Associated Numbers
AEC1753 AUTOELECTRO
113336 CARGO
CAL30201GS CASCO
DAN641 DENSO
57150 EAI
28-4805 ELSTOCK
46543023 FIAT
CA1753IR HC PARTS
8EL738126-001 HELLA
301223RI KUHNER
301753RI KUHNER
11.1753 LAUBER
11.1753M LAUBER
LRA02313 LUCAS
63321491 MAGNETI MARELLIList
63321858 MAGNETI MARELLIList
9213004 POWERMAX
505.504.120 PSH
2030201 SANDO
SA676 SOVEREIGN
ALT12131 WOODAUTO
A4056
A4034 ASPLList
AEC1698 AUTOELECTRO
0986049400 BOSCH
113336 CARGO
CAL30104 CASCO
CAL30104AS CASCO
CAL30104GS CASCO
CAL30104OS CASCO
4754 CEVAM
DA5185 DELCO
DRA4075 DELCO
RAA15186 DELCO
DAN502 DENSO
EAA221028 EAA
56881 EAI
284648 ELSTOCK
210236 ERA
46430530 FIAT
46447117 FIAT
46543023 FIAT
46544329 FIAT
46554408 FIAT
46709068 FIAT
46748343 FIAT
46748353 FIAT
46765838 FIAT
46809068 FIAT
60812535 FIAT
60815944 FIAT
60815953 FIAT
60816045 FIAT
60816954 FIAT
71721106 FIAT
71721512 FIAT
71724056 FIAT
71780050 FIAT
71780054 FIAT
7782188 FIAT
7782315 FIAT
AG0197 GHIBAUDI
CA1698IR HC PARTS
8EL011710701 HELLA
8EL738059001 HELLA
32049400 HERTH+BUSS
ALE1698 KRAUF
LRA02186 LUCAS
063321858010 MAGNETI MARELLI
063321859010 MAGNETI MARELLI
063321860010 MAGNETI MARELLI
063731223010 MAGNETI MARELLI
063731698010 MAGNETI MARELLI
63321491 MAGNETI MARELLIList
63321507 MAGNETI MARELLIList
63321858 MAGNETI MARELLIList
63321859 MAGNETI MARELLIList
944390902020 MAGNETI MARELLI
MAN1117 MAGNETI MARELLI
MRA90202 MAGNETI MARELLI
89212349 POWERMAX
105.505.120 PSH
20104401BN REAL
20104401OE REAL
2030104 SANDO
SB052 SOVEREIGN
20539R WAI / TRANSPO
ALT12067 WOODAUTO
DENDAN502 WOODAUTO
12090289 EuroTec
23315N WAI
23315R WAI
284805 Elstock
46543023 Fiat
505504120 PSH
57150 EAI
6197SP Spidan
63321491 Magneti Marelli
9090185F Friesen
9090202F Friesen
CA1753IR HC
DRA0661 Remy
LRA02313 Lucas
0986049400 Bosch ruil
1012101870 Denso
105505120 PSH
113336 Cargo
12042780 EuroTec
12049400 EuroTec
12060952 EuroTec
23112N WAI
284648 Elstock
46447117 Fiat
46748353 Fiat
46809068 Fiat
60815944 Alfa Romeo
60816954 Alfa Romeo
60816984 Alfa Romeo
6155SP Spidan
63321507 Magneti Marelli
63321859 Magneti Marelli
71721512 Fiat
738059001 Hella
8EL738059001 Hella
9090202F Friesen
A127IM Elmot
ALT4232 Unipoint
ALT4238 Unipoint
ALTH261 Unipoint
CA1698IR HC
DAN502 Denso
DRA4075 Remy
F032UA0086 Bosch
F032UA0086K4K Bosch
F042208020 Bosch
F042A07032 Bosch
HCA1698IR HC
L49400 ATL
LRA02186 Lucas
MAN1117 Magneti Marelli
MAN1860 Magneti Marelli
0986040631 Bosch ruil
113939 Cargo
12040630 EuroTec
12042780 EuroTec
20130226 Prestolite
21427R WAI
283647 Elstock
495501100 PSH
56566 EAI
63321232 Magneti Marelli
ALTH177 Unipoint
CA1223IR HC
F042A0H177 Bosch
L40630 ATL
L62550 ATL
LRB00425 Lucas
063321858010 063321859010 063321860010 063731223010 063731698010 0986049400 105.505.120 113336 20104401BN 20104401OE 2030104 20539R 210236 28-4648 301223RI 301698RI 301698RIM 301753RI 32049400 46430530 46447117 46543023 46544329 46554408 46709068 46748343 46748353 46765838 46809068 4754 56881 60812535 60815944 60815953 60816045 60816954 63321491 63321507 63321858 63321859 71721106 71721512 71724056 71780050 71780054 7782188 7782315 89212349 8EL011710-701 8EL738059-001 944390902020 A4034 AEC1698 AG0197 ALE1698 ALT12067 CA1698IR CAL30104 CAL30104AS CAL30104ES CAL30104GS CAL30104OS CAL30104RS DA5185 DAN502 DENDAN502 DRA4075 EAA-221028 GA321859-A GA321859M-R LRA02186 MAN1117 MRA90202 RAA15186 SB052
Specifications
| Amp | 120 A |
| Bottom Mounting Foot Width (B) | 21.5 mm |
| Diameter (D.1) | 10.5 mm |
| Diameter (D.2) | 12.5 mm |
| Diameter (D.3) | 12.5 mm |
| Length (L.1) | 196 mm |
