Associated Numbers
S114870 S13551Specifications
| B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 .mm |
| Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
| Coil Bolt Length | 13.3 mm |
| Inside Diameter (I.D.1) | 22.7 mm |
| L.B+ | 13.5 mm |
| Length (L.1) | 60.2 mm |
| Outside Diameter (O.D.1) | 52.6 mm |
| Outside Diameter (O.D.2) | 43.6 mm |
| Type | Solenoid |
| Unit Type | HITACHI |
| Voltage | 12 V |
Reference Information
UD00305SS UD00329SS SOL3058Video/Publications
S13551 S2042 UD00305SS UD00329SS S114870Add Your Number
