Associated Numbers
6585041 ANJ350 65-8504-1
A6061
UD11507A ASPL
1042105520 DENSO List
1042105521 DENSO
2706037030 TOYOTA List
2706037031 TOYOTA List
104210-5520 104210-5521
Specifications
| Amp | 130 A |
| Diameter (D.1) | 11 mm |
| Diameter (D.2) | M8x1.25 mm |
| Diameter (D.3) | M10x1.25 mm |
| Grooves | 6 qty |
| Length (L.1) | 168.5 mm |
| Outside Diameter (O.D.1) | 55.5 mm |
| Pivot Foot Length (B) | 20 mm |
| Pivot Inside Length (C) | 51 mm |
| Plug Code | PL_4002 |
| Pulley Type | CLUTCH |
| Pulley to Mount Distance (A) | 35 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Noah 2.0 | [3ZR] | |
| TOYOTA | Voxy 2.0 | [3ZR] |
Alternatives >>>
A6061S - 100 Amp Version
Reference Information
UD11507A 27060-37030 104210-5520 27060-37031 104210-5521Video/Publications
104210-5520 104210-5521 27060-37030 27060-37031 UD11507AAdd Your Number
