Associated Numbers
230A1 230A1-3708000 UD10949SSpecifications
| Kilowatt | 1.5 kW |
| Length (L.1) | 318 mm |
| Mount Hole Center - Center (O.1) | 105 mm |
| Mount Hole Diameter (C.1) | M12x1.75 mm |
| Mount Hole Diameter (C.2) | M12x1.75 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| Pinion at Rest (B) | 28 mm |
| Rotation | CW |
| Spigot Diameter (A) | 82 mm |
| Unit Type | UNIVERSAL |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| GAZ | 3307 | ||
| GAZ | 53 | ||
| GAZ | 66 | ||
| GAZ | 71 | ||
| GAZ | 73 | ||
| KAVZ | Various Models | ||
| PAZ | 3205 | ||
| PAZ | 672 |
Reference Information
11131826 STR0065 230A1 СТ230A1370800010 UD10949S CT230A1370800010 300N10597Z 230A1-3708000 СТ230Ð1370800010 CT230A13708000 60423708000 52343708 5.234E+14Video/Publications
230A1 230A1-3708000 UD10949SAdd Your Number
