Associated Numbers
0124615030 0124615041
UD10834ARC AS-PL
F00M133287 BOSCH
1101-160RS RS
IBR287 WAI / TRANSPO
0124615030 BOSCH
0124615041 BOSCH
Bosch F00M133287 Cargo 333813 KRAUF AEB2287AN Transpo IBR287 UTM EB2287A Используется для агрегатов0124515187, 0124615030, 0124615041, 0124615055, 0124615057, ALB0537, ALB3030, ALB3030WA, ALB5941AN, ALB9831UX, RE537508
References:
Bosch F00M133287
PIC Picture ID 7720-1571
0124615030 Bosch, Alternator, 12V, 150A, New
Enlarge 0124615055 0124615055 Bosch, Alternator, 12V, 150A, New
Enlarge 0124615057 0124615057 Bosch, Alternator, 12V, 150A, New
013-154-26-02 Mercedes, Alternator, 12V, 150A
0124615030 Bosch, Alternator, 12V, 150A, New
Enlarge 0124615055 0124615055 Bosch, Alternator, 12V, 150A, New
Enlarge 0124615057 0124615057 Bosch, Alternator, 12V, 150A, New
013-154-26-02 Mercedes, Alternator, 12V, 150A
Agco Sisu Power 4280470F91, 4281878M92, 4281878M93, 4281880M92, 4281880M93, 4288341M91, 800006, 89685300, C000900010320; Bosch 0124615030, 0124615041, 0124615055, 0124615057; Case 03269108, 87452821; Claas 00903320, 07984930; Clark 00903320; Deutz Engine Mfr 01181741, 01182027, 01182040, 01182629, 01182691, 01183185, 01183483, 01183606; Fendt 836864048; John Deere AL119537, AL171541; KHD 01182040; Letrika Old 11.204.550; Massey Ferguson 4280470F91, 4281878M92, 4281878M93, 4281880M92, 8281880M93, 88601600; Mercedes-Benz 0121541402, 013-154-26-02, A0121541402, A0131542602; Perkins Engine 2871A415, 378-9645; Valtra 88601600, 89685300; Zetor Tractor MN 16359209
Specifications
| B+ Stud Diameter & Thread Pitch (B+d) | M8X1.25 mm |
| B+ Thread Length (B+H) | 20.8 mm |
| Diode Amp Rating | 60 A |
| Diodes (Main) | 6 qty |
| D+ Stud Diameter & Thread Pitch (D+d) | M8X1.25 mm |
| D+ Thread Height (D+H) | 8.5 mm |
| Height (H.1) | 52.00 mm |
| Inside Diameter (I.D.1) | 38 mm |
| Mount Distance (C-C) | 54.5 mm |
| Outside Diameter (O.D.1) | 129 mm |
| Reg/Rec Combo | No |
| Source | WYE |
| Unit Type | BOSCH |
| With Attached Bracket | No |
Reference Information
F00M133287 IBR287 RCT1230 UD10834ARCVideo/Publications
F00M133287 IBR287 A0338 0124615030 0124615041 UD10834ARC 124615030 124615041Add Your Number
