Associated Numbers
A003TJ1081 A3TJ1081 UD12504A 27-6973 A002TJ0791 A2TJ0791 A5123 AEK3494 ALTF895 DRA1284 LF8J LF8J-18-300 LRA03863 LRA3863 UD11014A 14-897 14897 AS-PL MITSUBISHIList 656640 6566401 656640G anj590GQ LF2L LF2L18300 14191 14-191G
Specifications
| Amp | 110 A |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | 9.5 mm |
| Diameter (D.3) | 10.5 mm |
| Diameter (D.4) | 10.5 mm |
| Grooves | 6 qty |
| Length (L.1) | 188 mm |
| Mount Inside Length or Pad Mount C-C (C) | 68 mm |
| Outside Diameter (O.D.1) | 55 mm |
| Pad mount thickness (E.1) | 45 mm |
| Pad mount thickness (E.2) | 79.5 mm |
| Pad mount thickness (E.3) | 45 mm |
| Pad mount thickness (E.4) | 75 mm |
| Plug Code | PL_3310 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 74.5 mm |
| Pulley Type | SOLID |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MAZDA | Premacy 2.0 | 01.2005- |
Alternatives >>>
A5128 - Brand new option, With Solid pulley
A5358R - Remanufactured Option
Reference Information
A003TJ1081 UD12504A A3TJ1081 A5358Video/Publications
A003TJ1081 A3TJ1081 UD12504AAdd Your Number
