Associated Numbers
AEK3244 AUTOELECTRO
0124525113 BOSCHList
0124525226 BOSCHList
0986081370 BOSCH
CAL10378 CASCO
CAL10378AS CASCO
CAL10378GS CASCO
4663 CEVAM
12994 DELCO
DRA0312 DELCO
A6619 DIXIE
EAA222118 EAA
57302 EAI
285855 ELSTOCK
210850 ERA
9090660 FRIESEN
CA2007IR HC PARTS
8EL738212451 HELLA
112007 LAUBER
LRA03244 LUCAS
89213826 POWERMAX
205545140 PSH
205545150 PSH
20101873BN REAL
20101873OE REAL
2010378 SANDO
06H903016L VW
06H903016LX VW
11466N WAI / TRANSPO
11466R WAI / TRANSPO
90156622 WILSON
ALT10620 WOODAUTO
BOS0124525113 WOODAUTO
Arrowhead ABO0476
JANNCO 40024289N
Bosch 0124525113, 0124525226
Lester 11466
0124525113 Bosch
0124525226 Bosch
06H903016L VW
06H903016LX VW
0986081370 Bosch ruil
11466N WAI
12090346 EuroTec
205545140 PSH
285855 Elstock
57302 EAI
6458SP Spidan
9090660F Friesen
930312 EDR
ALT1555sa Electrolog
CA2007IR HC
DRA0312 Remy
HCA2007IR HC
KTR411090280 KTR
LRA03244 Lucas
Lucas LRA03244
PIC Picture ID 2205771
Remy Light Duty 12994
Volkswagen 06H903016LX, 06H906016L bxa047 0124525226 6525101g
Specifications
| Amp | 140 A |
| Diameter (D.1) | 9.5 mm |
| Diameter (D.2) | 9.5 mm |
| Diameter (D.3) | 9.5 mm |
| Diameter (D.4) | 9.5 mm |
| Grooves | 6 qty |
| Length (L.1) | 196 mm |
| Mount Inside Length or Pad Mount C-C (C) | 56 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 56 mm |
| Pad mount thickness (E.1) | 70 mm |
| Pad mount thickness (E.2) | 70 mm |
| Plug Code | PL_2306 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 30 mm |
| Pulley Type | CLUTCH |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A4 1.8 TFSi | [CABA] | 01.2008-12.2015 |
| AUDI | A4 1.8 TFSi | [CABB] | 11.2007-03.2012 |
| AUDI | A4 1.8 TFSi | [CDHA] | 01.2008-12.2015 |
| AUDI | A4 1.8 TFSi | [CDHA] | 04.2008-12.2015 |
| AUDI | A4 1.8 TFSi | [CDHB] | 11.2007-03.2012 |
| AUDI | A4 1.8 TFSi Quattro | [CDHB] | 09.2008-03.2012 |
| AUDI | A4 2.0 TFSi | [CAEA] | 06.2008-12.2015 |
| AUDI | A4 2.0 TFSi | [CAEB] | 06.2008-05.2013 |
| AUDI | A4 2.0 TFSi | [CDNB] | 06.2008-12.2015 |
| AUDI | A4 2.0 TFSi | [CDNC] | 06.2008-05.2013 |
| AUDI | A4 2.0 TFSi | [CFKA] | 06.2008-12.2015 |
| AUDI | A4 2.0 TFSi Quattro | [CAEB] | 06.2008-12.2015 |
| AUDI | A4 2.0 TFSi Quattro | [CDNC] | 06.2008-12.2015 |
| AUDI | A4 2.0 TFSi Quattro | [CPMA] | 06.2008-12.2015 |
| AUDI | A4 Allroad 2.0 TFSi Quattro | [CDNC] | 04.2009-05.2016 |
| AUDI | A4 Allroad 2.0 TFSi Quattro | [CPMA] | 04.2009-05.2016 |
