Associated Numbers
8000174Specifications
| B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 .mm |
| Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
| Coil Bolt Length | 9.7 mm |
| L.B+ | 14.3 mm |
| Length (L.1) | 73.4 mm |
| Outside Diameter (O.D.1) | 52.6 mm |
| Outside Diameter (O.D.2) | 46.9 mm |
| Type | Solenoid |
| Unit Type | DELCO |
| Voltage | 12 V |
Reference Information
SOL2037 10520736 UD02724SSVideo/Publications
8000174 UD02724SSAdd Your Number
