Associated Numbers
844503 John Deere MIA12023 U7646D12001E01 SND0768 410-52421 JOHN DEERE U76-46D12-001E01 16094N 0128036182 0128036482 Lester 16094
Specifications
| Mount Hole Center - Center (O.1) | 58 mm |
| Mount Hole Diameter (C.1) | 8.5 mm |
| Mount Hole Diameter (C.2) | 8.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 15 qty |
| Pinion at Rest (B) | 3 mm |
| Rotation | ACW |
| Spigot Diameter (A) | 60 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| JOHN DEERE | Gator XUV 550 | 16HP 57 | |
| JOHN DEERE | Gator XUV 550 S4 | 16HP 57 | |
| JOHN DEERE | Gator XUV 560 | 16HP 57 | |
| JOHN DEERE | Gator XUV 560 S4 | 16HP 57 |
