Associated Numbers
16160 36100-3C151 8000465 PXPSA-024 S-1536 STD0465 UD02650SDelco 8000465
Hyundai 361003C151
Lester 6968
PIC Picture ID 1406072B 41012726
7062581
UD02650S ASPL
16160 DELCO
8000465 DELCO
S1536 DIXIE
361003C151 HYUNDAI / KIA
STD0465 KRAUF
PXPSA024 PARTS MALL
Specifications
Kilowatt | 1.4 kW |
Length (L.1) | 220 mm |
Mount Hole Center - Center (O.1) | 101 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 10 qty |
No./Teeth (Replaces) | 10 qty |
Pinion at Rest (B) | 17 mm |
Rotation | CW |
Spigot Diameter (A) | 70 mm |
Unit Type | DELCO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HYUNDAI | Azera 3.0 | [G6DE] | 01.2011- |
HYUNDAI | Azera 3.0 | [G6DG] | 01.2011-12.2016 |
HYUNDAI | Grandeur 3.0 | [G6DG] | 01.2011-12.2016 |
HYUNDAI | Grandeur 3.0 | [G6DG] | 01.2012-12.2016 |
HYUNDAI | Grand Santa Fe 3.3 V6 | [G6DF] | 01.2014- |
HYUNDAI | Grand Santa Fe 3.3 V6 Allroad | [G6DF] | 01.2013- |
HYUNDAI | Grand Santa Fe 3.3 V6 Allroad | [G6DH] | 01.2013- |
HYUNDAI | ix55 3.8 V6 AWD | [G6DA] | 01.2011-12.2013 |
HYUNDAI | Santa Fe 3.5 | [G6DC] | 01.2009-12.2013 |
HYUNDAI | Santa Fe 3.5 | [G6DC] | 01.2011-12.2013 |
HYUNDAI | Santa Fe 3.5 4x4 | [G6DC] | 01.2011-12.2012 |
KIA | Sorento 3.3 | [G6DF] | 01.2015- |
KIA | Sorento 3.3 4WD | [G6DF] | 01.2015- |
KIA | Sorento 3.5 | [G6DC] | 01.2013- |
KIA | Sorento 3.5 | [G6DC] | 01.2013-12.2015 |
KIA | Sorento 3.5 4WD | [G6DC] | 01.2011- |
Reference Information
CST46127GS 361003C151 6046127.1 361003C151RU S1078(DELCO) 91-01-4770 S-1536 25-5223 LRS04059 STD0465 6968N 36100-3C151 20460721OE LRS4059 UD02650SVideo/Publications
20460721OE 25-5223 6046127.1 6968N 91-01-4770 CST46127GS LRS04059 LRS4059 S-1536 STD0465 UD02650SAdd Your Number
