Associated Numbers
06D903016D VW
06D903016DX VW
115953 Cargo
12060968 EuroTec
12090361 EuroTec
205548150 PSH
439656 Valeo
440242 Valeo
57425 EAI
606017 Valeo
TG15C144 Valeo
XR837164 Jaguar
A3164 ASPLList
AEC1769 AUTOELECTRO
115953 CARGO
CAL15370 CASCO
CAL15370GS CASCO
9441 CEVAM
DRA0197 DELCO
57270 EAI
285562 ELSTOCK
CA1996IR HC PARTS
8EL738212201 HELLA
XR837164 JAGUAR
11.1996 LAUBER
11.1996M LAUBER
LRA02948 LUCAS
9213750 POWERMAX
205.534.150 PSH
20179073OE REAL
2015370 SANDO
2543315 VALEOList
2543315D VALEOList
2606017 VALEO
439581 VALEOList
440039 VALEOList
TG15C144 VALEOList
TG16C014 VALEOList
06E903016D VW
06E903016DX VW
6525111g
Specifications
| Amp | 150 A |
| Bottom Mounting Foot Width (B) | 70 mm |
| Diameter (D.1) | 9.5 mm |
| Diameter (D.2) | 9.5 mm |
| Diameter (D.3) | 9.5 mm |
| Diameter (D.4) | 9.5 mm |
| Grooves | 6 qty |
| Length (L.1) | 187 mm |
| Mount Inside Length or Pad Mount C-C (C) | 56 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 56 mm |
| Pad mount thickness (E.1) | 70 mm |
| Pad mount thickness (E.2) | 70 mm |
| Plug Code | PL_2303 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 29 mm |
| Pulley Type | CLUTCH |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A6 2.0 TFSi | [BPJ] | 06.2005-03.2011 |
Reference Information
2015370 9441 CAL15370OS ANM32417X 2543315 205.534.150 2543315D 440039 115953 115858 06E903016DX 20179073OE ALT00267 XR837164 2606017 9213750 06D903016D 06E903016D 28-5562 11.1996 ALTF525 LRA02948 ALTF409 CAL15370 CAL15370RS 57270 442098 11.1996M DRA0197 6E903016D 301996RIV CAL15370AS 439581 CA1996IR CAL15370ES LRA2948 A3164 06D903016DX 210554 8EL738212-201 CAL15370GS TG16C014 6E903016DXVideo/Publications
06E903016D 06E903016DX 11.1996 11.1996M 115858 115953 2015370 20179073OE 205.534.150 2543315 2543315D 2606017 28-5562 301996RIV 439581 440039 57270 8EL738212-201 9213750 9441 A3164 AEC1769 ALTF409 ALTF525 CA1996IR CAL15370 CAL15370AS CAL15370ES CAL15370GS CAL15370OS CAL15370RS DRA0197 LRA02948 LRA2948 TG15C144 TG16C014 XR837164 210554Add Your Number
Contact Details
Request More Information
Add your number to the message box below and we will add it to our system
View your shopping basket or Browse other items in Alternators.
