Associated Numbers
113191 161.508.113 18058N 18058R 20445306BN 23300-06J01 23300-06J02 23300-06J04 23300-34T00 254138 6020603 CST20603AS S2050 S25-158 S25-158A S25-158B S25-160 S25158A UD02122S
snj443 hxs9408
S2050 ASPLList
UD02122S ASPL
113191 CARGO
CST20603AS CASCO
S25158 HITACHIList
S25158A HITACHIList
S25158B HITACHIList
S25160 HITACHIList
S25158A HITACHIList
2330006J01 NISSAN
2330006J02 NISSANList
2330006J04 NISSANList
2330034T00 NISSANList
161.508.113 PSH
20445306BN REAL
6020603 SANDO
18058N WAI / TRANSPO
18058R WAI / TRANSPO
703013 hxs9408 srj400
11040697 EuroTec
161508113 PSH
18058N WAI
18058R WAI
2330006J01 Nissan
2330006J02 Nissan
2330006J04 Nissan
2330034T00 Nissan
91251127 Wilson
913883 EDR
A76660 ATL
ADS944 ATK
DRS3883 Remy
LRS01886 Lucas
S25158 Hitachi
S25158A Hitachi
S25158B Hitachi
S25160 Hitachi
STR3110NDsa Electrolog
STR3110sa Electrolog
TRS159 TWA
Hitachi S25158BN
Substitutes:
Wilson 91251127
References:
Nissan 2330006J02
Denso 2809011
Hitachi S25158, S25158A, S25158B
Lester 18058
Nissan 2330006J01, 2330006J02, 2330006J04
PIC Picture ID 104292
Wilson 91251127N
S2050 ASPLList
UD02122S ASPL
113191 CARGO
CST20603AS CASCO
S25158 HITACHIList
S25158A HITACHIList
S25158B HITACHIList
S25160 HITACHIList
S25158A HITACHIList
2330006J01 NISSAN
2330006J02 NISSANList
2330006J04 NISSANList
2330034T00 NISSANList
161.508.113 PSH
20445306BN REAL
6020603 SANDO
18058N WAI / TRANSPO
18058R WAI / TRANSPO
Specifications
| Kilowatt | 4.5 kW |
| Length (L.1) | 257 mm |
| Mount Hole Center - Center (O.1) | 81 mm |
| Mount Hole Center - Center (O.2) | 140 mm |
| Mount Hole Center - Center (O.3) | 115 mm |
| Mount Hole Diameter (C.1) | 13.5 mm |
| Mount Hole Diameter (C.2) | 13.5 mm |
| Mount Hole Diameter (C.3) | 13.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| No./Teeth (Replaces) | 11 qty |
| Pinion at Rest (B) | 6 mm |
| Rotation | CW |
| Spigot Diameter (A) | 105 mm |
| Unit Type | HITACHI |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| NISSAN | Patrol GR 4.2 D | [TD42] |
Reference Information
S25-160 S2050 3D944 003-D944 18058N 23300-6J02 23300-6J04 18058R 23300-06J01 6020603 23300-06J02 336210 STR3110B 23300-06J04 CGB-25158 23300-34T00 MAV226030 20445306BN S25-158 254138 113191 161.508.113 CST20603AS MTD944 UD02122S S25158A S25-158B S25-158AVideo/Publications
003-D944 113191 161.508.113 18058N 18058R 20445306BN 23300-06J01 23300-06J02 23300-06J04 23300-34T00 254138 3D944 6020603 CGB-25158 CST20603AS MAV226030 MTD944 S2050 S25-158 S25-158A S25-158B S25-160 S25158A UD02122SAdd Your Number
