Associated Numbers
8000032Specifications
| B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 .mm |
| Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
| Coil Bolt Length | 8.3 mm |
| L.B+ | 21.3 mm |
| Length (L.1) | 81 mm |
| Outside Diameter (O.D.1) | 52.6 mm |
| Outside Diameter (O.D.2) | 46.3 mm |
| Type | Solenoid |
| Unit Type | DELCO |
| Voltage | 12 V |
Reference Information
SND13049 UD02633SS 330380 SOL2036 UD01819SS CQ2031428Video/Publications
SND13049 UD02633SS 8000032 330380 UD01819SS CQ2031428Add Your Number
