Associated Numbers
UD11525A ASPL 56029914AD CHRYSLER 56029914AF 56029914AL 4210000470 DENSO List 4210000500 4210000711 ALN0146 KRAUF 11240N6G1 WAI / TRANSPO 11240R6G1 ALT30452 WOODAUTO 11240 11240N 4210000440 4210000530 56029914AG 835910160 40052137R 2100631 2905137 2905137D 5905137C 94746 90295686 40052373R 2905137B 2905137C Arrowhead AND0416 Chrysler Denso 2100650 421000053 Lester Wilson J N 40052373 AND0414 PIC Picture ID Remy Light Duty 12850 11240N-6G1 11240R-6G1 421000-0470 421000-0500 421000-0711 554067RI anj317 dxa4039 ARROWHEAD VND0416 BOSCH AL6472X MOTORS 210-0631 ELECTRICAL PRODUCT 400-52137 400-52137R LESTER 04801252AD 0986CN0707 Bosch ruil 0986CN0711 0986UR0707 0986UR0711 EAI 2100706 show 4801252AD PSH 90295686N AL6470N (USA) AL6470X AL6472N AIM AZ-00107R Ashdown Ingram DXA4039 BBB Industries Reman Service Europe 0-986-UR0-707 Dixie Electric Ltd A-80342 Hollander 908C IAT 210-11240 Industry J& MPA 15035 15694 NAPA 13-9729 213-9729 New Advantage N11240 290-5137 Romaine Voltux V2-11240 V2-11240R Wagner 610060A 1-2854-01ND 11240-6G1 11240R 11240R-6G2 90-29-5686 15201115 AES 6602914AD A80342 Wood Auto RNL4210000500 RNL RNL4210000530 WOOALT30452 J&N 65-8520 ANJ317 PRODUCTSSpecifications
| Amp | 160 A |
| Bottom Mounting Foot Width (B) | 12 mm |
| Diameter (D.1) | 11.5 mm |
| Diameter (D.2) | 12.5 mm |
| Diameter (D.3) | M10x1.75 mm |
| Diameter (D.4) | 10 mm |
| Grooves | 6 qty |
| Length (L.1) | 157 mm |
| Mount Inside Length or Pad Mount C-C (C) | 68 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 57 mm |
| Plug Code | PL_2804 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 26 mm |
| Pulley Type | SOLID |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CHRYSLER | Aspen 4.7 | 01.2007- | |
| DODGE | Durango 4.7 | 01.2007- | |
| DODGE | Nitro 3.7 | 01.2007-12.2009 | |
| JEEP | Commander 3.7 | 01.2007- | |
| JEEP | Commander 4.7 | ||
| JEEP | Grand Cherokee 3.7 | ||
| JEEP | Grand Cherokee 4.7 | ||
| JEEP | Liberty 3.7 | 01.2007-12.2009 |
Reference Information
ALN0146 56029914AL 20132535BN ALT30452 UD11525A 2040535 421000-0470 421000-0711 554067RI 421000-0500 56029914AF 56029914AD 11240N-6G1 CAL40535AS 11240R-6G1Video/Publications
11240N-6G1 11240R-6G1 421000-0470 421000-0500 421000-0711 554067RI 56029914AD 56029914AF 56029914AL ALN0146 ALT30452 UD11525AAdd Your Number
