Associated Numbers
BXA072
UD12523A AS-PL
F005A00033 BOSCH List
92049391 HOLDEN
92075371 HOLDEN
92076074 HOLDEN
92077267 HOLDEN
92077270 HOLDEN
anb433 bxa009 bxh1333
92049391 92075371 92076074 92077267 92077270 F005A00033 UD12523A
Specifications
Amp | 100 A |
Bottom Mounting Foot Width (B) | 13 mm |
Diameter (D.1) | 11.5 mm |
Diameter (D.2) | 10.5 mm |
Diameter (D.3) | M10x1.5 mm |
Grooves | 6 qty |
Length (L.1) | 182 mm |
Mount Inside Length or Pad Mount C-C (C) | 42 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 56 mm |
Plug Code | PL_2102 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley Type | SOLID |
Pulley to Mount Distance (A) | 39 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CHEVROLET | Omega 3.8 | 01.1999-12.2007 | |
HOLDEN | Caprice 3.8 i V6 | 01.1995-12.2004 | |
HOLDEN | Commodore 3.8 i V6 | 01.1995-12.2004 | |
HOLDEN | Crewman 3.8 i V6 | 01.2003-12.2004 | |
HOLDEN | One Tonner 3.8 i V6 | 01.2003-12.2004 | |
HOLDEN | Statesman 3.8 i V6 | 01.1995-12.2004 | |
TOYOTA | Lexcen 3.8 | 01.1993-12.1997 |
Alternatives >>>
A0458 - Remanufactured OEM Core
Reference Information
92076074 92049391 92077270 UD12523A 92075371 ALT1351 F005A00033 0F005A00033 92077267Video/Publications
92049391 92075371 92076074 92077267 92077270 F005A00033 UD12523AAdd Your Number
