Associated Numbers
1161910FD
1161911FD
1161930FD
1161931FD
20232101
20232102
2023211
20232111
20232112
7778
885517115
F3HT10300LA
F3HZ10346B
F3PU10346BA
F5HT10300BA
F5PU10346EA
F6HT10300KA
F6HT10300MA
F6PU10346AF
F6PU10346TA
F6PZ10346AFRM
F6PZ10346TARM
GL325
UD01134A ASPL
EAA222085 EAA
F0PU10346CA FORD List
F0PU10346NC FORD List
F0VF10300AA FORD List
F0VU10300AA FORD List
F0VU10300AB FORD
F0VU10300AC FORD
F0VY10346A FORD List
F0VY10346B FORD List
F0VY10346BRM FORD
F5HT10300BA FORD
F5HZ10346E FORD
F5PU10346EA FORD
F6HT10300KA FORD
F6HT10300MA FORD
F6PU10346AF FORD
F6PU10346TA FORD
F6PZ10346AF FORD
F6PZ10346AFRM FORD
F6PZ10346TA FORD
F6PZ10346TARM FORD
1019059RS RS
774911N WAI / TRANSPO
Arrowhead AFD0043
Bosch AL7530X
Ford F5HT10300BA, F5HZ10346E, F5PU10346EA, F6HT10300KA, F6HT10300MA, F6PU10346TA, F6PZ10346AF, F6PZ10346TA, GL352, GL387, GL389
Lester 7778, 777811
Wilson 90025082, 90025082N
400-14072 40014072
650004 axa967 ANA018
Specifications
This Alternator can be converted to single wire by using the self excited regulator 230-14044
| Amp | 130 A |
| Bottom Mounting Foot Width (B) | 77 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 11 mm |
| Grooves | 2 qty |
| Length (L.1) | 170 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 47.5 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Type | SOLID |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | B600 | 7.0L/429CI V8 | 1992 - 1998 |
| FORD | B700 | 7.0L/429CI V8 | 1992 - 1998 |
| FORD | B800 | 7L/429CI V8 | 1992 - 1998 |
| FORD | CF8000 | 7.8L/473CI L6 | 1993 |
| FORD | CF8000 | 8.3L/504CI L6 | 1993 - 1997 |
| FORD | F600 | 5.9L/359CI L6 | 1993 - 1994 |
| FORD | F600 | 6.6L/401CI L6 | 1993 |
| FORD | F600 | 7.0L/429CI V8 | 1992 - 1994 |
| FORD | F700 | 5.9L/359CI L6 | 1993 - 1996 |
| FORD | F700 | 6.6L/401CI L6 | 1993 |
| FORD | F700 | 7.0L/429CI V8 | 1992 - 1998 |
| FORD | F800 | 5.9L/359CI L6 | 1995 - 1997 |
| FORD | F800 | 7.0L/429CI V8 | 1997 - 1998 |
| FORD | F800 | 7.8L/473CI L6 | 1993 |
| FORD | F800 | 8.3L/504CI L6 | 1993 - 1997 |
| FORD | L8501 | 5.9L/359CI L6 | 1997 - 1998 |
| FORD | L8501 | 8.3L/505CI L6 | 1997 - 1998 |
| FORD | LN7000 | 5.9L/359CI L6 | 1993 - 1997 |
| FORD | LN7000 | 6.6L/401CI L6 | 1993 |
| FORD | LN8000 | 7.8L/473CI L6 | 1993 |
| FORD | LN8000 | 8.3L/504CI L6 | 1993 - 1997 |
| FORD | L-Series | CATERPILLAR 3126 | 1995 - 1999 |
| Make | Model | Engine | Years |