| Mount Inside Length or Pad Mount C-C (C) | 54 mm |
| OEM Product | No |
| Plug Code | PL_9104 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Type | NO PULLEY |
| Unit Type | LUCAS/MARELLI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ALFA ROMEO | 147 1.9 JTD | [182B9.000] | 06.2003- |
| ALFA ROMEO | 147 1.9 JTD | [937A2.000] | 11.2000- |
| ALFA ROMEO | 156 2.4 JTD | [841G.000] | 10.2003-05.2006 |
| FIAT | Brava 1.9 JTD | [182B4.000] | 12.1998-10.2001 |
| FIAT | Brava 1.9 JTD | [182B9.000] | 09.2000-10.2001 |
| FIAT | Bravo 1.9 Diesel Multijet | 04.2007- | |
| FIAT | Bravo 1.9 JTD | [182B4.000] | 12.1998-10.2001 |
| FIAT | Bravo 1.9 JTD | [182B9.000] | 09.2000-10.2001 |
| FIAT | Doblo 1.9 Diesel Multijet | [186A9.000] | 10.2005- |
| FIAT | Idea 1.9 JTD | [188B2.000] | 01.2004- |
| FIAT | Marea 1.9 JTD | [186A6.000] | 01.2001- |
| FIAT | Marengo 1.9 JTD | [186A6.000] | 08.2000-09.2002 |
| FIAT | Multipla 1.9 JTD | [186A6.000] | 03.2001- |
| FIAT | Punto 1.9 Diesel | [188A3.000] | 09.1999- |
| FIAT | Stilo 1.9 JTD | [192A1.000] | 10.2001- |
| FIAT | Stilo 1.9 JTD | [192A3.000] | 02.2002- |
| FIAT | Stilo 2.4 20V | [192A2.000] | 10.2001- |
| LANCIA | Kappa 2.4 TD | [838A3.000] | 11.1994-10.2001 |
| LANCIA | Lybra 1.9 JTD | [937A2.000] | 05.2001- |
| LANCIA | Lybra 1.9 JTD | [AR32302] | 07.1999-09.2000 |
| LANCIA | Lybra 1.9 JTD | [AR37101] | 09.2000- |
| LANCIA | Lybra 1.9 JTD SW | [AR37101] | 09.2000- |
| LANCIA | Lybra 2.4 JTD | [839A5.000] | 10.1999-09.2000 |
| LANCIA | Lybra 2.4 JTD | [839A6.000] | 09.2000-05.2002 |
| LANCIA | Lybra 2.4 JTD | [841C.000] | 05.2002- |
| LANCIA | Lybra 2.4 JTD | [AR32501] | 10.1999-09.2000 |
| LANCIA | Lybra 2.4 JTD SW | [839A6.000] | 09.2000-05.2002 |
| LANCIA | Musa 1.9 Diesel Multijet | [188B2.000] | 10.2004- |
Reference Information
7782315 46447117 ALTL162 46748343 301223RI MAN1117 20104401OE A12MA0032 63321860010 CA1698IR MRA90202 DA5185 ALT322010 71780054 46748353 89212349 DAN502 63321859010 LRA02186 71780050 A4034 A12MA0032A2 AX 301698RIM 63321507 CAL30104AS 2030104 CAL30104RS 60816954 0986049400 GA321859M-R RNL63321859 301698RI 60816045 63321491 CAL30104 ALE1698 EAA-221028 4754 ALT9023 6033 STA0079R 113336 63321858010 9.44391E+11 20104401BN LRA2186 DRA4075 46809068 46709068 46765838 46544329 8EL738059-001 5540403 ALT2200 20539R 60812535 ALT2280 8EL011710-701 GA321859-A 7782188 SB052 210759 63731698010 28-4648 60816984 ALTS948 CAL30104ES ANM36295X 210236 ALT321430 46543023 32049400 46430530 60815944 RAA15186 DENDAN502 ALT122620 AEC1698 63321858 63321859 301753RI 71721512 63731223010 ALT12067 46554408 ALTF072 AG0197 CAL30104OS 60815953 56881 71724056 CAL30104GS 986049400 105.505.120 71724854 71773262 71721106Video/Publications
063321858010 063321859010 063321860010 063731223010 063731698010 0986049400 105.505.120 113336 20104401BN 20104401OE 2030104 20539R 210236 28-4648 301223RI 301698RI 301698RIM 301753RI 32049400 46430530 46447117 46543023 46544329 46554408 46709068 46748343 46748353 46765838 46809068 4754 56881 60812535 60815944 60815953 60816045 60816954 63321491 63321507 71721106 71721512 71724056 71780050 71780054 7782188 7782315 89212349 8EL011710-701 8EL738059-001 944390902020 A4034 AEC1698 AG0197 ALE1698 ALT12067 ALT122620 ALT2200 ALT2280 ALT321430 ALT322010 ALTF072 ALTL162 ALTS948 AX 6033 CA1698IR CAL30104 CAL30104AS CAL30104ES CAL30104GS CAL30104OS CAL30104RS DA5185 DAN502 DENDAN502 DRA4075 EAA-221028 GA321859-A GA321859M-R LRA02186 LRA2186 MAN1117 MRA90202 RAA15186 RNL63321859 SB052 210759Add Your Number
