Associated Numbers
0001125507 0001125508 0001125517 0001125518 069911023J 069911023M 0986018940 101187 101187B 11979 20401692BN 20401692OE 20401692RC 22.1187 22.1187M 25-3024 3024 32553N 42018380 458538 6010296 8018940 8212301 88212301 8EA012527-371 8EA737802-001 AEU1187 CS1187 CST10296AS CST10296GS CST10296RS DRS8940 EAA-121081 LRS01540 S0192 SS643 STR50317
S0192 ASPLList
AEU1187 AUTOELECTRO
0001125507 BOSCHList
0001125508 BOSCHList
0001125517 BOSCHList
0001125518 BOSCHList
0986018940 BOSCH
CST10296AS CASCO
CST10296GS CASCO
CST10296RS CASCO
3024 CEVAM
DRS8940 DELCO
EAA121081 EAA
11979 EAI
253024 ELSTOCK
8018940 FRIESEN
CS1187 HC PARTS
8EA012527371 HELLA
8EA737802001 HELLA
42018380 HERTH+BUSS
22.1187 LAUBER
22.1187M LAUBER
LRS01540 LUCAS
8212301 POWERMAX
88212301 POWERMAX
20401692BN REAL
20401692OE REAL
20401692RC REAL
6010296 SANDO
SS643 SOVEREIGN
458538 VALEO
069911023J VW
069911023M VW
32553N WAI / TRANSPO
STR50317 WOODAUTO
0001125507 Bosch
0001125508 Bosch
0001125517 Bosch
0001125518 Bosch
069911023J VW
069911023M VW
0986018940 Bosch ruil
11018940 EuroTec
11090174 EuroTec
112430 Cargo
114690 Cargo
11979 EAI
120425 PIC
231221 Cargo
253024 Elstock
300557092 PSH
3024 CEVAM
32553 Lester
32553N WAI
458538 Valeo
4639SP Spidan
8018940F Friesen
918940 EDR
A18940 ATL
CS1187 HC
DRS8940 Remy
F032US0053 Bosch
F032US0053K4S Bosch
F042S02188 Bosch
F042S0H121 Bosch
HCS1187 HC
LRS01540 Lucas
OSM11039 Optimum
STM1031 Rolling Components
STR1317sa Electrolog
STR2291 Unipoint
STRH121 Unipoint
Specifications
Kilowatt | 2 kW |
Length (L.1) | 235 mm |
Mount Hole Center - Center (O.1) | 51 mm |
Mount Hole Center - Center (O.2) | 92 mm |
Mount Hole Center - Center (O.3) | 106 mm |
Mount Hole Diameter (C.1) | M12x1.75 mm |
Mount Hole Diameter (C.2) | 12 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 21 mm |
Rotation | CW |
Spigot Diameter (A) | 82.5 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
VW | LT 28-35 2.5 TDi | [ANJ] | 05.1999-07.2006 |
VW | LT 28-35 2.5 TDi | [APA] | 05.1999- |
VW | LT 28-35 2.5 TDi | [AVR] | 12.2002-07.2006 |
VW | LT 40-55 2.5 TDi | [ANJ] | 05.1999- |
Alternatives >>>
S0049 - Has 2 threaded holes
Reference Information
STA0176R RAS39051 DRS8940 S0192 101187B CST10296RS RNL1894 63721187010 8EA012527-371 6010296 LRS01540 1516682R STM1031 300.557.092.215 32553N 300.557.092.770 300.557.092.010 300.557.092.210 300.557.092.018 AEU1187 MAV122960 20401692RC 9.4428E+11 3328 1125507 986018940 1125508 8EA737802-001 069911023J CST10296AS 20401692BN LRS1540 069911023M 3024 20401692OE 220651 69911023M ANM11160X STR1317 1125517 069911023JX 0001125508 1125518 25-3024 69911023J 0001125507 STR50317 112430 AI-80020 PRSS100 22.1187M S12BH0797A2 CGB-53024 458538 22.1187 6010296.1 8018940 EAA-121081 101187 6010296.2 STRS100 SS643 69911023MX MQS1187 11979 CS1187 0001125517 332242 9.43212E+11 0001125518 300.557.092.280 CST10296GS 88212301 069911023MX 000986018940Video/Publications
0001125507 0001125508 0001125517 0001125518 069911023J 069911023M 0986018940 101187 101187B 112430 11979 20401692BN 20401692OE 20401692RC 22.1187 22.1187M 25-3024 32553N 42018380 458538 6010296 8018940 8212301 88212301 8EA012527-371 8EA737802-001 AEU1187 CS1187 CST10296AS CST10296GS CST10296RS DRS8940 EAA-121081 LRS01540 LRS1540 MAV122960 RNL1894 S0192 SS643 STR50317 STRS100 220651< Critical Notes >
** May come with main battery feed connection on the side of the starter, This is removeable if you require it.**
** May come without main battery feed connection, you may need to reuse your original one.**