| AUDI | A5 1.8 TFSi | [CABD] | 10.2007-01.2017 |
| AUDI | A5 1.8 TFSi | [CDHB] | 05.2009-09.2011 |
| AUDI | A5 1.8 TFSi | [CDHB] | 09.2009-03.2012 |
| AUDI | A5 1.8 TFSi | [CJEB] | 10.2007-01.2017 |
| AUDI | A5 1.8 TFSi Sportback | [CDHB] | 11.2009-09.2011 |
| AUDI | A5 2.0 TFSi | [CAEA] | 03.2009-03.2012 |
| AUDI | A5 2.0 TFSi | [CAEB] | 03.2009-06.2014 |
| AUDI | A5 2.0 TFSi | [CDNB] | 03.2009-03.2012 |
| AUDI | A5 2.0 TFSi | [CDNB] | 11.2008-03.2012 |
| AUDI | A5 2.0 TFSi | [CDNC] | 03.2009-06.2014 |
| AUDI | A5 2.0 TFSi | [CDNC] | 06.2008-11.2013 |
| AUDI | A5 2.0 TFSi Quattro | [CAEB] | 03.2009-01.2017 |
| AUDI | A5 2.0 TFSi Quattro | [CAEB] | 06.2008-01.2017 |
| AUDI | A5 2.0 TFSi Quattro | [CDNC] | 03.2009-01.2017 |
| AUDI | A5 2.0 TFSi Quattro | [CDNC] | 06.2008-01.2017 |
| AUDI | A5 2.0 TFSi Quattro | [CPMA] | 03.2009-01.2017 |
| AUDI | A5 2.0 TFSi Quattro Sportback | [CAEB] | 09.2009-01.2017 |
| AUDI | A5 2.0 TFSi Quattro Sportback | [CDNC] | 09.2009-01.2017 |
| AUDI | A5 2.0 TFSi Sportback | [CDNB] | 09.2009-06.2014 |
| AUDI | A5 2.0 TFSi Sportback | [CDNC] | 09.2009-11.2013 |
| AUDI | Q5 2.0 TFSi Quattro | [CAEB] | 11.2008-09.2012 |
| AUDI | Q5 2.0 TFSi Quattro | [CDNB] | 08.2009-05.2017 |
| AUDI | Q5 2.0 TFSi Quattro | [CDNC] | 11.2008-09.2012 |
| AUDI | Q5 2.0 TFSi Quattro | [CNCB] | 08.2009-05.2017 |
| AUDI | Q5 2.0 TFSi Quattro | [CPMA] | 11.2008-09.2012 |
Reference Information
CAL10378ES 06H903016LX 90-15-6622 A-6619 LRA03244 CAL10378AS 443255 EAA-223159 ALT1555 11466N 124525226 ALTF020 DA1422 A12BH0377 57302 115367 986081370 ALT123780A 8EL738212-451 CGB-85855 4663 8EL011713-041 AEK3244 ALT10620 28-5855 A0271 CAL10378 6H903016LX CAL10378RS 345005 ALTF020B ANM32532X ALT539CP CAL10378GS 89213826 205.545.140 06H903016L 440794 6H903016L 20101873 CAL10378OS 302007RIR A12BH0377AS ALB2007 L06H903016L BOS0124525113 0986081370 0124525226 DRA0312 LRA3244 124525113 442373 302007RIB PRAF020 210850 0124525113 ALT123780 CA2007IR 2010378Video/Publications
0124525113 0124525226 06H903016L 06H903016LX 0986081370 11466N 115367 20101873 2010378 205.545.140 210850 28-5855 302007RIB 302007RIR 345005 440794 443255 4663 57302 89213826 8EL011713-041 8EL738212-451 90-15-6622 A-6619 AEK3244 ALB2007 ALT10620 ALT123780 ALT123780A ALT539CP ALTF020 ALTF020B BOS0124525113 CA2007IR CAL10378 CAL10378AS CAL10378ES CAL10378GS CAL10378OS CAL10378RS CGB-85855 DA1422 DRA0312 EAA-223159 LRA03244 LRA3244 PRAF020Add Your Number
