Associated Numbers
0001112032 0986014350 0986014351 110394 11562 16966N 17194N 17662N 17836N 20380 20380S 20437101BN 20500605 20513028 22.5380 22.5380M 25-1261 25-2456 255566 31100-60A10 31100-60A11 31100-60A12 31100-60A13 31100-60A20 31100-60A22 31100-60AC2 31100-60AD0 31100-82021 31100-83010 31100-83011 31100-83020 31100-83030 31100-83031 31100-83421 31100-A83010 31100-A83031 436053 455901 6035101 8052805 8213162 88213162 8EA011611-141 8EA726468-001 9000333121 9747 AES6105 CST35101AS CST35193AS D6RA13 DRS3045 EAA-121037 GST72481-A ISJ0002 JS380 LRS00605 M1T72481 M1T72481ZC M1T72483 M1T72483ZC M1T74581 M1T74583 M1T85881 M3T34781 M3T34782 M3T38981 M3T41781 ND122 RNL213ZS S5016 SS253 SS389 SS839 STR71031 VS333
S5016 ASPLList
AES6105 AUTOELECTRO
0001112032 BOSCHList
0986014350 BOSCH
0986014351 BOSCH
9000333121 BOSCHList
110394 CARGO
CST35101AS CASCO
9747 CEVAM
DRS3045 DELCO
EAA121037 EAA
11562 EAI
251261 ELSTOCK
252456 ELSTOCK
8052805 FRIESEN
GST72481A GPARTS
JS380 HC PARTS
8EA011611141 HELLA
8EA726468001 HELLA
ISJ0002 ISKRA / LETRIKA
22.5380 LAUBER
22.5380M LAUBER
LRS00605 LUCAS
M1T72481 MITSUBISHIList
M1T72481ZC MITSUBISHIList
M1T72483 MITSUBISHIList
M1T72483ZC MITSUBISHIList
M1T74581 MITSUBISHIList
M1T74583 MITSUBISHIList
M1T85881 MITSUBISHIList
M3T34781 MITSUBISHIList
M3T34782 MITSUBISHIList
M3T38981 MITSUBISHIList
M3T41781 MITSUBISHIList
8213162 POWERMAX
88213162 POWERMAX
20500605 PRESTOLITE
20513028 PRESTOLITE
20437101BN REAL
RNL213ZS RNL
6035101 SANDO
SS253 SOVEREIGN
SS389 SOVEREIGN
SS839 SOVEREIGN
3110060A10 SUZUKI
3110060A11 SUZUKIList
3110060A12 SUZUKIList
3110060A13 SUZUKI
3110060A20 SUZUKIList
3110060A22 SUZUKI
3110060AC2 SUZUKIList
3110060AD0 SUZUKI
3110082021 SUZUKIList
3110083010 SUZUKIList
3110083011 SUZUKIList
3110083020 SUZUKIList
3110083030 SUZUKIList
3110083031 SUZUKIList
3110083421 SUZUKIList
31100A83010 SUZUKIList
31100A83031 SUZUKIList
436053 VALEO
455901 VALEO
D6RA13 VALEOList
ND122 VALEO
VS333 VALEO
16966N WAI / TRANSPO
17194N WAI / TRANSPO
17662N WAI / TRANSPO
17836N WAI / TRANSPO
STR71031 WOODAUTO
Arrowhead SMT0056
Bosch F042001037, SR4501X
Delco 96064783, 96065247
Denso 2804144
General Motors 96064783, 96065247
Lester 17266
Mitsubishi M001T72483, M001T72483ZC, M1T72481, M1T72483, M1T72483ZC
Suzuki 3110060A22
Wilson 91273102, 91273256
103160
11012590 EuroTec
11040298 EuroTec
11040302 EuroTec
11562 EAI
17194N WAI
17194R WAI
17206 Lester
17836N WAI
180508092 PSH
252456 Elstock
3110060A10 Suzuki
3110060A11 Suzuki
3110060A12 Suzuki
3110060A13 Suzuki
3110060A20 Suzuki
3110060A22 Suzuki
3110060A30 Suzuki
3110060AD0 Suzuki
8052812F Friesen
910914 EDR
A12590 ATL
AZS264 ATK
D6RA13 Valeo
J5218005 Nipparts
M001T72481 Mitsubishi
M001T72483 Mitsubishi
M001T74581 Mitsubishi
M001T74583 Mitsubishi
M001T85881 Mitsubishi
M1T72481 Mitsubishi
M1T72481ZC Mitsubishi
M1T72483 Mitsubishi
M1T72483ZC Mitsubishi
M1T74581 Mitsubishi
M1T74583 Mitsubishi
M1T85881 Mitsubishi
snj561 706029 706106 mxs253 mxs811
Specifications
| Kilowatt | 0.7 kW |
| Length (L.1) | 189 mm |
| Mount Hole Center - Center (O.1) | 105 mm |
| Mount Hole Diameter (C.1) | 9.5 mm |
