Associated Numbers
16-738
- ARROWHEAD SCH0037, SMU0137, SMU0358
- DENSO 028000-0850, 028000-0851, 028000-8710, 028000-8711, 028000-8712, 128000-8750, 128000-9242, 228000-0851, 228000-9850
- HI LEVEL 217350, 219502, STS0137
- HYOSUNG 31100-42A01, 31100-HD6-300, 31100-HL7-300
- J&N ELECTRICAL PRODUCTS 410-54052
- LESTER 18783, 18811, 19625
- SOCIETA GENERALE RICAMBI 17.81227
- SUZUKI 31100-05300, 31100-05320, 31100-05500, 31100-05501, 31100-05510
-
AIM SN-00407R Amsco SZ-124 Arrowhead SMU0137 DENSO 028000-8710, 028000-8711, 028000-8712, 228000-0850, 228000-0851 Dixie Electric New 242-06136, 246-06136 Electric Motor Service SS-1, SS-1N IAT 620-091 Industry 18783 J&N 410-54052 Lester 18783 PIC 191-468 Remy Power Products RS41211 Romaine Electric 18783N Standard Starter Drive 439416 Suzuki 31100-05300, 31100-05320, 31100-05500, 31100-05501, 31100-05510, 31100-05530 Voltux V1-18783 WAI 18783N, 2-2412-MT Wilson 71-26-18783
DENSO 028000-8710, 028000-8711, 028000-8712, 228000-0850, 228000-0851 IAT 620-091 Lester 18783 PIC 191-468 Remy Power Products RS41211 Suzuki 31100-05300, 31100-05320, 31100-05500, 31100-05501, 31100-05510, 31100-05530 620-18811 Lester 18811 PIC 191-486 Suzuki 31100-42A01
Specifications
| Kilowatt | 0.4 kW |
| Length (L.1) | 147 mm |
| Mount Hole Center - Center (O.1) | 65.5 mm |
| Mount Hole Diameter (C.1) | 6.5 mm |
| Mount Hole Diameter (C.2) | 6.8 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| Pinion/Drive OD | 13.6 mm |
| Rotation | ACW |
| Spigot Diameter (A) | 29.8 mm |
| Spigot Diameter (A) | 30 mm |
| Unit Type | SMALL MOTOR( Briggs, Kohler, UT etc) |
| Unit Type | MITSUBA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| SUZUKI | DN125 | ||
| SUZUKI | DR125 | ||
| SUZUKI | DR200 | ||
| SUZUKI | GN125 |
