Associated Numbers
LR1100711BGhibaudi PRP661 Hitachi GD214970L, L110023201, L1100G23201 Mobiletron RH71 Nissan 231246P601, 232300L700, 232304P106 SJ JH771 Transpo IHR771 Unipoint REC697A UTM EH0771A Используется для агрегатовLR1100711B, LR1100711B, LR1100725, LR1100725B, LR1100725C, LR1110721, LR1110721B, LR1110721E, LR1110721F, LR1130703
L1100G-23201 HITACHI
23230-0L700 NISSAN
1104-039RS RS
IHR771 WAI / TRANSPO
LR1100711B
Arrowhead AHI1275
Hitachi GD14970L, L1100-23201, L1100G23201
PIC Picture ID 7704-1551
Regitar RH71
L1100G43001 Hitachi, Housing, SRE, Alternators
L1100G53081 Hitachi, Regulator, Electronic, 12V
LR1100-711B Hitachi, Alternator, 12V, 100A
Specifications
| B+ Stud Diameter & Thread Pitch (B+d) | M5x0.8 mm |
| B+ Thread Length (B+H) | 13.2 mm |
| Diode Amp Rating | 60 A |
| Diodes (Main) | 6 qty |
| Outside Diameter (O.D.1) | 119.4 mm |
| Reg/Rec Combo | No |
| Unit Type | HITACHI |
| With Attached Bracket | No |
Reference Information
IHR771 215464 L1100G-23201 RCT3038 23230-0L700Video/Publications
IHR771 215464 LR1100711B L1100G-23201 23230-0L700Add Your Number
