Associated Numbers
MAHLE 11.131.399, AZF4104, IS1130
Arrowhead IS1130
Caterpillar 370-4011
MAHLE IS1130
11131399 Mahle
701510103 PSH
AZF4104 Mahle
IS1130 Mahle
MS99 Mahle
N37637 SABRE ENGINES
Specifications
| Description: | Starter |
| OEM(s): | MAHLE |
| Family: | Letrika/MAHLE AZF41 |
| Voltage: | 24 |
| Power: | 4kW / 5.36HP |
| Number of Teeth: | 10 |
| Gear OD: | 1.559in / 39.6mm |
| Application: | Cat Marine and Sabre Applications |
| Kilowatt | 4 kW |
| Length (L.1) | 346 mm |
| Mount Hole Center - Center (O.1) | 90 mm |
| Mount Hole Center - Center (O.2) | 127 mm |
| Mount Hole Center - Center (O.3) | 90 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| Pinion at Rest (B) | 29 mm |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | MAHLE |
| Voltage | 24 V |
