Associated Numbers
lr250508B lr250-508b 8971443921 LR280501 HITACHI List LR280506 LR280508 8972489141 ISUZU 8973515740 9873325020 ALT32187 WOODAUTO Hitachi Isuzu 8973325020 Lester 12718 PIC Picture ID 204303 J N 40044127 12718N 136804080 CAL20608AS hxa092 anj406 6530161g 554612RI LR280-501 LR280-506 LR280-508 20145806BN 2020608.0 List ISUZU 0280508 Andre Niermann 116531 Cargo PSH 2020608 Sando 20206080 224291 EAA 2617 CEVAM 8972416291 8972482951 8972489150 8973325032 8973515741 8981808750 Wood Auto L612210 BTS Turbo L83510 ATL show LR280502 LR280503B LR280505 LR280507B LR280508B LR280509 RNLLR280508 RNL WOOALT32187Specifications
| Amp | 80 A |
| Bottom Mounting Foot Width (B) | 17 mm |
| Diameter (D.1) | 8 mm |
| Diameter (D.2) | 10 mm |
| Diameter (D.3) | 10 mm |
| Grooves | 3 qty |
| Groove Width (W.1) | 11.5 mm |
| Length (L.1) | 282 mm |
| Mount Inside Length or Pad Mount C-C (C) | 77 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 55 mm |
| Outside Diameter (O.D.2) | 82 mm |
| Plug Code | PL_2004 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 43 mm |
| Pulley Type | SOLID |
| Unit Type | HITACHI |
| Vacuum Pump | Yes |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ISUZU | Various Models | [4HE1] | |
| ISUZU | Various Models | [4HF1] |
Alternatives >>>
A2046 - Manufacturer Difference
