S9254 - Brand new AS-PL Starter motor

Brand new AS-PL Starter motor
Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
MITSUBA
Price:
NZ$ 326.01 including GST

NZ$ 283.49 excluding GST
each
S6394S
S9254
3
Purchase Qty:


120.549.092 16128 17960N 25-4023 31200R40A01 31200R40A01RM 31200R41L01 31200RAAA61 31200RRAA51 31200RZAA01 91-26-2143 AEY2351 LRS02351 RAA5K RRA53 RZA5V S-80314 S9254 SM730-02 STR75460 UD03381S UD12441S sm71004 sm710-04 ASPLList ASPL AUTOELECTRO DELCO S80314 DIXIE 254023 ELSTOCK HONDA HONDAList LUCAS SM73002 MITSUBA PSH WAI / TRANSPO 91262143 WILSON WOODAUTO 702850 snj570 J N 41054107 Bosch SR1331X Remy Light Duty 16055 Wilson 91262074 References: Arrowhead SMU0428 J&amp Acura Honda Lester 17960 Mitsuba SM71002 SM71005 SM71007 SM73001 PIC Picture ID 191183 16057 JANNCO 41054107R BSR1331X 17961 19009 191191 322055092 DRI 910568 EDR 9937 CEVAM DRS0568 H521A51 NPS Lucas SM71002SEL +line SR1331N (USA) SR1346X mxs821 70-2844 SNJ570 31200RTB004 sm710-14 16-593 16593 16-688

Kilowatt1.6 kW
Length (L.1)226 mm
Mount Hole Center - Center (O.1)116 mm
Mount Hole Diameter (C.1)11 mm
Mount Hole Diameter (C.2)13 mm
No./Mount holes2 qty
No./Mount holes with thread0 qty
No./Teeth9 qty
Pinion at Rest (B)34 mm
RotationCW
Spigot Diameter (A)75 mm
Unit TypeMITSUBA
Voltage12 V
Make Model Type Year
ACURA CSX 2.0 01.2006-12.2011
ACURA TSX 2.0 01.2009-12.2010
HONDA Accord 2.4 i [K24A] 01.2006-12.2007
HONDA Accord 2.4 i [K24Z3] 01.2008-12.2015
HONDA Civic 2.0 Type-R [K20Z4] 01.2006-12.2012
HONDA CR-V 2.4 01.2008-12.2011
HONDA Element 2.4 01.2007-12.2011
HONDA TSX 2.4 01.2009-12.2014

S6394S - Denso Style

31200-RAA-A51 UD03381S CST33132AS 91-26-2143 STR75460 31200R40A01 MAV351320A RAA5K UD12441S 31200R40A01RM LRS02351 RZA5V LRS2351 SM710-07 120.549.092 17960N 31200RAAA61 31200RZAA01 113821 AEY2351 31200-RAA-A01 S9254 20467231BN 6033132 M0T20371 M0T20371ZC 31200R41L01 SM730-02 SM730-01 MHG016 RRA53 16128 120.549.092.190 25-4023 31200RRAA51 S-80314
113821 120.549.092 16128 17960N 25-4023 31200R40A01 31200R40A01RM 31200R41L01 31200RAAA61 31200RRAA51 31200RZAA01 91-26-2143 AEY2351 LRS02351 LRS2351 RAA5K RRA53 RZA5V S-80314 S9254 SM710-07 SM730-01 SM730-02 STR75460 UD03381S UD12441S

This starter will replace S9039 Version however this has a bespoke plug that the wiring clips to.
