or four payments of $120.70
with
Learn More
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
104210-3701Associated Numbers
1042103700
1042103701
11205
285724
2905286
455521150
930742
ALT30272
ALT6416sa
DAN986
DRA0742
KTR911042300
LR008862
LRA03112
YLE500240
YLE500410
65-8507-1 DXA4021
AEK3112 AUTOELECTRO
115928 CARGO
DRA0742 DELCO
1042103700 DENSO
1042103701 DENSO List
DAN986 DENSO
285724 ELSTOCK
LRA03112 LUCAS
YLE500410 ROVER
11205R WAI / TRANSPO
ALT30272 WOODAUTO
ANJ298
J&N 40052372
Arrowhead AND0413, VND0413
Bosch AL9351X
Denso 1042103700, 1042103701
Lester 11205
Lucas LRA03112
PIC Picture ID 2905286
Remy Light Duty AR101786
Rover YLE500240, YLE500410
Wilson 90295609
JANNCO 40052372R
Bosch AL9351X
Denso 2100693
Remy Light Duty 12705
Wilson 90295609
References:
Arrowhead AND0413
Denso 2100693
Lester 11205
Wilson 90295609
104210-3700 104210-3701 11205R 115928 20132803BN 20132803OE 2040308 28-5724 553927RID A6043 AEK3112 ALT30272 CAL40308AS CAL40308GS DAN986 DRA0742 LRA03112 YLE500410
|
0210800120 |
Denso |
|---|---|
|
063377524010 |
Magneti Marelli |
|
0986UR0562 |
Bosch Exchange |
|
1042103700 |
Denso |
|
1042103701 |
Denso |
|
11205N |
WAI |
|
11205R |
WAI |
|
115928 |
HC-Cargo |
|
13201177 |
AES |
|
20201208 |
AES |
|
444258 |
Valeo |
|
455521150 |
PSH |
|
63377524 |
Magneti Marelli |
|
63377524010 |
Magneti Marelli |
|
AL9351X |
Bosch (USA) |
|
ALT30272 |
Wood Auto |
|
ALT620 |
Rolling Components |
|
DAN986 |
Denso |
|
DENDAN986 |
Wood Auto |
|
DRA0742 |
Delco Remy |
|
LEA0701 |
Lucas |
|
LR008862 |
Land Rover |
|
LRA03112 |
Lucas |
|
LRA3112 |
Lucas |
|
MAN7524 |
Magneti Marelli |
|
RNL1042103700 |
RNL |
|
RNL1042103701 |
RNL |
|
WOOALT30272 |
Wood Auto |
|
YLE500240 |
Land Rover |
|
YLE500240E |
Land Rover |
|
YLE500410 |
Land Rover |
Specifications
| Amp | 150 A |
| Diameter (D.1) | 12 mm |
| Diameter (D.2) | 13 mm |
| Diameter (D.3) | 15 mm |
| Length (L.1) | 165 mm |
| Mount Inside Length or Pad Mount C-C (C) | 49 mm |
| OEM Product | No |
| Pad mount thickness (E.1) | 40 mm |
| Pad mount thickness (E.2) | 50 mm |
| Pad mount thickness (E.3) | 50 mm |
| Plug Code | PL_3402 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 54 mm |
| Pulley to Mount Distance (A) | 30 mm |
| Pulley Type | Solid |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| LAND ROVER | Discovery 4.0 V6 | (TAA) | 02.2005- |
Reference Information
| 104210-3700 | DENSO |
| 104210-3701 | DENSO |
| 11205R | WAI / TRANSPO |
| 115928 | CARGO |
| 20132803BN | REAL |
| 20132803OE | REAL |
| 2040308 | SANDO |
| 28-5724 | ELSTOCK |
| 446919 | LOGISTIK |
| 553927RID | KUHNER |
| A6043 | AS-PL |
| AEK3112 | AUTOELECTRO |
| ALT30272 | WOODAUTO |
| ALT6416 | ELECTROLOG |
| AM-3604 | AUTO MAGNETO |
| ANM32962X | ANDEL |
| CAL40308AS | CASCO |
| CAL40308GS | CASCO |
| DAN986 | DENSO |
| DRA0742 | DELCO |
| F032115928 | CARGO |
| LRA03112 | LUCAS |
| LRA3112 | LUCAS |
| STX100440 | STARDAX |
| YLE500200 | ROVER |
| YLE500410 | ROVER |
Video/Publications
A6043View your shopping basket or Browse other items in Alternators.
