dT (B546)	J8S760	11.1993-07.1996
RENAULT	Trafic 2.1 Diesel	[852720]	03.1980-10.1997
RENAULT	Trafic 2.1 Diesel	[852750]	09.1980-10.1997
RENAULT	Trafic 2.1 Diesel	[J8S620]	06.1994-10.1997
RENAULT	Trafic 2.1 Diesel	[J8S758]	06.1994-10.1997
RENAULT	Trafic 2.1 Diesel 4x4	[852750]	11.1986-04.1989
RENAULT	TRAFIC Bus (T_, P_, V_) 2.1 D	852720	05.1989-06.1994
RENAULT	TRAFIC Bus (T_, P_, V_) 2.1 D	852750	03.1980-04.1989
RENAULT	TRAFIC Bus (T_, P_, V_) 2.1 D	852750	05.1989-06.1994
RENAULT	TRAFIC Bus (T_, P_, V_) 2.1 D	J8S620	06.1994-10.1997
RENAULT	TRAFIC Bus (T_, P_, V_) 2.1 D	J8S758	06.1994-10.1997
RENAULT	TRAFIC Bus (T_, P_, V_) 2.1 D 4x4	852750	05.1985-02.1989
RENAULT	TRAFIC Platform/Chassis (T_, P_, V_) 2.1 D	852720	03.1980-04.1989
RENAULT	TRAFIC Platform/Chassis (T_, P_, V_) 2.1 D	852750	07.1980-04.1985
RENAULT	TRAFIC Platform/Chassis (T_, P_, V_) 2.1 D	J8S620	09.1994-04.1998
RENAULT	TRAFIC Platform/Chassis (T_, P_, V_) 2.1 D	J8S750	05.1985-02.1989
RENAULT	TRAFIC Platform/Chassis (T_, P_, V_) 2.1 D 4x4	852750	05.1985-02.1989
RENAULT	TRAFIC Platform/Chassis (T_, P_, V_) 2.1 D RWD	852720	05.1989-06.1994
RENAULT	TRAFIC Platform/Chassis (T_, P_, V_) 2.1 D RWD	J8S620	06.1994-10.1997
RENAULT	TRAFIC Platform/Chassis (T_, P_, V_) 2.1 D RWD	J8S758	06.1994-10.1997
RENAULT	TRAFIC Van (T_, P_, V_) 1.9 D	F8Q600	06.1997-03.2001
RENAULT	TRAFIC Van (T_, P_, V_) 1.9 D	F8Q606	06.1997-03.2001
RENAULT	TRAFIC Van (T_, P_, V_) 2.1 D	852750	05.1986-02.1989
RENAULT	TRAFIC Van (T_, P_, V_) 2.1 D	852750	05.1989-06.1994
RENAULT	TRAFIC Van (T_, P_, V_) 2.1 D	852750	09.1980-04.1989
RENAULT	TRAFIC Van (T_, P_, V_) 2.1 D	J8S620	06.1994-10.1997
RENAULT	TRAFIC Van (T_, P_, V_) 2.1 D	J8S758	06.1994-10.1997
RENAULT	TRAFIC Van (T_, P_, V_) 2.1 D 4x4	852750	11.1986-04.1989

Reference Information

0001218002	BOSCH
0986010590	BOSCH
0986016611	BOSCH
10338	KUHNER
10338R	KUHNER
10353	KUHNER
112541	CARGO
11355	EAI
11361	EAI
1516739R	DAF
1516747R	DAF
17005R	WAI
20479451BN	REAL
20479451OE	REAL
20479451RC	REAL
20479751RC	REAL
220032	ERA
22.0338	LAUBER
22.0338M	LAUBER
25-0411	ELSTOCK
25-1490	ELSTOCK
310156	RENAULT
310502	RENAULT
330490	LOGISTIK
3508	CEVAM
35257880	PRESTOLITE
42099451	HERTH+BUSS
432538	VALEO
433256	VALEO
436061	VALEO
5002476	VOLVO
570.501.123.010	WAI
570.501.123.500	WAI
570.501.123.505	WAI
6015154	SANDO
6015157	SANDO
75491649	PEUGEOT
7700499246	RENAULT
7700665613	RENAULT
7700764429	RENAULT
7701351026	RENAULT
7701352055	RENAULT
7701381644	RENAULT
7701499246	RENAULT
7701499466	RENAULT
7702111904	RENAULT
8016611	FRIESEN
8953002577	RENAULT
8953008165	RENAULT
8EA726086-001	HELLA
9000331420	BOSCH
943251059	MAGNETI MARELLI
AES3183	AUTOELECTRO
AES5131	AUTOELECTRO
ANM12810X	ANDEL
CS338	HC PARTS
CST15154AS	CASCO
CST15154GS	CASCO
CST15154RS	CASCO
CST15157RS	CASCO
D11E172	VALEO
D11E272	VALEO
DRS0590	DELCO
DRS3075	DELCO
F032112541	CARGO
LRS00383	LUCAS
LRS00531	LUCAS
LRS383	LUCAS
LRS531	LUCAS
MAV171460	SIOM
MAV171540	SIOM
MAV171570	SIOM
S0183	AS-PL
S12BH0685A2	SIDAT
S133.619	WAI
SS311	SOVEREIGN
SS343	SOVEREIGN
STR00153	ELECTROLOG
STR1986	ELECTROLOG
STR2053	WOODAUTO
STRS124	3EFFE
STRS316	3EFFE
STX200314	STARDAX
VS168	VALEO

Video/Publications

S0183
