- Associated Numbers
- Specifications
- Vehicle Applications
- Alternatives >>>
- Reference Information
- Video/Publications
- Related Items
Associated Numbers
1022115511 2706022190 1022115500 1022111930 1022111931 2706022050
1012119960 DENSO List
EAA221912 EAA
94857218 OPEL
270600D010 TOYOTA
ALT5111 WOODAUTO
ALT30265 WOODAUTO
References:
Arrowhead AND0177
Bosch AL3292X
Denso 1012119960
General Motors 94857218
Lester 13756
PIC Picture ID 2905000
Toyota 270600D010
Wilson 90295350
J&N 40052037
Delco 94857218
Denso 1012119960
References:
J&N 40052037
Bosch AL3292X
Delco 19134301, 3341308, 94857218
Denso 1012119960, 2100432
Lester 13756
PIC Picture ID 2905000
Toyota 270600D010
dxa555 ARJ197 658385
101211-9960 270600-D010 94857218 ALT-5111 ALT30265 EAA-221912
Specifications
| Amp | 80 A |
| Bottom Mounting Foot Width (B) | 18 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 11 mm |
| Diameter (D.3) | M10x1.25 mm |
| Length (L.1) | 166 mm |
| Mount Inside Length or Pad Mount C-C (C) | 41 mm |
| OEM Product | No |
| Plug Code | PL_3301 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 55 mm |
| Pulley to Mount Distance (A) | 34 mm |
| Pulley Type | Solid |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Corolla 1.8 L | 08.1997-12.2002 |
Alternatives >>>
A6054R - Remanufactured option - wiring in different spot
A6054 - Brand New aftermarket option - wiring in different spot
A6054(DENSO) Genuine Denso Option - wiring in different spot
Reference Information
| 101211-9960 | DENSO |
| 270600-D010 | TOYOTA |
| 94857218 | OPEL |
| ALT30265 | WOODAUTO |
| ALT-5111 | WOODAUTO |
Video/Publications
A6114Related Items
