- Associated Numbers
- Specifications
- Vehicle Applications
- Alternatives >>>
- Reference Information
- Video/Publications
- Add Your Number
Associated Numbers
14-894 14894
UD11026A AS-PL
AEC1957 AUTOELECTRO
0986081220 BOSCH
115548 CARGO
CAL35244AS CASCO
CAL35244GS CASCO
9240 CEVAM
DRA0394 DELCO
57345 EAI
28-5872 ELSTOCK
9090719 FRIESEN
CA1957IR HC PARTS
8EL738212-151 HELLA
11.1957 LAUBER
11.1957M LAUBER
LRA03260 LUCAS
A002TJ0291 MITSUBISHI List
A002TJ0291ZE MITSUBISHI List
A2TJ0291 MITSUBISHI List
A2TJ0291ZC MITSUBISHI List
A2TJ0291ZE MITSUBISHI List
23100-BC00A NISSAN
23100-BC400 NISSAN
23100-EM01A NISSAN List
23100-EM01AR NISSAN
89213733 POWERMAX
165.561.120 PSH
20137442BN REAL
20137442OE REAL
SB317 SOVEREIGN
11344R WAI / TRANSPO
020291
0986081220
11344
165561120
23100BC00A
23100BC400
23100EM01A
285872
90251208
9090719F
930394
A002TJ0291
A2TJ0291ZE
CA1957
CA1957IR
DRA0394
HCA1957IR
JA1957IR
LRA03260
N5111115
Lester 11344
Mitsubishi A002TJ0291, A002TJ0291ZC
Nissan 23100EM01A MXA2072 ANJ550 656690
UD11026A ASPL
AEC1957 AUTOELECTRO
0986081220 BOSCH
115548 CARGO
CAL35244AS CASCO
CAL35244GS CASCO
9240 CEVAM
DRA0394 DELCO
57345 EAI
285872 ELSTOCK
9090719 FRIESEN
CA1957IR HC PARTS
8EL738212151 HELLA
11.1957 LAUBER
11.1957M LAUBER
LRA03260 LUCAS
A002TJ0291 MITSUBISHI List
A002TJ0291ZE MITSUBISHI List
A2TJ0291 MITSUBISHI List
A2TJ0291ZC MITSUBISHI List
A2TJ0291ZE MITSUBISHI List
23100BC00A NISSAN
23100BC400 NISSAN
23100EM01A NISSAN List
23100EM01AR NISSAN
89213733 POWERMAX
165.561.120 PSH
20137442BN REAL
20137442OE REAL
SB317 SOVEREIGN
11344R WAI / TRANSPO
020291
0986081220
11344
165561120
23100BC00A
23100BC400
23100EM01A
285872
90251208
9090719F
930394
A002TJ0291
A2TJ0291ZE
CA1957
CA1957IR
DRA0394
HCA1957IR
JA1957IR
LRA03260
N5111115
Lester 11344
Mitsubishi A002TJ0291, A002TJ0291ZC
Nissan 23100EM01A MXA2072 ANJ550 656690
0986081220 11.1957 11.1957M 11344R 115548 165.561.120 20137442BN 20137442OE 2035244 23100-BC00A 23100-BC400 23100-EM01A 23100-EM01AR 28-5872 301957RI 301957RIM 57345 89213733 8EL738212-151 9090719 9240 A002TJ0291 A002TJ0291ZE A2TJ0291 A2TJ0291ZC A2TJ0291ZE AEC1957 CA1957IR CAL35244AS CAL35244GS DRA0394 LRA03260 SB317 UD11026A 11344N
Specifications
| Amp | 110 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | 8.5 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M8x1.25 mm |
| Grooves | 7 qty |
| Length (L.1) | 184 mm |
| Mount Inside Length or Pad Mount C-C (C) | 59 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 55 mm |
| Plug Code | PL_3320 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 32 mm |
| Pulley Type | SOLID |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| NISSAN | Micra 1.6 160 SR | [HR16DE] | 10.2005- |
| NISSAN | Micra C+C 1.6 SR | [CR16DE] | 01.2005-12.2007 |
| NISSAN | Note 1.6 | [HR16DE] | 01.2006- |
| NISSAN | Qashqai 1.6 | [HR16DE] | 01.2007- |
| NISSAN | Tiida 1.6 | [HR16DE] | 01.2007- |
Alternatives >>>
A5118R - Remanufactured version, has clutch pulley and L-S regulator
A5122 - Brand new version, has clutch pulley and L-S-C regulator
Reference Information
A12MH0698 11.1957M 23100-BC400 A12MH0698A2 A5129 A002TJ0291 AEC1957 9090719 PRAJ031 11.1957 57345 CAL35244GS 23100-EM01AR ANM32614X LRA3260 WOOALT31148 115548 ALM1957 23100-BC00A 11344R 165.561.120.280 23100-EM01A 11344N 165.561.120.130 A2TJ0291 165.561.120.370 0986081220 23100-1HS1A 165.561.120.138 CAL35244AS 9240 8EL738212-151 LRA03260 446535 2035244 55351019 A002TJ0291ZC 301957RIM SB317 A002TJ0291AM A002TJ0291ZE 23110BC00A 89213733 20137442OE RNLA2TJ0291 2035244.1 ALTJ031 CA1957IR DRA0394 UD11026A 445712 23100BC02M 20137442BN ALT5227 23110-BC00A J5111116 A2TJ0291AM A2TJ0291ZE 986081220 A2TJ0291ZC 301957RI 28-5872Video/Publications
0986081220 11.1957 11.1957M 11344N 11344R 115548 165.561.120 20137442BN 20137442OE 2035244 23100-BC00A 23100-BC400 23100-EM01A 23100-EM01AR 28-5872 301957RI 301957RIM 57345 89213733 8EL738212-151 9090719 9240 A002TJ0291 A002TJ0291ZE A2TJ0291 A2TJ0291ZC A2TJ0291ZE AEC1957 ALTJ031 CA1957IR CAL35244AS CAL35244GS DRA0394 LRA03260 LRA3260 RNLA2TJ0291 SB317 UD11026A 209347Add Your Number
