Associated Numbers
0001107423 0001107424 0001120400 0001120401 0001120402 0001120403 S0242 0001120400Specifications
| B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 .mm |
| Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
| Coil Bolt Length | 8.7 mm |
| Inside Diameter (I.D.1) | 26 mm |
| L.B+ | 21.7 mm |
| Length (L.1) | 66.2 mm |
| Outside Diameter (O.D.1) | 52.4 mm |
| Outside Diameter (O.D.2) | 45.7 mm |
| Type | Solenoid |
| Unit Type | BOSCH |
| Voltage | 12 V |
Reference Information
2339305052 2339305074 227913 2339305005 235138 2339305024 020911287A SND11110 SOL1357 2339305322Video/Publications
0001107424 0001107423 2339305052 2339305074 1107423 1107424 227913 0001120402 1120400 0001120403 1120401 2339305005 S0242 235138 2339305024 020911287A SND11110 0001120400 1120402 0001120401 1120403Add Your Number
