Associated Numbers
361002G200 DRS0618 8000357 8000285Specifications
B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 .mm |
Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M6x1.0 mm |
Coil Bolt Length | 8.2 mm |
L.B+ | 13 mm |
Length (L.1) | 55.2 mm |
Outside Diameter (O.D.1) | 46.4 mm |
Outside Diameter (O.D.2) | 42.2 mm |
Type | Solenoid |
Unit Type | DELCO |
Voltage | 12 V |
Reference Information
36120-2G200 054.000.151.037 054.000.151.036 ZM1261 66-190 SOL2005 1261 335722 71261 337188 ZN71261 E8134 054.000.151.390 36120-03BB0 SSD2022Video/Publications
361003C151 8000529 36120-2G200 S3132S 66-190 361002E501 361002E500 S1078(DELCO) DRS0618 361002G200 361002G000 UD02632SS 8000285 8000400 8000357 36120-03BB0 SSD2022 S9337SAdd Your Number
