Associated Numbers
16150 180.016.082 19066N 20437703OE 25-5023 31100-78K00 6035307 91-27-3480 CST35307 CST35307AS CST35307ES CST35307GS CST35307OS CST35307RS DRS0927 J5218032 LRS03850 M000T23171 M0T23171 S-80537 UD12061S
0986025760 20437242OE 25-4254 254676 31100-51K00 31100-73K00 3147 4709919 6035242 8080358 8214184 88214184 93134147 AEY2561 CS1528 CST35242 CST35242AS CST35242ES CST35242GS CST35242OS CST35242RS DRS0642 LRS02582 M000T36971 M000T36971ZE M0T36971 M0T36971ZE UD30040S
UD12061S ASPL
CST35307 CASCO
CST35307GS CASCO
16150 DELCO
DRS0927 DELCO
S80537 DIXIE
255023 ELSTOCK
J5218032 HERTH+BUSS
LRS03850 LUCAS
M000T23171 MITSUBISHI
M0T23171 MITSUBISHI
180.016.082 PSH
20437703OE REAL
6035307 SANDO
3110078K00 SUZUKI
19066N WAI / TRANSPO
91273480 WILSON
11040867 EuroTec
180016082 PSH
19066 Lester
19066N WAI
3110078K0 Suzuki
3110078K00 Suzuki
910927 EDR
DRS0927 Remy
LRS03850 Lucas
M000T23171 Mitsubishi
M0T23171 Mitsubishi
mxs2054 706677 snj803
Denso 2804335
Mitsubishi M0T23171
Remy Light Duty 16150
Wilson 91273480
References:
Arrowhead SMT0395
Beck Arnley 1871028
Denso 2804335
Lester 19066
Mitsubishi M000T23171, M0T23171
PIC Picture ID 1035001
Remy Light Duty 16150
Suzuki 3110078K00
Youtech/PartRef 436971
Wilson 91273480
Arrowhead M0T23171
J&N 41048240
Lester 19066
Mitsubishi M000T23171
Suzuki 3110078K00
Specifications
| Kilowatt | 1.4 kW |
| Length (L.1) | 183 mm |
| Mount Hole Center - Center (O.1) | 103 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | M10x1.75 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 8 qty |
| Pinion at Rest (B) | 28 mm |
| Rotation | CW |
| Spigot Diameter (A) | 70 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| SUZUKI | Grand Vitara 2.4 4x4 | [J24B] | 01.2009-12.2015 |
| SUZUKI | Kizashi 2.4 | 01.2010-12.2014 | |
| SUZUKI | SX4 2.0 | 01.2010-12.2014 |
Reference Information
91-27-3480 180.016.082.130 16150 180.016.082.370 M0T23171 M0T23173 19066N M000T23171AM 31100-78K00 MITM0T23173 UD12061S CST35307AS 31100-78K0 M0T23171AM S5228 25-5023 STRJ602 M0T23173AM M000T23173AM STR5193 J5218032 M000T23173 S12MH0581A2 M000T23171 5035785 DRS0927 LRS03850 20437703OE 6035307.1 S-80537 LRS3850 S12MH0581Video/Publications
16150 180.016.082 19066N 20437703OE 25-5023 31100-78K00 6035307 91-27-3480 CST35307 CST35307AS CST35307ES CST35307GS CST35307OS CST35307RS DRS0927 J5218032 LRS03850 LRS3850 M000T23171 M0T23171 S-80537 S5228 STRJ602 UD12061SAdd Your Number
