Associated Numbers
1012110860 1012110861 1012110862 111603 CARGO CAL40605AS CASCO DRA3743 DELCO 1002117170 DENSO List 1002117370 EAA221672 EAA 481627 ELSTOCK JA984IR HC PARTS 8EL737059001 HELLA LRA02447 LUCAS 2706058020 TOYOTA 2706058090 ALT30093 WOODAUTO 11208006 196502030 5474SP 9760211717 1002116200 1002116210 196502050 2706058030 2706058050 483531 DRA3744 JA1118IR SA067 658484 anj355 100211-7170 100211-7370 20132506BN 2040605 27060-58020 27060-58090 40984RI 48-1627 8EL737059-001 EAA-221672 Denso show Cargo Mahle 12060391 EuroTec 12060393 PSH 235133304 DRI Toyota Elstock Spidan Remy L82060 ATL LucasSpecifications
Amp | 30 A |
Bottom Mounting Foot Width (B) | 58 mm |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | 10.5 mm |
Groove Width (W.1) | 15.5 mm |
Grooves | 1 qty |
Length (L.1) | 157 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 50 mm |
Outside Diameter (O.D.2) | 86.5 mm |
Plug Code | PL_3500 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley Type | SOLID |
Pulley to Mount Distance (A) | 96 mm |
Unit Type | DENSO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Dyna 3.0 Diesel 200 | (BU61)[11B] | 08.1988-09.1993 |
Reference Information
ALT426050 20132506BN 2040605 8EL737059-001 EAA-221672 DRA3743 40984RI 100211-4780 100211-7370 ALT6260 2706058050 100211-7170 27060-58020 LRA02447 ALT30093 2706058030 CGB-13743 27060-58020-84 CAL40605AS 111603 ALTF796 JA984IR LRA2447 2.70606E+11 48-1627 9760211717 27060-58090 9760211-717Video/Publications
100211-7170 100211-7370 111603 20132506BN 2040605 27060-58020 27060-58090 40984RI 48-1627 8EL737059-001 ALT30093 ALT426050 ALTF796 CAL40605AS CGB-13743 DRA3743 EAA-221672 JA984IR LRA02447 LRA2447< Critical Notes >
We have listed some alternators as a cross over that are not 100% a match.
We added them as an option but may require slight modification.
If you have part number 101211-0860 101211-0861 101211-0862 then you will need to swap the pulley from your old unit if you need twin belts.
Also you will require ATP6006 Wiring adaptor plug