| Mount Hole Diameter (C.2) | 9.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 8 qty |
| No./Teeth (Replaces) | 8. 9 qty |
| Pinion at Rest (B) | 4.5 mm |
| Rotation | CW |
| Spigot Diameter (A) | 66 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| SUZUKI | Grand Vitara 1.6 | [G16B] | 03.1998- |
| SUZUKI | Jimny 1.3 16V | [G13BB] | 09.1998- |
| SUZUKI | Jimny 1.3 16V | [M13A] | 02.2001- |
| SUZUKI | Jimny 1.3 16V 4WD | [G13BB] | 09.1998- |
| SUZUKI | Jimny 1.3 16V 4WD | [M13A] | 02.2001- |
| SUZUKI | Samurai 1.3 | [G13A] | 11.1988- |
| SUZUKI | Samurai 1.3 | [G13BA] | 11.1988- |
| SUZUKI | SJ 413 1.3 | [G13A] | 08.1984-08.1990 |
| SUZUKI | Vitara 1.6 | [G16A] | 09.1988-03.1998 |
| SUZUKI | Vitara 1.6 16V | [G16B] | 09.1991-12.1994 |
| SUZUKI | Vitara 1.6 i 4WD | [G16B] | 07.1990-03.1999 |
| SUZUKI | X-90 1.6 i 16V | [G16B] | 09.1995- |
| SUZUKI | X-90 1.6 i 16V 4WD | [G16B] | 09.1995- |
Reference Information
M001T74583ZC 9.43252E+11 M003T41781 STM0380 31100-83021 PRSL019 31100-83020 31100-83421 31100-60AD0 20437101BN 110394 M1T72481ZC 455901 M3T34782B 25-1261 5035049 M3T39981 31100-60AC2 J5218017 31100-83030 31100-83031 ANM15265X 20500605 0001112032 31100-60A22 9747 31100-60A20 M003T34782-B 31100-60A10-000 M1T74583ZC M3T38981 SS253 31100-60AB1 EAA-121037 31100-60AB2 M001T74581 220017 M001T74583 31100-60AB0 986014350 986014351 M003T24782 LRS605 3110082021 11562 31100-60A10 31100-60A11 31100-60A12 31100-60A13 M001T72483ZC M003T31471 1A51-18-400 3110093031 M1T72481 3110083010L M1T72483 3110085C00 436053 M3T34782 31100-60A12-000 M3T34781 3110060AD0 M3T38982 S5016 3110060A20000 3.11008E+12 M003T39981 CST35101AS M3T34782-B M001T74581ZC 22.538 SS839 STR5059 96064782 20380M 31100-A83031 STR71031 M003T38981 M1T72483ZC CGB-51261 M003T34781 M003T34782 3110060A22 3110060A20 M0T85781 31100-82021 S12MH0042A2 SS389 31100-60A20-000 RNL213ZS 3110083021 6035101 20380 JS380 LRS00605 22.5380M STRL019 3110-60AB1 8052805 M1T74581ZC 180.004.082.415 3110060A13 3110060A12 31106-0AB1 3110060A11 3110060A10000 429917400 M001T72481 MQS0380 STA0170R M001T72483 1112032 M000T85781 M001T72481ZC 000986014350 31100-A83010 000986014351 96058456 180.004.082.130 M1T74583 M1T74581 M3T41781 31100-83010 31100-83011 M3T24782 16966N 8EA011611-141 3100083021 335230 MAV6160 M3T31471 31100-85C00Video/Publications
0001112032 003-Z212 003-Z213 0986014350 0986014351 110394 11562 16966N 17194N 17662N 17836N 20380 20380S 20437101BN 20500605 20513028 22.5380 22.5380M 220017 25-1261 25-2456 255566 31100-60A10 31100-60A11 31100-60A22 31100-60AC2 31100-60AD0 31100-82021 31100-83010 31100-83011 31100-83020 31100-83030 31100-83031 31100-83421 31100-A83010 31100-A83031 3Z212 3Z213 436053 455901 6035101 8052805 8213162 88213162 8EA011611-141 8EA726468-001 9000333121 9747 AES6105 CGB-23045 CST35101 CST35101AS CST35193AS D6RA13 DRS3045 EAA-121037 GST72481-A ISJ0002 J5218017 JS380 LRS00605 LRS605 M1T72481 M1T72481ZC M1T72483 M1T72483ZC M1T74581 M1T74583 M1T85881 M3T34781 M3T34782 M3T38981 M3T41781 MAV371930 MAV6160 MTZ212 MTZ213 ND122 RNL213ZS S5016 SS253 SS389 SS839 STR71031 STRL019 VS333Add Your Number
