Associated Numbers
230.506.102 255546D 8000222 96627036 96673023 DRS0903 PXPSC-013 S1085R UD02077S
70-6286 snd046 snd046gq DXS592
11090329 EuroTec
230506102 PSH
255153 Elstock
328085102 DRI
8000222 Remy
96627036 Opel
96673023 GM
DRS0903 Remy
LRS03991 Lucas
57-105 57105
UD02077S ASPL
8000222 DELCO
96627036 DELCO
96673023 DELCO
DRS0903 DELCO
PXPSC013 PARTS MALL
S1085R PRESTOLITE
230.506.102 PSH
706286
11090329 EuroTec
230506102 PSH
255153 Elstock
8000222 Remy
96627036 Opel
96673023 GM
DRS0903 Remy
LRS03991 Lucas
DXS592 SND046gq
Specifications
Kilowatt | 1.2 kW |
Length (L.1) | 213 mm |
Mount Hole Center - Center (O.1) | 98 mm |
Mount Hole Diameter (C.1) | 10.5 mm |
Mount Hole Diameter (C.2) | 10.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
No./Teeth (Replaces) | 10 qty |
Pinion at Rest (B) | 29 mm |
Rotation | CW |
Spigot Diameter (A) | 68 mm |
Unit Type | DELCO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CHEVROLET | Captiva 3.2 4WD | [LU1] | 06.2006- |
OPEL | Antara 3.2 V6 | [Z32SEE] | 07.2006-12.2011 |
Reference Information
4805519 96673023 CST46115GS 96627036 TZ 6046115.1 230.506.102.390 1202516 S1085R DRS0903 255546D 95520349 LRS03991 KC PXPSC-013 8000222 230.506.102.030 LRS3991 DS2013 11090329 20460511OE 25-5153 UD02077SVideo/Publications
230.506.102.390 255546D 8000222 230.506.102.030 DRS0903 PXPSC-013 S1085R UD02077S CST46115GS 20460511OE DS2013 6046115.1 96627036 96673023 25-5153 LRS03991 LRS3991 11090329 1202516 4805519 95520349 KC TZAdd Your Number
