- Associated Numbers
- Specifications
- Vehicle Applications
- Alternatives >>>
- Reference Information
- Video/Publications
- Add Your Number
Associated Numbers
A5098 ASPL List
UD10997A ASPL
AEK2915 AUTOELECTRO
0986081300 BOSCH
CAL35216 CASCO
CAL35216AS CASCO
CAL35216GS CASCO
9424 CEVAM
DRA0109 DELCO
275529 ELSTOCK
12060833 EUROTEC
9090847 FRIESEN
JA1902IR HC PARTS
8EL738211711 HELLA
LRA02915 LUCAS
LF5018300 MAZDA
LF5018400 MAZDA
A003TG1391 MITSUBISHI List
A003TG1391A MITSUBISHI List
A003TG1391AD MITSUBISHI
A003TG4791 MITSUBISHI
A3TG1391 MITSUBISHI List
A3TG1391A MITSUBISHI List
A3TG1391AD MITSUBISHI
A3TG4791 MITSUBISHI
9212485 POWERMAX
20137612BN REAL
20137612OE REAL
SB226 SOVEREIGN
11008N WAI / TRANSPO
90273308 WILSON
ALT31237 WOODAUTO
MITA3TG1391 WOODAUTO
mxa220 656640 arj527 anj513 anj513gq
Bosch AL4238X
Denso 2104214
Mitsubishi A3TG1391A
Remy Light Duty 12615
Wilson 90273308
References:
Beck Arnley 1861172
Bosch AL4238X
Denso 2104214
Lester 11008, 11174
Mazda LF1F18300, LF1F18300R00, LF5018300, LF5018300A
Mitsubishi A003TG1391, A003TG1391A, A003TG1391AZC, A003TG4791, A003TG4791ZC, A3TG1391, A3TG1391A
PIC Picture ID 2035064
Remy Light Duty 12615
Wilson 90273308, 90273369
0986081300 Bosch ruil
0986UR0180 Bosch
11008 Lester
145536090 PSH
275529 Elstock
90273308 Wilson
A003TG1391A Mitsubishi
A003TG4791 Mitsubishi
A3TG1391A Mitsubishi
A3TG4791 Mitsubishi
ALT5153sa Electrolog
AMA427 ATK
DRA0109 Remy
HJA1902IR HC
JA1902 HC
JA1902IR HC
KTR291072180 KTR
L83260 ATL
LF1F18300 Mazda
LF5018300 Mazda
LF5018300A Mazda
LRA02915 Lucas
N5113060 Nipparts
TRA055 TWA
Specifications
| Amp | 90 A |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | 8.5 mm |
| Diameter (D.3) | 10.5 mm |
| Diameter (D.4) | 10.5 mm |
| Grooves | 6 qty |
| Length (L.1) | 191 mm |
| Mount Inside Length or Pad Mount C-C (C) | 70 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 49 mm |
| Pad mount thickness (E.1) | 45 mm |
| Pad mount thickness (E.2) | 80 mm |
| Pad mount thickness (E.3) | 45 mm |
| Pad mount thickness (E.4) | 75 mm |
| Plug Code | PL_2005 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 73 mm |
| Pulley Type | SOLID |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MAZDA | 3 2.0 | [LF17] | 01.2003-12.2009 |
| MAZDA | 5 1.8 | [L823] | 01.2005-12.2010 |
| MAZDA | 5 2.0 | [LFF7] | 01.2005-12.2010 |
| MAZDA | 5 2.3 | [L3C1] | 01.2005-12.2010 |
Alternatives >>>
A5098R - Remanufactured Option
Reference Information
A3TG4791 DRA0109 9424 27-5529 ALM427 JA1902 90-27-3308 PRAJ032 002-M427 A5098 A003TG1391 LF50-18-300 A3TG1391AM CAL35216AS 8EL738211-711 A003TG1391A 115786 9212485 A3TG1391AD JA1902IR LF1F18300 CAL35216ES UD10997A AEK2915 CAL35216 986081300 447196 A003TG1391AD 12060833 A003TG4791 LF50-18-300A A003TG1391AM ALT31237 LF1F-18-300 11008N CAL35216RS 401902 LRA2915 A3TG1391A 0986081300 2M427 LF50-18-400 A3TG1391 20137612BN ANM32329X MITA3TG1391 9090847 ALTJ032 209358 CAL35216GS 2035216 CAL35216OS SB226 20137612OE A12MH0357A2 LRA02915Video/Publications
002-M427 0986081300 11008N 115786 12060833 20137612BN 20137612OE 2035216 27-5529 2M427 401902 8EL738211-711 90-27-3308 9090847 9212485 9424 A003TG1391 A003TG1391A A003TG1391AD A003TG4791 A3TG1391 A3TG1391A A3TG1391AD A3TG4791 A5098 AEK2915 ALM427 ALT31237 ALTJ032 CAL35216 CAL35216AS CAL35216ES CAL35216GS CAL35216OS CAL35216RS DRA0109 JA1902 JA1902IR LF50-18-300 LF50-18-400 LRA02915 LRA2915 MITA3TG1391 SB226 UD10997A 209358Add Your Number
