- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Add Your Number
Associated Numbers
25-4367 255127 255127R 28100-40120 28100-40121 428080-6121 DENDSN1221 DSN1221 LRS02695 LRS2695 STN0058 UD805279(DENSO)SSpecifications
| Kilowatt | 0.8 kW |
| Length (L.1) | 205 mm |
| Mount Hole Center - Center (O.1) | 130 mm |
| Mount Hole Diameter (C.1) | 11.5 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 8 qty |
| Pinion at Rest (B) | 26 mm |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | IQ 1.0 | [1KR-FE] | 01.2009- |
Reference Information
6040398.1 255127R 28100-40120 28100-40121 DENDSN1221 STN0058 428080-6121 STR6704 25-4367 MAV423980 255127 DSN1221 LRS02695 UD805279(DENSO)S 20432893OE LRS2695 CST40398GSVideo/Publications
25-4367 255127 255127R 28100-40120 28100-40121 428080-6121 DENDSN1221 LRS02695 LRS2695 STN0058 UD805279(DENSO)SAdd Your Number
